2012 FORD SUPER DUTY engine

Additional maintenance items
1
Miles (x 1,000) 15 22.5 30 45 60 67.5 75 90 105 112.5 120 135 150
Kilometers (x 1,000) 24 36 48 72 96 108 120 144 160 172 184 206 240
Replace accessory drive belt(s) if not replaced in the
last 100,000 miles (160,000 km)•
Replace front wheel bearings and seals if non-sealed
bearings are used (2WD vehicles)•1Additional maintenance items can be performed within 3,000 miles (4,800 km) of the last oil change. Do not exceed
the designated distance for the interval.2Every 15,000 miles (24,000 km), 600 engine hours or as indicated by the message center3Every 22,500 miles (36,000 km) or as indicated by the message center4Inspect at 90,000 miles (144,000 km), then every 15,000 miles (24,000 km); replace at 150,000 miles (240,000 km)5Initial replacement at 6 years, 100,000 miles (160,000 km) or as indicated from coolant tests for concentration
(freeze-point) or additive strength (corrosion inhibitor) (whichever comes first); then every 3 years, 50,000 miles
(80,000 km) or as indicated from coolant tests for concentration (freeze-point) or additive strength (corrosion inhibitor)
Scheduled Maintenance Guide
76
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

SPECIAL OPERATING CONDITIONS
If you operate your vehicleprimarilyin one of the conditions listed
below, you will need to have some items serviced more frequently. If you
onlyoccasionallyoperate your vehicle under any of these conditions,
you don’t need to perform the additional maintenance. For specific
recommendations, see your dealership service advisor or technician.
Frequent/extended idling (over 10 minutes per hour of normal
driving) or frequent low speed operation if vehicle is used for
stationary operation
As required Change engine oil and filter as indicated by
message center and perform services listed in the
scheduled maintenance chart
Every 15,000 miles
(24,000 km), 6 months,
600 engine hours or as
indicated by message
centerReplace engine- and frame-mounted fuel filters
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point protection)
and additive strength (corrosion inhibitor); add
engine coolant additive, if required
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Note:Vehicles operating under these severe service conditions need to
have their maintenance requirements adjusted. This needs to be
considered when determining vehicle service intervals.
Scheduled Maintenance Guide
80
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Frequent low speed operation, consistent heavy traffic less than
25 mph (40 km/h) and/or long rush hour traffic
As required Change engine oil and filter as indicated by
message center and perform services listed in the
scheduled maintenance chart
Every 15,000 miles
(24,000 km), 6 months,
600 engine hours or as
indicated by message
centerReplace engine- and frame-mounted fuel filters
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point protection)
and additive strength (corrosion inhibitor); add
engine coolant additive, if required
Every 60,000 miles
(96,000 km)Change transfer case fluid (4WD vehicles)
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Scheduled Maintenance Guide
81
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Sustained high-speed driving at Gross Vehicle Weight Rating
(maximum loaded weight for vehicle operation)
As required Change engine oil and filter as indicated by
message center and perform services listed in the
scheduled maintenance chart
Every 15,000 miles
(24,000 km), 6 months,
600 engine hours or as
indicated by message
centerReplace engine- and frame-mounted fuel filters
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point protection)
and additive strength (corrosion inhibitor); add
engine coolant additive, if required
Every 30,000 miles
(48,000 km)Replace wheel bearing grease and grease seals if
non-sealed bearings are used (2WD vehicles)
Every 50,000 miles
(80,000 km)Change rear axle fluid (if equipped with a Dana
rear axle; some F-350s, all F-450/550s)
Change transfer case fluid (4WD vehicles)
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Scheduled Maintenance Guide
82
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Operating in sustained ambient temperatures below -10°F
(-23°C) or above 100°F (38°C)
As required Change engine oil and filter as indicated by
message center and perform services listed in
the scheduled maintenance chart
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Every 30,000 miles
(48,000 km)Replace wheel bearing grease/grease seals if
non-sealed bearings are used (2WD vehicles)
Every 60,000 miles
(96,000 km)Change transfer case fluid (4WD vehicles)
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Scheduled Maintenance Guide
83
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Towing a trailer or using a camper or car-top carrier
As required Change engine oil and filter as indicated by
message center and perform services listed in
the scheduled maintenance chart
Every 15,000 miles
(24,000 km) or 600
engine hoursInspect concentration (freeze-point
protection) and additive strength (corrosion
inhibitor); add engine coolant additive, if
required
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Every 30,000 miles
(48,000 km)Replace wheel bearing grease/grease seals if
non-sealed bearings are used (2WD vehicles)
Every 60,000 miles
(96,000 km)Change transfer case fluid (4WD vehicles)
Every 60,000 miles
(96,000 km) or 2,400
engine hoursFlush and refill engine coolant; do not add
engine coolant additive
Perform the services noted in the preceding table at the specified
time/mileage (km) period either within 3,000 miles (4,800 km) of the
OIL CHANGE REQUIRED message appearing in the message center or
when the time/mileage (km) reading indicates service is due.
Example #1:The OIL CHANGE REQUIRED message comes on at
19,751 miles (31,786 km); perform the 22,500 mile (36,000 km) fuel
filter replacement.
Example #2:The OIL CHANGE REQUIRED message hasnotcome on
but the odometer reads 22,500 miles (36,000 km); perform the fuel filter
replacement. (i.e., Intelligent Oil Life Monitor™ was reset at 15,000 miles
[24,000 km].)
Note:When adding coolant additive, do not exceed the specified
maximum of 48 fl. oz. (1.4L). Operating the engine with excessive
coolant additive may cause overheating which could lead to severe
permanent engine damage.
Note:After initial coolant flush and fill at 60,000 miles (96,000 km) or
2,400 engine hours, flush and fill every 45,000 miles (72,000 km) or
1,800 engine hours thereafter.
Scheduled Maintenance Guide
84
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Off-road operation
As required Inspect functional holes in each leg of the twin
tip and the holes under the shield just inboard
of the right rear tire to make sure they are
kept clean/clear of debris or foreign materials.
Refer to theCleaningchapter for more
information
Inspect steering and suspension ball joints and
tie rods; lubricate if equipped with grease
fittings
Every 7,500 miles
(12,000 km)Rotate tires, inspect tires for wear and
measure tread depth and inspect wheel ends
for endplay and noise; dual rear wheels should
only be rotated if unusual wear is observed
Inspect brake system pads and rotors
Inspect engine air filter restriction gauge;
replace filter as indicated by gauge
Every 7,500 miles
(12,000 km) or 300
engine hoursChange engine oil and filter
Inspect and lubricate U-joints
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Every 30,000 miles
(48,000 km)Replace wheel bearing grease/grease seals if
non-sealed bearings are used (2WD vehicles)
Every 50,000 miles
(80,000 km)Change rear axle fluid (if equipped with a
Dana rear axle; some F-350s, all F-450/550s)
Change transfer case fluid (4WD vehicles)
Inspect front axle fluid (4WD vehicles)
Reset your Intelligent Oil Life Monitor™ after each engine oil and filter
change; refer to theInstrument Clusterchapter of theOwner’s
Guide.
Scheduled Maintenance Guide
85
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Operating in dusty conditions (i.e. unpaved or dusty roads)
Every 7,500 miles
(12,000 km)Rotate tires, inspect tires for wear and
measure tread depth and inspect wheel ends
for endplay and noise; dual rear wheels should
only be rotated if unusual wear is observed
Inspect brake system pads and rotors
Inspect engine air filter restriction gauge;
replace filter as indicated by gauge
Inspect steering and suspension ball joints and
tie rods; lubricate if equipped with grease
fittings
Every 7,500 miles
(12,000 km), 6 months
or 300 engine hoursChange engine oil and filter
Inspect and lubricate U-joints
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Every 30,000 miles
(48,000 km)Replace wheel bearing grease/grease seals if
non-sealed bearings are used (2WD vehicles)
Reset your Intelligent Oil Life Monitor™ after each engine oil and filter
change; refer to theInstrument Clusterchapter of theOwner’s
Guide.
Use of Biodiesel, up to and including 20% Biodiesel (B20)
As required Change engine oil and filter as indicated by
message center and perform services listed in
the scheduled maintenance chart
Every 15,000 miles
(24,000 km),
6 months, 600 engine
hours or as indicated
by message centerReplace engine- and frame-mounted fuel filters
Scheduled Maintenance Guide
86
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)
