2013 Citroen C4 PICASSO engine

160
Driving














Stop & Start
Operation
Going into engine STOP mode
The "ECO"
warning lamp comes onin the instrument panel and the enginegoes into standby automatically:
-with a manual gearbox
, at speeds below
12 mph (20 km/h), when you place the gear lever in neutral, and you release the clutch pedal, - with an electronic gearbox,at speeds
below 5 mph (8 km/h), when you press the
brake pedal or place the gear selector lever in position N ,
- with an automatic gearbox,
with the
vehicle stationary, when you press the brake pedal or place the gear selector lever in position N.If your vehicle is fitted with the system, a timecounter calculates the sum of the periods in STOP mode during a journey. It resets itself to
zero every time the ignition is switched on with
the STA R T/STOP button.
Never refuel with the engine in STOPmode; you must switch off the ignition with the STA R T/STOP button.
For your comfor t, during parkingmanoeuvres, STOP mode is not available for a few seconds after coming out of reverse gear.STOP mode does not affect the functionality of the vehicle, such as for example, braking, power steering...


Special cases: STOP mode not
available
STOP mode is not invoked when:


- the driver's door is open,

- the driver's seat belt is not fastened,

- the vehicle has not exceeded
6 mph(10 km/h) since the last engine start usingthe START/STOP button,

- the electric parking brake is applied or being applied,

- the engine is needed to maintain acomfor table temperature in the passenger compartment,

- demistin
g is active,

- some special conditions (battery charge, engine temperature, braking assistance,ambient temperature...) where the engine isneeded to assure control of a system.

In this case, the "ECO"
warning lampflashes for a few seconds then goesoff.This operation is per fectly normal.
The Stop & Star t system puts the engine temporarily into standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...). The engine restar ts automatically - START mode - as soon as you want to move off. The restart takes place instantly, quickly and silently.
Per fect for urban use, the Stop & Star t system reduces fuel consumption and exhaust emissions as well as the noise level when stationary.

161
4
Driving

Going into engine START mode
The "ECO"warning lamp goes off and the engine starts automatically:
-with a manual gearbox
, when you fullydepress the clutch pedal,
-
with an electronic gearbox
:
●
gear selector lever in position Aor M
,
when you release the brake pedal,
●
or gear selector lever in position Nand the brake pedal released, when you place the gear selector lever inposition A
or M,●
or when you engage reverse gear.
-
with an automatic gearbox:
●
gear selector in position Dor M
, whenyou release the brake pedal,
●
or gear selector in position N
and brakepedal released, when you place the gear selector in position D
or M,●
or when you engage reverse.
START mode is invoked automatically when:
- you open the the driver's door,
- you unfasten the driver's seat belt,
- the speed of the vehicle exceeds 15 mph (25 km/h) with a manual gearbox, 7 mph(11 k m / h) with an electronic gearbox and
2 mph (3 km/h) with an automatic gearbox,
- the electric parking brake is being applied,
- some special conditions (battery charge,engine temperature, braking assistance,
ambient temperature...) where the engine is
needed for control of a system.
Special cases: START invoked automatically

If the system has been deactivatedin STOP mode, the engine restar ts immediately. Deactivation o
f Stop & Star t is done in the
"Driving assistance" menu.
Deactivation
In this case the "ECO"
warning lampflashes for a few seconds, then goes off.
This operation is per fectly normal.
Press this button to deactivate thesystem.
This is con
firmed by the indicator lamp in the button and this symbol.


When driving on a flooded road, it isrecommended that the Stop & Star tfunction be deactivated and that you drive very slowly.

162
Driving

The system is reactivated automaticallyevery time the engine is star ted by the driver.

Reactivation

Press this button again.


Operating fault

Have it checked by a CITROËN dealer or aqualified workshop.
In the event of a fault in STOP mode, the
vehicle may stall.
All of the instrument panel warning lamps come on.
Depending on version, an alert message may
also be displa
yed, asking you to place the gear
selector lever in position Nand put your foot on
the brake pedal.
It is then necessar
y to switch off the ignition
and star t the engine again using the "START/STOP" button.In th
e event of a fault with the system, this warning lamp comes
on continuously.
The system is active again; this is confirmed by the indicator lamp in thebutton going off and illumination of
this symbol.
The Stop & Start system makes use of advanced technology. For any work onthe system go to a qualified workshop with the skills and equipment required, which a CITROËN dealer is able toprovide.

Before doing anything under the bonnet,deactivate the Stop & Start system toavoid any risk of injury resulting fromautomatic operation of STA R T m o d e .


Maintenance

This system requires a 12 V battery with a special specification and technology (reference numbers available from CITROËN dealers).
Fitting a battery not listed by CITROËN introduces the risk of malfunction of
the system.
For charging, use a 12 V charger and do not
reverse the polarity.

174
Driving





Active cruise control
This systems allows, in addition to maintainingyour vehicle's speed at a value that you have defined, the inter-vehicle time you have
selected between your vehicle the the one ahead to be maintained (2 seconds by default,
on activating the function).

Principles of operation

Using a radar with a range of about 100 metres,located at the front of the vehicle, this system
detects a vehicle running in front of your
vehicle.
It automatically adapts the speed of the vehicle
to that of the vehicle in front.
If the vehicle in front is running more slowly,
the system progressively reduces the speed of your vehicle using just engine braking (as if thedriver had pressed the "- " button).
If your vehicle is too close to or approaching tooquickly the vehicle in front, the cruise control
is automatically deactivated. The driver is then
aler ted by an audible signal, accompanied by a message.
If the vehicle in front accelerates or changeslane, the active cruise control progressively
accelerates your vehicle to return to the
programmed speed.
If the driver operates a direction indicator to
the left (left hand drive) or the right (right hand
drive), to over take a slower vehicle, the active cruise control allows your vehicle to temporarily
approach the vehicle in front to assist the
over takin
g manoeuvre, though never exceeding
the programmed speed.

The active cruise control operates byday and at night, in fog or in moderate rainfall.


The system does not act on the brakingsystem, but works only with engine braking.
The regulation range is limited: there willno longer be any adjustment of speed if the difference between the programmed speedsetting and the speed of the vehicle in front becomes too high (18 mph (30 km/h).


The activation of this system deactivates the function of inter-vehicle time.


If the difference between the programmed speed setting and the speed of the vehicle in front is toogreat, the speed cannot be adjusted: the cruise control is automatically
deactivated.

179
4
Driving
not possible, conditions unsuitable" is displayed while reactivation is not possible. When the conditions allow, it is recommended that the function be reactivated by pressing button 2or 3,
which will make the current speed of your vehicle the new cruise speed setting, rather than by pressing button 4(on/pause) which reactivates the cruise control using the old cruise speed setting, which may be very different from the current speed of your vehicle.

SymbolDisplay in theinstrument panelAssociated messageComments
"
SPEED ADJUSTED" Detection of a vehicle that is too close or running at a speed lower than your
vehicle's cruise speed setting.
The system uses engine braking to slow your vehicle and then hold it at the speed of
the vehicle in front so as to maintain the programmed inter-vehicle time.
The regulation range is limited to a maximum difference of 20 mph (30 km/h)between the speed setting and the speed of the vehicle ahead.
"
Cruise control paused". If the system exceeds the limit of speed adjustment possible by the system and in
the absence of any reaction by the driver (operation of the direction indicator, change
of lane, reduction of the speed of the vehicle), the system is automatically paused.
The display of the deactivation message is accompanied by an audible signal.

180
Driving
The active cruise control uses only engine
braking to slow the vehicle. Consequently the
vehicle looses speed slowly, as when releasingthe accelerator pedal.
The system is paused automatically:
- if the vehicle in front slows down to much
or too suddenl
y, and the driver does notbrake,
- if a vehicle comes between your vehicle and the vehicle in front,
- if the system does not slow the vehicle
enough to continue to maintain a safe
distance, for example when descending a
steep hill.
Limits of operation

As the radar's field of view is quite narrow, it is
possible that the system may not detect:
Th
e cruise control does not take account of:


- stationary vehicles,

- vehicles driving in the opposite direction.

- vehicles o
f reduced width, such as
motorcycles, for example,


- vehicles not runnin
g in the middle of the lane,


- ve
hicles entering a corner,


- vehicles changing lane at the last moment.
The re
gulation range is limited to a maximum
difference of 20 mph (30 km/h) between thespeed setting and the speed of the vehicle ahead. Above this, the system goes into pause
if a safe distance is not maintained.
Severe weather conditions (very heavy rain, accumulations of snow in frontof the radar) can interfere with theoperation of the system, resulting inthe display of the message "SYSTEMINACTIVE: Visibility reduced". Thefunction remains unavailable until themessage disappears.

193
4
Driving
Operation
Activating the function
With the engine running:) Select the " Driving assistance
" menu of
the touch screen tablet.
With this menu displa
yed, select one of the
three views:

Deactivating the function
)
Accelerate so as to exceed 18 mph (30 km/h).
or ) Select the "Driving assistance" menu of
the touch screen tablet.
Check the cleanliness of the camera lenses regularly. High pressure jet wash When washing your vehicle, direct the lance at least 30 cm away from the camera.
)
Press this button for access to
the "360 vision" sub-menu.
)Press this button for access tothe " 360 vision
" sub-menu.
)Select "Camera Off".

"Fr
ont camera".
"
360

194
Driving





Park Assist
This system provides active assistance with parking, detecting a parking space then controlling the steering to park in the space. It controls the steering while the driver manages the accelerator, brakes, gears andclutch (manual gearbox). During phases of entry into and exit from a parking space, the system provides visual and audible information
to the driver in order to make the manoeuvres safe. It may be necessary to move for wards and backwards more than once.
During a manoeuvre the steering wheelturns quickly: do not hold the steeringwheel, do not place your hand between
the spokes of the steering wheel and take care with loose and bulky clothing, scarves, handbags... There is a risk of injury.


When Park Assist is activated, itprevents a change to STOP mode of Stop & Start. In STOP mode, activation of Park Assist restarts the engine.


The Park Assist system cannot in anycircumstances replace the care and responsibility of the driver.
The driver must remain in control of their vehicle ensuring that thespace remains clear throughout themanoeuvre. In some circumstances, the sensors may not detect small obstacles located in their blind spots.
The driver can take control at any time bygripping the steering wheel.
The Park Assist s
ystem provides assistance for
the following manoeuvres:


- entr
y into a parallel parking space

- exitin
g from a parallel parking space

- ba
y parking

The Park Assist system takes control of the power steering for a maximumof 4 manoeuvre cycles. The functionis deactivated after these 4 cycles.If you think that your vehicle is notpositioned correctly, you should then take control of the steering to carry outthe manoeuvre.

The Park Assist system cannot workwith the engine off.
