2012 YAMAHA MT-03 Owners Manual

OWNER’S MANUAL
2BF-F8199-E0
MT-03

EAU26942
General manager of quality assurance div. Date of issue: 1 Aug. 2002 Place of issue: Shizuoka, Japan
DECLARATION of CONFORMITY
Company: YAMAHA MOTOR ELECTRONICS CO., LTD. We
Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan
Kind of equipment: IMMOBILIZER Hereby declare that the product:
Type-designation: 5SL-00
is in compliance with following norm(s) or documents:
R&TTE Directive(1999/5/EC)
EN300 330-2 v1.3.1(2006-01), EN300 330-2 v1.5.1(2010-02)
EN60950-1:2006/A11:2009
Two or Three-Wheel Motor Vehicles Directive(97/24/EC: Chapter 8, EMC)
1
2
3
4Version up the norm of EN60950 to EN60950-1
To change company name
version up of the following norm:


27 Feb. 2006
1 Mar. 2007
8 Jul. 2010 Revision record
No. Contents
To change contact person and integrate type-designation.Date
9 Jun. 2005

INTRODUCTION
EAU10100
Welcome to the Yamaha world of motorcycling!
As the owner of the MT-03, you are benefiting from Yamaha’s vast experience and newest technology regarding the de-
sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MT-03. The owner’s manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself
and others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have
any further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!

IMPORTANT MANUAL INFORMATION
Particularly important information is distinguished in this manual by the following notations:
WARNING0
NOTE:
CAUTION:
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS
INVOLVED!
Failure to follow WARNING instructions could result in severe injury or death to the
motorcycle operator, a bystander, or a person inspecting or repairing the motorcycle.
A CAUTION indicates special precautions that must be taken to avoid damage to
the motorcycle.
A NOTE provides key information to make procedures easier or clearer.
NOTE:
●This manual should be considered a permanent part of this motorcycle and should remain with it even if the motor-
cycle is subsequently sold.
●Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the
most current product information available at the time of printing, there may be minor discrepancies between your
motorcycle and this manual. If you have any questions concerning this manual, please consult your Yamaha dealer..
EWA10030
WARNING0
PLEASE READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING THIS MOTORCYCLE.
* Product and specifications are subject to change without notice.
EAU10151

IMPORTANT MANUAL INFORMATION
EAUB1011
MT-03
OWNER'S MANUAL
2012 by MBK industrie
1
stedition, March 2012
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
MBK industrie
is expressly prohibited.
Printed in France

TABLE OF CONTENTS
SAFETY INFORMATION.....................1-1
Safe riding .........................................1-1
Protective apparel.............................1-2
Modifications .....................................1-2
Loading and accessories ..................1-2
Gasoline and exhaust gas ................1-4
DESCRIPTION.....................................2-1
Left view ............................................2-1
Right view .........................................2-2
Controls and instruments ..................2-3
INSTRUMENT AND CONTROL
FUNCTIONS........................................3-1
Immobilizer system...........................3-1
Main switch/steering lock ..................3-2
Indicator and warning lights ..............3-3
Multi-function meter unit ...................3-5
Tachometer .......................................3-6
Odometer, tripmeter modes ..............3-6
Clock mode .......................................3-7
Self-diagnosis devices......................3-7
Indicator lights brightness
control mode..............................3-8
Anti-theft alarm (optional) .................3-8
Handlebar switches...........................3-9
Clutch lever .....................................3-10
Shift pedal.......................................3-10
Brake lever ......................................3-11Brake pedal.....................................3-11
Fuel tank cap...................................3-11
Fuel .................................................3-12
Fuel tank breather/overflow hose ...3-13
Catalytic converter..........................3-13
Seats ...............................................3-14
Adjusting the shock absorber
assembly..................................3-16
Sidestand........................................3-18
Ignition circuit cut-off system ..........3-19
PRE-OPERATION CHECKS...............4-1
Pre-operation check list ....................4-2
OPERATION AND IMPORTANT
RIDING POINTS..................................5-1
Starting the engine............................5-1
Shifting ..............................................5-2
Tips for reducing fuel consumption ...5-3
Engine break-in .................................5-3
Parking..............................................5-4
PERIODIC MAINTENANCE
AND MINOR REPAIR.........................6-1
Owner’s tool kit.................................6-1
Periodic maintenance and
lubrication chart..........................6-2
Removing and installing panels ........6-6
Checking the spark plug ...................6-6Engine oil and oil filter element.........6-8
Coolant............................................6-12
Replacing the air filter element
and cleaning the check hoses ...6-13
Adjusting the engine idling speed ...6-14
Checking the throttle cable
free play...................................6-15
Valve clearance...............................6-15
Tires ................................................6-16
Cast wheels....................................6-19
Adjusting the clutch lever
free play...................................6-19
Checking the front and rear
brake pads...............................6-20
Checking the brake fluid level .........6-21
Changing the brake fluid .................6-22
Drive chain slack .............................6-23
Cleaning and lubricating the
drive chain ................................6-24
Checking and lubricating the
cables .......................................6-25
Checking and lubricating the
throttle grip and cable ..............6-25
Checking and lubricating the
brake and clutch levers ............6-26
Lubricating the brake pedal............6-26
Checking and lubricating the
sidestand..................................6-27
Lubricating the side suspension .....6-27

TABLE OF CONTENTS
Checking the front fork....................6-27
Checking the steering.....................6-28
Checking the wheel bearings..........6-29
Battery .............................................6-29
Replacing the fuses ........................6-31
Replacing the headlight bulb ..........6-33
Replacing an auxiliary light bulb .....6-34
Replacing the tail/brake light bulb ...6-34
Replacing a turn signal light bulb....6-35
Replacing the license plate
light bulb...................................6-36
Supporting the motorcycle ..............6-36
Front wheel.....................................6-37
Rear wheel......................................6-38
Troubleshooting..............................6-39
Troubleshooting charts....................6-40
MOTORCYCLE CARE
AND STORAGE...................................7-1
Care ..................................................7-1
Storage.............................................7-3
SPECIFICATIONS ..............................8-1
CONSUMER INFORMATION..............9-1
Identification numbers.......................9-1

1-1
1
2
3
4
5
6
7
8
9
10
SAFETY INFORMATION
EAU10281
MOTORCYCLES ARE SINGLE
TRACK VEHICLES. THEIR SAFE
USE AND OPERATION ARE DEPEN-
DENT UPON THE USE OF PROPER
RIDING TECHNIQUES AS WELL AS
THE EXPERTISE OF THE OPERA-
TOR. EVERY OPERATOR SHOULD
KNOW THE FOLLOWING REQUIRE-
MENTS BEFORE RIDING THIS MO-
TORCYCLE.
HE OR SHE SHOULD:
●OBTAIN THOROUGH INSTRUC-
TIONS FROM A COMPETENT
SOURCE ON ALL ASPECTS OF
MOTORCYCLE OPERATION.
●OBSERVE THE WARNINGS
AND MAINTENANCE REQUIRE-
MENTS IN THE OWNER'S MAN-
UAL.
●OBTAIN QUALIFIED TRAINING
IN SAFE AND PROPER RIDING
TECHNIQUES.
●OBTAIN PROFESSIONAL TECH-
NICAL SERVICE AS INDICATED
BY THE OWNER'S MANUAL
AND/OR WHEN MADE NECES-
SARY BY MECHANICAL CONDI-
TIONS.Safe riding
●Always make pre-operation
checks. Careful checks may help
prevent an accident.
●This motorcycle is designed to
carry the operator and a passen-
ger.
●The failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been
caused by an automobile driver
who did not see the motorcycle.
Making yourself conspicuous ap-
pears to be very effective in re-
ducing the chance of this type of
accident.
Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for motorcycle accidents
to occur.• Ride where other motorists can
see you. Avoid riding in another
motorist's blind spot.
●Many accidents involve inexperi-
enced operators. In fact, many
operators who have been in-
volved in accidents do not even
have a current motorcycle li-
cense.
• Make sure that you are quali-
fied and that you only lend your
motorcycle to other qualified
operators.
• Know your skills and limits.
Staying within your limits may
help you to avoid an accident.
• We recommend that you prac-
tice riding your motorcycle
where there is no traffic until
you have become thoroughly
familiar with the motorcycle and
all of its controls.
●Many accidents have been
caused by error of the motorcycle
operator. A typical error made by
the operator is veering wide on a
turn due to EXCESSIVE SPEED
or undercornering (insufficient
lean angle for the speed).
