2012 VOLKSWAGEN JETTA SPORTWAGEN Owners Manual

Windshield wiper and washer

Lights
up Possible cause Proper response
Y Not enough windshield washer fluid for
the front and rear windshield washers.
Refill windshield washer reservoir at the next
opportunity .

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 90 Operating the front windshield wipers.

Fig. 91 Operating the rear wiper.

Move the lever to the desired position ⇒:
(B) z
Intermittent wiping for the windshield.
Adjust the interval settings with switch ⇒ fig. 90 (1).
(C) LOW Slow wiper speed.
(D) HIGH Fast wiper speed.
(E) x One-tap wiping – brief wiping. Hold the lever pressed down longer to wipe more often.
(F) W Pull the lever toward the steering wheel to activate the front windshield washers, then
release.
(G) Z Intermittent wiping for the rear window. The wiper wipes about every 6 seconds.
(H) \ Press the lever forward as far as it will go to activate the rear window washers, then
release.

NOTICE
To help prevent damage to the wiper blades and the wiper motor when it is cold outside,
always make sure that blades are not frozen to the windshield before operating the wipers.
Using the service position can be helpful in cold weather so the wipers do not freeze to the
windshield .
x If the ignition is switched off while the wipers are running, the wipers will continue at the
same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other
objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen
recommends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can
be scratched.
On some vehicles, the windshield wipers work only if the ignition is switched on and the engine
hood is closed. The windshield wipers turn off automatically when the engine hood is opened. The
rear window wiper turns off when the rear hatch is opened.
The intermittent wiping for the front windshield depends on the driving speed. The higher the
speed, the faster the wipers move.
If the front wipers are on, the rear wiper is switched on automatically when backing up.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends
using a deicing spray.

Windshield wiper functions

Carefully fold the wiper arms back onto the windshield before driving! Switch the ignition on and press
the windshield wiper lever down briefly ⇒ fig. 90 (E). The wiper arms move back to their original
position.
Lifting the wiper blades and tilting them away from the windshield
x Put the wiper arms in service position ⇒ .
x Do not handle the wiper blades, handle the wiper arms only at the attachment above the wiper
blades.
NOTICE
x To help prevent damage to the engine hood and the windshield wiper arms, lift the wiper
arms away from the windshield only when they are in the service position.
x Always carefully fold the windshield wiper arms down against the windshield before driving
the vehicle.
Checking and refilling windshield washer fluid

Fig. 93 In the engine compartment: Cap of the windshield washer fluid reservoir.

x All-season Windscreen ClearG 052 164 A2 or equivalent. Mixing ratio in winter to 0 °F (-18 °C)
about 1:2 (1 part concentrate to 2 parts water), otherwise, mixing ratio 1:4 in the windshield washer
reservoir.
Filling capacity
The windshield washer fluid reservoir holds 3.1–4.2 quarts (about 3–4 liters).
WARNING
Never mix antifreeze or similar additives into the windshield washer reservoir. This could
produce an oily film on the windshield, which would considerably reduce visibility.
x Use clear water with a cleaning solution recommended by Volkswagen.
x If necessary, blend with a suitable windshield washer fluid antifreeze agent.
NOTICE
x Never mix cleaning solutions recommended by Volkswagen with other cleaning agents. If
you do, this could cause sediments or other by-products that can clog the windshield wiper
nozzles.
x When refilling, do not confuse one type of operating liquid with another! Otherwise serious
malfunctions and engine damage can occur!

Mirrors

For example, visibility through the rear window could be impaired if there is a sunshade on the rear
window or clothing on the luggage compartment cover, or if the rear window is covered with ice, snow,
or dirt.
Manually adjustable inside mirror
x Home position: Lever on the bottom edge of the mirror points forward.
x To adjust to non-glare visibility, move the lever so that it points backward ⇒ fig. 94.
Outside mirrors

Fig. 95 In the driver door: Adjusting knob for the outside mirrors.
