2012 Lexus LFA lexus LFA 2012 Owner's Manual / LEXUS 2012 LFA OWNERS MANUAL (OM77006U)

143
2-2. Instrument cluster
2
When driving
■Operation
Press up and down on the control pad.
Start (“ Start”)/stop (“ Stop”)
measurement
Press: Mark off one lap
(“ Lap”)
Press and hold: Reset
(“ Reset”)
Resetting erases all measurement
results.
■Measurement method
Select “Lap Timer” and press right
on the control pad.
STEP1

144
2-2. Instrument cluster
Select “Lap Timer” and press right
on the control pad.
The “Lap Timer” function will be
turned “ON” and the trip informa-
tion/odometer will be changed to
stopwatch mode.
Select “Lap Times” and press right
on the control pad.
Lap time list, “Fastest Lap”, and
“Total” will be displayed. “ Start”
and “ Reset” will be shown on the
stopwatch display.
STEP2
STEP3

145
2-2. Instrument cluster
2
When driving
Press up on the control pad
(“ Start”) to begin measurement.●To measure lap times:
Press down on the control pad
(“ Lap”) during measurement
to mark off a lap. The lap time
will be added to the lap time list.
(The most recent lap will be dis-
played at the top of the lap time
list.)
The fastest lap time will also be
displayed as “Fastest Lap”.
● To stop measurement:
Press up on the control pad
(“ Stop”) during measurement.
When “ Stop” is selected, the
stopwatch time is not recorded
as a lap time.
When “ Start” is selected,
measurement resumes from the
stopwatch time shown.
STEP4

146
2-2. Instrument cluster
■Displaying measurement results
Measurement results can be displayed when the “Lap Timer” function
is “OFF”. Results can also be disp layed when the “Lap Timer” function
is turned “ON” but not recording measurements.
Select “Past Times” and press right
on the control pad.
Lap time list, “Fastest Lap”, and
“Total” will be displayed.
Move through the lap time list by
pressing up and down on the con-
trol pad.
The lap time list displays the 20
most recent lap times.

147
2-2. Instrument cluster
2
When driving
“Brightness” (brightness control)The brightness of the meter, instrument panel lights and down light (while
tail lights are on) can be adjusted. Select “Brightness” and press right
on the control pad.
Adjust the brightness by pressing
up and down on the control pad.
STEP1
STEP2

148
2-2. Instrument cluster
“Settings”Settings for the meter display can be changed. (Settings cannot be
changed while the vehicle is in motion.) Select “Settings” and press right
on the control pad.
Select the desired setting and
press right on the control pad.
“Needle” (
P. 1 4 9 )
“Rev Peak” (
P. 150)
“Clock” (
P. 151)
“Shortcut” (
P. 153)
“Units” (
P. 1 5 4 )
“Temp” (
P. 1 5 4 )
“Language” (
P. 155)
STEP1
STEP2

149
2-2. Instrument cluster
2
When driving
■“Needle”
Each time right on the control pad
is pressed, the color of the
tachometer needle will change as
follows:

150
2-2. Instrument cluster
■“Rev Peak”
When the engine speed reaches
or exceeds 6000 rpm, an afterim-
age of the tachometer needle will
be displayed at the highest engine
speed for approximately 0.5 sec-
onds.
Set up procedure Press the right side of the control
pad to turn this function “ON” or
“OFF”
The afterimage color of the
tachometer needle changes as fol-
lows:
Tachometer
needle colorAfterimage color
Blue Red Red Blue
White Blue
