2012 Lexus IS220d Navigation manual

25
3. QUICK REFERENCE
1
QUICK GUIDE
ISF_IS_ISC_Navi_EE
No.NameFunctionPage
“General”
Touch to change the selected language, oper-
ation sound, automatic screen change set-
tings, etc.
47
“Voice”Touch to set the voice guidance settings.56
“Navigation”Touch to access the page which enables the
setting of the average speed, displayed screen
contents, POI categories, etc.124
“Display”Touch to adjust the contrast and brightness of
the screens, turn the display off, etc.35
“Vehicle”Touch to set vehicle information such as
maintenance information.129
“Info”Touch to set traffic information.295
“Audio”Touch to set sound, radio and iPod settings.262
“Bluetooth*”Touch to set Bluetooth® phones and
Bluetooth® audio devices.187
“Telephone”Touch to set the telephone sound, phonebook,
message settings, etc.165
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

26
3. QUICK REFERENCE
ISF_IS_ISC_Navi_EE

2
27
1
2
3
4
5
6
7
8
9
10
ISF_IS_ISC_Navi_EE1. INITIAL SCREEN ........................... 28
2. TOUCH SCREEN OPERATION .... 29
3. INPUTTING LETTERS AND
NUMBERS/LIST SCREEN
OPERATION ................................. 30
4. SCREEN ADJUSTMENT................ 35
SCREEN SETTING ADJUSTMENT ...... 35
5. MAP SCREEN OPERATION ......... 37
CURRENT POSITION DISPLAY........... 37
SCREEN SCROLL OPERATION ........... 37
SWITCHING MAP
CONFIGURATIONS............................. 42
MAP SCALE ............................................ 44
MAP ORIENTATION AND
3D MAP MODE .................................... 45
STANDARD MAP ICONS ...................... 46
1. GENERAL SETTINGS.................... 47
SCREENS FOR GENERAL SETTINGS. 47
2. VOICE SETTINGS .......................... 56
SCREEN FOR VOICE SETTINGS ......... 56
1BASIC INFORMATION
BEFORE OPERATION
2SETUP
BASIC FUNCTION
For vehicles sold outside Europe, some of the functions cannot be operated while

28
ISF_IS_ISC_Navi_EE
1. BASIC INFORMATION BEFORE OPERATION
1. INITIAL SCREEN
1When the “ENGINE START
STOP” switch is in ACCESSORY
or IGNITION ON mode, the initial
screen will be displayed and the sys-
tem will begin operating.
After a few seconds, the “CAUTION”
screen will be displayed.
After about 5 seconds, the “CAU-
TION” screen automatically switches
to the home screen.
• Touch “Show map” or press the
button to display the home screen.
Images shown on the initial screen
can be changed to suit individual
preferences. (See page 51.)
CAUTION
When the vehicle is stopped with the
engine running, always apply the
parking brake for safety.
MAINTENANCE
INFORMATION
This system reminds users when to
replace certain parts or components
and shows dealer information (if reg-
istered) on the screen.
When the vehicle reaches a previous-
ly set driving distance or date speci-
fied for a scheduled maintenance
check, the “Information” screen will
be displayed when the navigation
system begins operating.
This screen goes off if the screen is
not operated for several seconds.
To prevent this screen from being dis-
played again, touch “Don’t show this
info again.”.
To register maintenance information,
see “MAINTENANCE” on page 129.

29
1. BASIC INFORMATION BEFORE OPERATION
2
BASIC FUNCTION
ISF_IS_ISC_Navi_EE
2. TOUCH SCREEN OPERATION
This system is operated mainly by
the buttons on the screen. (Referred
to as screen buttons in this manual.)
When a screen buttons is touched, a
beep sounds. (To set the beep sound,
see page 47.)
NOTICE
To prevent damaging the screen,
lightly touch the screen buttons with
your finger.
Do not use objects other than your
finger to touch the screen.
Wipe off fingerprints using a glass
cleaning cloth. Do not use chemical
cleaners to clean the screen, as they
may damage the touch screen.
INFORMATION
If the system does not respond to
touching a screen button, move your
finger away from the screen and then
touch it again.
Dimmed screen buttons cannot be
operated.
The displayed image may become
darker and moving images may be
slightly distorted when the screen is
cold.
In extremely cold conditions, the map
may not be displayed and the data
input by a user may be deleted. Also,
the screen buttons may be harder than
usual to depress.
When you look at the screen through
polarized material such as polarized
sunglasses, the screen may be dark
and hard to see. If so, look at the
screen from different angles, adjust
the screen settings on the “Display”
screen or take off your sunglasses.

30
1. BASIC INFORMATION BEFORE OPERATION
ISF_IS_ISC_Navi_EE
3. INPUTTING LETTERS AND NUMBERS/LIST SCREEN OPERATION
1Touch the keys directly to enter let-
ters or numbers.
: Touch to erase one character.
Touch and hold to continue erasing
characters.
On certain letter entry screens, letters
can be entered in upper or lower case.
1Touch .
2Touch the desired character and key-
board and touch “OK”.
Perform each setting according to the
procedures outlined on the following
pages.
When searching for an address or
name, or entering data, letters and
numbers can be input via the screen.
TO INPUT LETTERS AND
NUMBERS
IconFunction
Touch to enter in lower case.
Touch to enter in upper case.
TO CHANGE CHARACTER
AND KEYBOARD TYPE

31
1. BASIC INFORMATION BEFORE OPERATION
2
BASIC FUNCTION
ISF_IS_ISC_Navi_EE
SELECTING KEYBOARD
CHARACTERS
1Touch .
2Touch the desired character.
“A-Z” type
 type type
TO INPUT UMLAUTS
1Touch .
2Touch .
3Touch the umlaut keys directly to
enter umlauts.
: Touch to erase one umlaut. Touch
and hold to continue erasing umlauts.
“A-Z”, or characters can
be selected.
INFORMATION
Depending on the conditions data is
being input, it may not possible to
change keyboard characters.

32
1. BASIC INFORMATION BEFORE OPERATION
ISF_IS_ISC_Navi_EE
TO INPUT NUMBERS AND
SYMBOLS
1Touch .
2Touch “0-9-%”.
3Touch the keys directly to enter
numbers or symbols.
: Touch to erase one number or
symbol. Touch and hold to continue
erasing numbers and/or symbols.
, : Touch to display other sym-
bols.
SELECTING A KEYBOARD
TYPE
1Touch .
2Touch the desired keyboard type.
“ABCDE” type
“QWERTY” type
“AZERTY” type
Keyboard type can be changed.
