2012 Lexus IS220d Navigation manual

47
2
BASIC FUNCTION
ISF_IS_ISC_Navi_EE
2. SETUP
1. GENERAL SETTINGS
1Press the “SETUP” button.
2Touch “General”.
3Touch the items to be set.
4Touch “OK”.
On this screen, the following functions
can be performed:
Settings are available for language
selection, operation sounds, etc.SCREENS FOR GENERAL
SETTINGS
No
.Function
Touch to change the time zone and
select “On” or “Off” for daylight
saving time. (See “SYSTEM
TIME SETTINGS” on page 48.)
Touch to change the language.
(See “SELECTING A LAN-
GUAGE” on page 49.)

48
2. SETUP
ISF_IS_ISC_Navi_EE
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “System time”.
4Touch the items to be set.
On this screen, the following functions
can be performed:
5Touch “OK”.
Touch to change the voice recog-
nition language. (See “SELECT-
ING A VOICE RECOGNITION
LANGUAGE” on page 50.)
Touch to change the home screen
settings. (See “HOME SCREEN
SETTINGS” on page 50.)
Touch to customize the opening
image. (See “CHANGING THE
OPENING IMAGE” on page 51.)
Touch to customize the screen off
image. (See “CHANGING THE
SCREEN OFF IMAGE” on page
52.)
Touch to turn the sound beeps
“On” or “Off”.
Touch to set automatic screen
changes “On” or “Off”. If “On” is
selected, the audio/air condition-
ing control screen will automati-
cally change back to the
previously displayed screen (for
example the map screen) if no op-
erations are performed for 20 sec-
onds.
Touch to change the screen button
colour. (See “SELECTING A
BUTTON COLOUR” on page
54.)
Touch to change the distance unit.
(See “UNIT OF MEASURE-
MENT” on page 54.)
Touch to delete personal data.
(See “DELETING PERSONAL
DATA” on page 55.)
Touch to update program ver-
sions. For details, contact your
Lexus dealer.
No
.FunctionSYSTEM TIME SETTINGS
Used for changing time zones and
the on/off settings of daylight saving
time.
No
.Function
Touch to change the time zone.
(See “TIME ZONE” on page 49.)
Touch to select “On” or “Off” for
daylight saving time.

49
2. SETUP
2
BASIC FUNCTION
ISF_IS_ISC_Navi_EE
TIME ZONE
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “System time” on the “Gener-
al settings” screen.
4Touch “Time zone”.
5Touch the desired time zone.
If “Other” is touched, the zone can be
adjusted manually. Touch “+” or “-” to
adjust the time zone and then touch
“OK”.
6Touch “OK”.
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Language”.
4Touch the desired screen button.
The previous screen will be displayed.
5Touch “OK”.
A time zone can be selected and
GMT can be set.
SELECTING A LANGUAGE
The language can be changed.

50
2. SETUP
ISF_IS_ISC_Navi_EE
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Voice recognition lang.”.
4Touch the desired screen button.
A confirmation message will be dis-
played. Touch “Yes” to complete the
settings and return to the “General set-
tings” screen.
5Touch “OK”.
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Home screen”.
The “Home screen” can also be
accessed by pressing the button.
4Touch “Climate”.
5Touch “OK”.
SELECTING A VOICE
RECOGNITION LANGUAGE
The voice recognition language can
be changed.HOME SCREEN SETTINGS
The displaying of the climate screen
can be set on or off.

51
2. SETUP
2
BASIC FUNCTION
ISF_IS_ISC_Navi_EE
TRANSFERRING DATA
1Open the cover and connect a USB
memory.
Turn on the power of the USB memory
if it is not turned on.
2Close the console box.
3Press the “SETUP” button.
4Touch “General” on the “Setup”
screen.
5Touch “Change opening image”.
6Touch “Transfer”.
7Touch “Yes”.
CHANGING THE OPENING
When the “ENGINE START STOP”
switch is in ACCESSORY or IGNI-
TION ON mode, the initial screen
will be displayed.
An image can be copied from a USB
memory and used as the opening im-
age. (For information regarding the
opening image, see “INITIAL
SCREEN” on page 28.)
INFORMATION
When saving the images to a USB,
name the folder that the opening
image is saved to “StartupImage” and
name the folder that the screen off
image is saved to “DisplayOffImage”.
If these folder names are not used, the
navigation system cannot download
the images. (The folder names are
case sensitive.)
The images file extension is JPG or
JPEG.
The images file name, including the
file extension, can be up to 32 charac-
ters.
Image files of 10 MB or less can be
saved.
Up to 3 images can be downloaded.

52
2. SETUP
ISF_IS_ISC_Navi_EE
SETTING THE OPENING IM-
AGE
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Change opening image” on
the “General settings” screen.
4Touch the desired image.
5Touch “OK”.
DELETING TRANSFERRED IM-
AGES
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Change opening image” on
the “General settings” screen.
4Touch “Delete all”.
5Touch “Yes”.
TRANSFERRING DATA
1Open the cover and connect a USB
memory.
Turn on the power of the USB memory
if it is not turned on.
2Close the console box.
3Press the “SETUP” button.
4Touch “General” on the “Setup”
screen.
5Touch “Change screen off image”.
CHANGING THE SCREEN
OFF IMAGE
Touch “Screen off” to turn off the
screen. An image can be copied from
a USB memory and can be set to dis-
play when “Screen off” is touched.
(For more information on “Screen
off”, see “SCREEN ADJUST-
MENT” on page 35.)

53
2. SETUP
2
BASIC FUNCTION
ISF_IS_ISC_Navi_EE
6Touch “Transfer”.
7Touch “Yes”.
SETTING THE SCREEN OFF IM-
AGE
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Change screen off image”
on the “General settings” screen.
4Touch the desired image.
5Touch “OK”.
DELETING TRANSFERRED IM-
AGES
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Change screen off image”
on the “General settings” screen.
4Touch “Delete all”.
5Touch “Yes”.

54
2. SETUP
ISF_IS_ISC_Navi_EE
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Button colour”.
4Touch the desired screen button co-
lour.
The previous screen will be displayed.
5Touch “OK”.
1Press the “SETUP” button.
2Touch “General” on the “Setup”
screen.
3Touch “Unit of measurement”.
4Touch “km” or “mile”.
5Touch “OK”.
SELECTING A BUTTON
COLOUR
The colour of the screen buttons can
be changed.UNIT OF MEASUREMENT
Distance unit can be changed.
This function is available only in
English. To switch language, see
“SELECTING A LANGUAGE” on
page 49.
