2013 Citroen C4 PICASSO ESP

04
350





Preset a station


Press on " Preset".


Select a radio station or frequency
(refer to the corresponding section).

Select a number in the list to preset thepreviously chosen radio station.
A long press on a number presets (memorises)the station.

Or

A press on this button presets all of the stationsone after the other.


Recall pre-set stations

Press on Media
to display the primary page
then select " Memo ".
RADIO












Activate/ Deactivate RDS
Select " Settings".
Press on Mediato display the primary page
then go to the secondary page.
Select " Radio ".

Activate
/deactivate "RDS options ".
RD
S, if activated, allows you to continue listening to the same
station by automatic retuning to alternative frequencies. However, incertain conditions, coverage of an RDS station may not be assured
throughout the entire country as radio stations do not cover 100 % of
the territory. This explains the loss of reception of the station duringa journey.

379379
Level 1Level 2Level 3Comments
Confi guration


Audio settings


Audio settings
Ambience Choose the sound ambience.
Balance Set the position of the sound in the vehicle using the Arkamys system.
Sound effects Choose the volume or activate the link to vehiclespeed.
Voice Choose the volume for the voice and announcementof street names.
Rin
gtones Choose the telephone ringtone and volume.
Confi rm

Save the settings.
Confi guration


Color


Choice of colour scheme
Confi rm After choosing the colour scheme, save the setting.
Confi guration


Interactive help
Consult the Interactive help.

.
407
Alphabetical index
DAB (Digital Audio Broadcasting) ................351Date (setting)...................................................57Daytime running lamps.................210,279, 281Deactivating ESP..........................................229Deactivating the passenger airbag...............236Deadlocking .......................................63,66,69Defrosting..............................................114, 115Demisting..............................................114, 115Diesel......................................................41, 316
Diesel additive level ......................................320Diesel engine pre-heat warning lamp .............41Digital Audio Broadcasting (DAB)................351Dimensions...........................................331,332Dipped beam..........................99, 202, 279, 280Dipstick....................................................53, 318Directional lighting................................212,213Direction indicators...............222, 279, 282-286Distance alert................................163,182,183Doors...............................................................73Doors back-up control....................................74
Driving positions (storing) ..............................87Driving economically.......................................24Dynamic emergency braking........................145Dynamic stability control (DSC) ........ 43,47,229
Eco-driving.....................................................24Economy mode .............................................298Electronic engine immobiliser.................r71, 140Electronic stability programme (ESC)..........227Emergency boot release.................................78Emergency call............................223, 335,336
Gearbox, automatic..............154, 160,297,322Gearbox, electronic...............150, 160,297,322Gearbox, manual ..........................149, 160,322Gear shift indicator......................................................r159Gear lever, manualgearbox.......................................................149Gear selector........................................r150,154Glove box..............................................118, 119Guidance.......................................................358Guide-me-home....................................206, 207
E
F
Filling with fuel ..............................313,315,316Fitting a wheel ...............................................276Fitting roof bars .............................................304Fittings, rear..................................................r125Flashing indicators........................................222Foglamps, front .............................204,212, 282Foglamps, rear..............................................r204Folding the rear seats..................92, 94,96, 97Fragrance car tridge......................................116Frequency (radio) .................................349, 350Front seats..........................................84,86, 87Fuel...............................................................316Fuel consumption............................................24Fuel filler cap.................................................313Fuel filler flap.........................................313,315Fuel gauge ........................................33, 34,313Fuel tank................................................313,315Fusebox, dashboard.....................................290Fuses .............................................................288
D
Emergency warning lamps ..................222, 223Energy economy mode.................................298Engine, Diesel................312,316, 317, 325-327Engine, petrol................................311, 316,323Engine compartment.............................311, 312Engine compartment fusebox .......................293Engine oil......................................................318Engine oil level indicator.........................r53,318Engines.........................................323, 325-327Environment......24, 70, 105, 115, 224, 297, 320ESC/ASR .......................................................227
G
Halogen headlamps......................................279Hands-free kit.......................................394,395Hazard warning lamps .........................222, 223Headlamp adjustment...................................211Headlamps, directional.........................213, 279Headlamp wash ............................................216Head restraints, front......................................88Head restraints, rear.......................................r93Heated seats...................................................90Heating..........................................106, 107, 109Height and reach adjustment, steering wheel............................................ 103Hill start assist...............................................148Hooks............................................................130
H
