Contents
7- i nch touch screen tablet 26
Instrument panels 33
Indicator and warning lamps 38
Adjustment buttons 54
Setting the date and time 57
Trip computer 59
Monitoring Familiarisation
Electronic key - remote control 61
"Keyless Entry and Star ting"
system 64
Central locking 72
Doors 73
Boot 75
Motorised tailgate 76
Alarm 79
Electric windows 82
Access
Front seats 84
Rear seats 92
Seat modularity 99
Mirrors 101
Steering wheel adjustment 103
Ventilation 104
Heating 106
Manual dual-zone air conditioning 107
Dual-zone digital air conditioning 109
Rear screen demist - defrost 115
Scented air freshener 116
Interior
fi ttings 118
Rear multimedia 127
Comfort
Starting-switching off the engine
with the electronic key 135
Starting-switching off the engine with the
"Keyless Entry and Starting" system 137
Electric parking brake 141
Hill start assist 148
5-speed manual gearbox 149
6-speed manual gearbox 149
6-speed electronic gearbox system 150
Automatic gearbox 154
Gear shift indicator 159
Stop & Start 160
Display of inter-vehicle time 163
Speed limiter 168
Cruise control 171
Active cruise control 174
Collision risk aler t 182
Lane depar ture warning system 185
Blind spot sensors 186
Parking sensors 189
Reversing camera 191
360 Vision 192
Park Assist 194
Driving
Eco-driving

.
7
Familiarisation
Exterior


Motorised tailgate

This system simplifies the opening and closing of the boot by means of motorisation of the
tailgate.
7
6
260 18
6
224

Te m p o r a ry puncture repair
kit
This kit is a complete system, consisting of acompressor and a sealant car tridge, for the
temporary repair of a tyre.

Under-inflation detection

This system continuously monitors thepressures in the tyres and aler ts you in theevent of an under-inflated tyre.


Blind spot sensors

In cer tain driving conditions, this system
detects the presence of vehicles in the blind
spots. You are aler ted by the illumination of a
warning lamp in the corresponding mirror.

.
25
Familiarisation

Limit the causes of excess consumption


Spread loads throughout the vehicle; place the heaviest items in the bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.


At the end of winter, remove snow tyres and refit your summer tyres.


Observe the recommendations on
maintenance


Check the tyre pressures regularly, when cold, referring to the label inthe door aperture, driver's side. Carry out this check in par ticular:


- before a long journey,

- at each change of season,

- after a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.


Have your vehicle ser viced regularly (engine oil, oil filter, air filter...) andobser ve the schedule of operations recommended by the manufacturer.


When refuelling, do not continue after the third cut-off of the nozzle toavoid any over flow.


At the wheel of your new vehicle, it is only after the first 1 800 miles (3 000 kilometres) that you will see the fuel consumption settle down toa consistent average.

1
45
Monitoring
StateCauseAction / Observations
Service
on temporarily. A minor fault has occurred for which
there is no specific warning lamp. Identify the fault by means of the associated message, such as:


- opening of a door, the boot or bonnet,

- low engine oil level,

- low screenwash/headlamp wash fluid level,

-
discharged remote control battery,

- low tyre pressures,

- saturation of the par ticle emission filter (PEF) on
Diesel vehicles.
For more information on the PEF, refer to the
"Checks - par ticle emissions filter" section.
For any other faults, contact a CITROËN dealer or a qualified workshop.

fix
ed. A major fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message and contact
a CITROËN dealer or a qualified workshop.

1
49
Monitoring
Warning / indicator lampStateCauseAction / Observations
Battery charge fixed. The battery charging circuit has a fault (dirty or loose terminals, slack or cut alternator belt, ...). The warnin
g lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or a
qualified workshop.
Maximum coolant temperature

fixed red. The temperature of the cooling system is too high. Stop as soon as it is safe to do so.
Wait until the engine has cooled down before topping
up the level, if necessary.
If the problem persists, contact a CITROËN dealer or qualified workshop.
Directionalheadlamps
flashing. The directional headlamps system has a fault. Have it checked by a CITROËN dealer or a qualified
workshop.
Door(s) open
*
fixed, associated with
a message identifying
the door, if the speed is
below 6 mph (10 km/h).
A door or the boot is still open. Close the door or boot.

fixed, associated with a
message identifying the
door, and accompanied
by an audible signal
if the speed is above
6 mph (10 km/h).
*

Only with the type 1 instrument panel.
Engine oilpressure

fixed. There is a fault with the engine
lubrication system. You must stop as soon it is safe to do so.
Park, switch off the ignition and contact a CITROËN
dealer or a qualified workshop.

61
2
Access
Remote control


















Electronic key

System which permits remote locking or
unlocking of the vehicle as well as opening the
boot and, depending on version, operation of
the alarm.
It also allows the location and star ting of the
vehicle as well as providing protection against
theft.
The electronic key includes an integral back-up emergency key.
Unlocking the vehicle
)
Press this button.
Unlocking the vehicle and
openin
g the boot

The direction indicators flash for a few seconds. The door mirror spot lampscome on. Depending on version, the door mirrors unfold, the welcome lighting comes on, the alarm is deactivated.
)
Make a long press on thisbutton to unlock the vehicleand, depending on version,release the tailgate or open the
motorised tailgate.
) To unlock the other doors and the boot,
press this button again.

The settin
g of the selective unlocking is done in
the "Driving assistance" menu, then "Vehicle
settings".Complete unlocking is activated by default.
Complete unlocking
) To unlock only the driver's door,
press this button once.
Selective unlocking Settings for the motorised tailgate can be
adjusted in the "Driving assistance " menu,
then " Vehicle settings". Motorised operation is activated by default.

62
Access
) Press this button.
Holding the button allows the
windows to be raised to the desired position.
Normal locking
If a door or the boot is not properly closed, locking does not take place. Never theless, the alarm (if fitted) will befully activated after around 45 seconds.If the vehicle is unlocked by mistake and no action is taken on the doors or boot, the vehicle will lock itself againautomatically after about thir ty seconds. if the alarm had already been activated,it will not be reactivated automatically.


The direction indicators come on for a few seconds. Depending on your version, the door mirrors fold, the alarm is activated.
Locking the vehicle

Ensure that nothing could prevent thecorrect closing of the windows.
Be aware of children when operating the windows.


The automatic folding and unfolding of the door mirrors can be deactivatedby a CITROËN dealer or a qualifiedworkshop.

67
2
Access

As a safety measure (children on
board), never leave the vehicle without taking the key for the Keyless Entry and Starting system, even for a shor t period.Be aware of the risk of theft when thekey for the Keyless Entry and Starting system is in one of the defined zones with the vehicle unlocked.
If one of the doors or the boot is still
open or if the electronic key for theKeyless Entry and Star ting system has been left inside the vehicle, the central locking does not take place.
However, the alarm (if present) will be fully activated after about 45 seconds.


In order to preser ve the battery in the
electronic key and the vehicle's battery,the "Hands-free" functions are put into long-term standby after 21 days withoutuse. To restore these functions, press one of the remote control buttons or start the engine with the electronic key in the reader (see the "Star ting with the Keyless Entry and Starting system"section).

If the vehicle is unlocked by mistakeand with no action on the doors or boot,the vehicle will lock again automaticallyafter about thir ty seconds.
If the alarm had been activated previously, it will not be reactivatedautomatically.


The automatic folding and unfolding of the door mirrors can be deactivatedby a CITROËN dealer or a qualifiedworkshop.
Accumulations (water, dust, grime,salt...) on the inner sur face if the door handle may affect detection.
If cleaning the inner surface of the door handle using a cloth does not restore detection, contact a CITROËN dealer or a qualified workshop.
A sudden splash of water (stream of water, high pressure jet washer, …) may be identified by the system as the desireto open the vehicle.
