PERIODIC MAINTENANCE AND MINOR REPAIR
To store the battery
1. If the vehicle will not be used for
more than one month, remove the
battery, fully charge it, and then
place it in a cool, dry place.
2. If the battery will be stored for
more than two months, check it at
least once a month and fully
charge it if necessary.
3. Fully charge the battery before in-
stallation.
4. After installation, make sure that
the battery leads are properly
connected to the battery termi-
nals.ECA10630CAUTION:
●Always keep the battery
charged. Storing a discharged
battery can cause permanent
battery damage.
●To charge a sealed-type (MF)
battery, a special (constant-
voltage) battery charger is re-
quired. Using a conventional
battery charger will damage
the battery. If you do not have
access to a sealed-type (MF)
battery charger, have a Yamaha
dealer charge your battery.
EAUB1260
Replacing the fuses
1. Main fuse
2. Reserve fuse
6-31

PERIODIC MAINTENANCE AND MINOR REPAIR
1. Parking lighting fuse
2. Signaling system fuse
3. Headlight fuse
4. Ignition fuse
5. Electronic fuel injection fuse
6. Radiator fan fuse
7. Backup fuse
8. Reserve fuses
The main fuse is located under the fu-
el tank. (See page 6-31.)
The fuse box which contains the fuses
for the individual circuits is located un-
der the rider seat. (See page 3-15.)
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off
the electrical circuit in question.
2. Remove the blown fuse, and then
install a new fuse of the specified
amperage.
ECA10640CAUTION:
Do not use a fuse of a higher am-
perage rating than recommended
to avoid causing extensive damage
to the electrical system and possi-
bly a fire.
3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
6-32
1
2
3
4
5
6
7
8
9
10
Specified fuses:
Main fuse:
30 A
Fuse box:
Parking lighting fuse:
10 A
Signaling system fuse:
10 A
Headlight fuse:
20 A
Ignition fuse:
10 A
Electronic fuel injection fuse:
10 A
Radiator fan fuse:
7.5 A
Fuel injection system fuse:
10 A
Backup fuse (for odometer,
clock and immobilizer):
10 A

1
2
3
4
5
6
7
8
9
10
PERIODIC MAINTENANCE AND MINOR REPAIR
EAUB1360
Replacing the headlight bulb
1. Headlight coupler
2. Headlight bulb cover
1. Headlight bulb holder
2. Headlight bulb
This model is equipped with a quartz
bulb headlight. If the headlight bulb
burns out, replace it as follows.
1. Turn the handlebar to the left side
to access the headlight coupler.
2. Disconnect the headlight coupler,
and then remove the bulb cover.
3. Unhook the headlight bulb holder,
and then remove the defective
bulb.
EWA10790
WARNING0
Headlight bulbs get very hot. There-
fore, keep flammable products
away from a lit headlight bulb, and
do not touch the bulb until it has
cooled down.
4. Place a new headlight bulb into
position, and then secure it with
the bulb holder.
1. Do not touch this areaECA10650CAUTION:
Take care not to damage the fol-
lowing parts:
●Headlight bulb
•Do not touch the glass part
of the headlight bulb to keep
it free from oil, otherwise the
transparency of the glass,
the luminosity of the bulb,
and the bulb life will be ad-
versely affected. Thoroughly
clean off any dirt and finger-
prints on the headlight bulb
using a cloth moistened with
alcohol or thinner.
6-33

PERIODIC MAINTENANCE AND MINOR REPAIR
●Headlight lens
•Do not affix any type of tinted
film or stickers to the head-
light lens.
•Do not use a headlight bulb
of a wattage higher than
specified.
5. Install the headlight bulb cover,
and then connect the coupler.
6. Have a Yamaha dealer adjust the
headlight beam if necessary.
EAUB1380
Replacing an auxiliary
light bulb
1. Auxiliary light socket
2. Auxiliary light bulb
If the auxiliary light bulb burns out, re-
place it as follows.
1. Turn the handlebar to the right or
left side to access the auxiliary
light socket.
2. Remove the auxiliary light socket
(together with the bulb) by pulling it.
3. Remove the defective bulb by
pulling it out.
4. Insert a new bulb into the socket.
5. Install the auxiliary light socket
(together with the bulb) by push-
ing it in.
EAUB1370
Replacing the tail/brake
light bulb
1. Tail/brake light bulb cover
2. Cover bolts
1. Tail/brake light socket
2. Tail/brake light bulb
6-34
1
2
3
4
5
6
7
8
9
10

1
2
3
4
5
6
7
8
9
10
PERIODIC MAINTENANCE AND MINOR REPAIR
1. Remove the tail/brake light bulb
cover by removing the bolts.
2. Remove the socket (together with
the bulb) by turning it counter-
clockwise.
3. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
4. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
5. Install the socket (together with
the bulb) by turning it clockwise.
6. Place the tail/brake light bulb
cover in its original position, insert
the bolts and then tighten them to
the specified torque.EAU24202
Replacing a turn signal
light bulb
1. Screw
2. Turn signal light lens
3. Turn signal light bulb
1. Remove the turn signal light lens
by removing the screw.
2. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw.
ECA11190CAUTION:
Do not overtighten the screw, oth-
erwise the lens may break.
6-35
Tightening torque:
Tail/brake light bulb cover bolt:
10 Nm (1.0 m·kgf, 7.2 ft·lbf)

PERIODIC MAINTENANCE AND MINOR REPAIR
EAUB1410
Replacing the license plate
light bulb
1. Reinforcement plate
2. Bulb socket
3. License plate light bulb
1. Remove the reinforcement plate
by removing the bolts and nuts.
2. Remove the license plate light
bulb socket by pulling it out.
NOTE:
When removing the license plate light
bulb socket, be careful not to pull too
hard.
EAU24350
Supporting the motorcycle
Since this model is not equipped with
a centerstand, follow these precau-
tions when removing the front and rear
wheel or performing other mainte-
nance requiring the motorcycle to
stand upright. Check that the motorcy-
cle is in a stable and level position be-
fore starting any maintenance. A
strong wooden box can be placed un-
der the engine for added stability.
To service the front wheel
1. Stabilize the rear of the motorcy-
cle by using a motorcycle stand
or, if an additional motorcycle
stand is not available, by placing
a jack under the frame in front of
the rear wheel.
2. Raise the front wheel off the
ground by using a motorcycle
stand.
6-36
1
2
3
4
5
6
7
8
9
10
3. Remove the defective bulb by
pulling it out of the socket.
4. Insert a new bulb into the socket.
5. Install the bulb socket by pushing
it in.
6. Install the reinforcement plate in
the original position, and then
tighten bolts and nuts to the spec-
ified torque.
Tightening torque:
Reinforcement plate nut:
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Reinforcement plate bolt (centre):
10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Reinforcement plate bolt (upper):
10 Nm (1.0 m·kgf, 7.2 ft·lbf)

1
2
3
4
5
6
7
8
9
10
PERIODIC MAINTENANCE AND MINOR REPAIR
6-37
To service the rear wheel
Raise the rear wheel off the ground by
using a motorcycle stand or, if a mo-
torcycle stand is not available, by plac-
ing a jack either under each side of the
frame in front of the rear wheel or un-
der each side of the swingarm.EAU24360
Front wheelEAU34390
To remove the front wheel
EWA10820
WARNING0
●It is advisable to have a Yama-
ha dealer service the wheel.
●Securely support the motorcy-
cle so that there is no danger of
it falling over.
1. Front wheel axle pinch bolt
2. Wheel axle bolt
3. Brake caliper bolts
4. Brake hose holder bolt
1. Lift the front wheel off the ground
according to the procedure on
page 6-36.
2. Loosen the front wheel axle pinch
bolt, then the wheel axle and the
brake caliper bolts.
3. Remove the brake hose holder on
each side by removing the bolts.
4. Remove the brake caliper on
each side by removing the bolts.
ECA11050CAUTION:
Do not apply the brake after the
brake calipers have been removed,
otherwise the brake pads will be
forced shut.
5. Pull the wheel axle out, and then
remove the wheel.
EAU24860
To install the front wheel
1. Lift the wheel up between the fork
legs.
2. Insert the wheel axle.
3. Lower the front wheel so that it is
on the ground.

PERIODIC MAINTENANCE AND MINOR REPAIR
6-38
1
2
3
4
5
6
7
8
9
10
EAU25080
Rear wheelEAU25311
To remove the rear wheelEWA10820
WARNING0
●It is advisable to have a Yama-
ha dealer service the wheel.
●Securely support the motorcy-
cle so that there is no danger of
it falling over.
1. Wheel axle nut
2. Drive chain slack adjusting bolt
3. Locknut
4. Drive chain
1. Wheel axle
2. Brake caliper bracket
1. Loosen the axle nut.
2. Lift the rear wheel off the ground
according to the procedure on
page 6-36.
3. Remove the axle nut.
4. Loosen the locknut on each side
of the swingarm.
5. Turn the drive chain slack adjust-
ing bolts fully in direction (a) and
push the wheel forward.
6. Remove the drive chain from the
rear sprocket.
4. Install the brake calipers by in-
stalling the bolts.
NOTE:
Make sure that there is enough space
between the brake pads before in-
stalling the brake calipers onto the
brake discs.
5. Install the brake hose holders by
installing the bolts.
6. Tighten the wheel axle, the front
wheel axle pinch bolt and the
brake caliper bolts to the speci-
fied torques.
Tightening torques:
Wheel axle:
72 Nm (7.2 m·kgf, 52 ft·lbf)
Front wheel axle pinch bolt:
14 Nm (1.4 m·kgf, 10 ft·lbf)
Brake caliper bolt:
40 Nm (4.0 m·kgf, 29 ft·lbf)
7. Push down hard on the handlebar
several times to check for proper
fork operation.
