2012 FORD SUPER DUTY engine

Item Capacity Ford part nameFord part number /
Ford specification or
specification
Engine oil (includes
filter change)13.0 quarts
(12.4L)•MotorcraftMotor Oil
10W30 Super Duty
•MotorcraftMotor Oil
15W40 Super Duty
•MotorcraftMotor Oil
5W40 Super Duty
•MotorcraftMotor Oil
0W30 Super Duty•XO-10W30–QSD /
WSS-M2C171–E
•XO-15W40-QSD /
WSS-M2C171-E
•XO-5W40-5QSD /
WSS-M2C171-E
•CXO-0W30-LAS12 /
WSS-M2C171-D
Diesel Exhaust Fluid
(DEF) — Pick-up5 gallons (18.9L)
MotorcraftDiesel
Exhaust FluidPM-27-G /
WSS-M99C130-A
Diesel Exhaust Fluid
(DEF) — Chassis Cab6 gallons (22.7L)
Cetane Booster &
Performance Improver—MotorcraftCetane
Booster & Performance
ImproverPM-22-A (US)
PM-22-B (Canada) /
—
Anti-Gel &
Performance Improver—MotorcraftAnti-Gel &
Performance ImproverPM-23-A (US)
PM-23-B (Canada) /
—
Fuel tank — Pick up
regular cab long box
and all short box26 gallons (98.4L) — —
Maintenance and Specifications
66
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

GENERAL MAINTENANCE INFORMATION
Why maintain your vehicle?
This guide describes the scheduled maintenance required for your vehicle.
Carefully following this schedule helps protect against major repair
expenses resulting from neglect or inadequate maintenance and may also
help to increase the value of your vehicle when you sell or trade it.
It is your responsibility to see that all scheduled maintenance is performed
and that the materials used meet Ford engineering specifications as
identified in theMaintenance and Specificationschapter. Failure to
perform scheduled maintenance specific in this guide will invalidate
warranty coverage on parts affected by the lack of maintenance. Be sure
receipts for completed maintenance are kept with the vehicle and
confirmation of the work performed is always recorded in this guide.
Your Ford dealer has factory-trained technicians who can perform the
required maintenance using genuine Ford parts. They are committed to
meeting your service needs and to assuring your continuing satisfaction.
Protecting your investment
Maintenance is an investment that will pay dividends in the form of
improved reliability, durability and resale value. To ensure the proper
performance of your vehicle and its emission control systems, it is imperative
that scheduled maintenance be completed at the designated intervals.
Your vehicle is equipped with the Intelligent Oil Life Monitor™ system
which displays a message in the message center at the proper oil change
service interval; this interval may be up to one year or 10,000 miles
(16,000 km). When ENGINE OIL CHANGE DUE or OIL CHANGE
REQUIRED appears in the message center display, it’s time for an oil
change; the oil change must be done within two weeks or 500 miles
(800 km) of the OIL CHANGE REQUIRED message appearing. The
Intelligent Oil Life Monitor™ must be reset after each oil change; refer to
theInstrument Clusterchapter.
If your message center is prematurely reset or becomes inoperative, you
should perform the oil change interval at six months, 5,000 miles
(8,000 km) or 200 engine hours from your last oil change.
Your vehicle is very sophisticated and built with multiple complex
performance systems. Every manufacturer develops these systems using
different specifications and performance features. That’s why it’s
important to rely upon your Ford dealership to properly diagnose and
repair your vehicle.
Scheduled Maintenance Guide
68
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Ford Motor Company has recommended maintenance intervals for various
parts and component systems based upon engineering testing. Ford Motor
Company relies upon this testing to determine the most appropriate
mileage for replacement of oils and fluids to protect your vehicle at the
lowest overall cost to you and recommends against maintenance schedules
that deviate from the scheduled maintenance information.
Ford strongly recommends the use of genuine Ford replacement parts.
Parts other than Ford, Motorcraftor Ford-authorized remanufactured
parts that are used for maintenance replacement or for the service of
components affecting emission control must be equivalent to genuine
Ford Motor Company parts in performance and durability. It is the
owner’s responsibility to determine the equivalency of such parts. Please
consult yourWarranty Guidefor complete warranty information.
Non Ford-approved chemicals or additives are not required for factory
recommended maintenance. In fact, Ford Motor Company recommends
against the use of such additive products unless specifically
recommended by Ford for a particular application.
Oils, fluids and flushing
In many cases, fluid discoloration is a normal operating characteristic of the
chemical compound and may not necessarily demonstrate that a fluid
needs to be changed. Oils and fluids identified in this guide should be
changed at the specified interval or in conjunction with a repair. Flushing is
a viable way to change fluid for many vehicle sub-systems during scheduled
maintenance and should only be done using the same fluid required to
finish the maintenance procedure, or a Ford-approved flushing chemical.
Genuine Ford parts and service
When planning your maintenance services, consider your dealership for
all your vehicle’s needs.
There are a lot of reasons why your dealership is a great way to help
keep your vehicle running great.
Convenience
To make your service visit even more convenient, in many cases, you’ll find
extended evening hours and Saturday hours. How’s that for quality service?
Factory-trained technicians
Service technicians participate in extensive factory-sponsored training to
help them become the experts on the operation of your vehicle. Many
participate in Ford-sponsored training to become certified. Ask your dealer
about the training and certification their technicians have received.
Scheduled Maintenance Guide
69
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Engine coolant change interval
Initial change 6 years or 100,000 miles (160,000 km)
(whichever comes first), or as indicated from the
coolant tests for concentration (freeze-point) or
additive strength (corrosion inhibitor)
After initial change Every 3 years or 50,000 miles (80,000 km), or as
indicated from the coolant tests for concentration
(freeze-point) or additive strength (corrosion
inhibitor)
Use engine coolant specified in theMaintenance product
specifications and capacitiestable in theMaintenance and
Specificationschapter
Refer toSpecial operating conditionslater in this chapter
Check every month
Engine air filter restriction gauge
Fuel filter/water separator; drain if necessary (or if indicated by the
message center)
Holes/Slots in the tail pipe to make sure they are functional and clear
of debris
Retightening lug nuts*
Vehicles with single
rear wheelsRetighten the lug nuts to the specified torque at
500 miles (800 km) after any wheel disturbance
(tire rotation, changing a flat tire, wheel removal,
etc).
Vehicles with dual
rear wheelsRetighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at
500 miles (800 km) of new vehicle operation and
after any wheel disturbance (tire rotation,
changing a flat tire, wheel removal, etc).
*Refer toWheel lug nut torque specificationsin yourOwner’s Guide
for the proper lug nut torque specification
Scheduled Maintenance Guide
71
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Multi-point inspection
In order to keep your vehicle running right, it is important that you have
the systems on your vehicle checked regularly. This can help identify any
potential issue before there are any problems. Ford Motor Company
suggests the following multi-point inspection to be performed at every
scheduled maintenance interval as the way to ensure your vehicle keeps
running right.
Multi-point inspection - recommended each visit
Accessory drive belt(s) Holes/Slots in the tail-pipe to make
sure they are functional and clear of
debris
Battery performance Horn operation
Engine air filter Radiators, coolers and heater and air
conditioning hoses
Exhaust system Shocks and struts and other
suspension components for leaks and
damage
Exterior lamps and hazard
warning system operationTires for wear and check air pressure,
including spare
Fluid levels*; fill if necessary Windshield for cracks, chips and
pitting
For oil and fluid leaks Windshield washer spray and wiper
operation
*Brake, engine coolant reservoir, secondary low-temperature cooling
system reservoir, automatic transmission, power steering and window
washer
Scheduled Maintenance Guide
72
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

NORMAL SCHEDULED MAINTENANCE AND LOG
Intelligent Oil Life Monitor™
Your vehicle is equipped with an Intelligent Oil Life Monitor™ that
determines when the engine oil should be changed based on how your
vehicle is used. By using several important factors in its calculations, the
monitor helps reduce the cost of owning your vehicle and reduce
environmental waste at the same time. This means you won’t have to
remember to change the oil on a mileage-based schedule; the vehicle lets
you know when an oil change is due by displaying OIL CHANGE
REQUIRED in the message center. The following table is intended to
provide examples of vehicle use and its impact on engine oil change
intervals; it is provided as a guideline only. Actual engine oil change
intervals will depend on several factors and will generally decrease with
severity of use.
When to expect the OIL CHANGE REQUIRED message
Miles (km) Vehicle use and examples
7500-10000
(12000-16000)Normal
– Normal commuting with highway driving
– No, or moderate, load/towing
– Flat to moderately hilly roads
– No extended idling
5000-7499
(8000-11999)Severe
– Moderate to heavy load/towing
– Mountainous or off-road conditions
– Extended idling
– Extended hot or cold operation
3000-4999
(4000-7999)Extreme
– Maximum load/towing
– Extreme hot or cold operation
– Use of high sulfur diesel fuel
Use the appropriate special operating condition for maintenance
information when using high sulfur diesel fuels, operating your vehicle
off-road or in dusty conditions (such as unpaved roads)
Scheduled Maintenance Guide
73
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Normal Scheduled Maintenance
At every oil change
interval as indicated
by the message
centerChange engine oil and filter
Refill diesel exhaust fluid tank
Rotate tires, inspect tire wear and measure tread
depth; vehicles equipped with dual rear wheels
should only rotate the rear wheels if unusual
wear is observed
Perform multi-point inspection (recommended)
Inspect air filter restriction gauge, replace filter
as necessary
Inspect automatic transmission fluid level
Inspect brake pads, shoes, rotors, drums, brake
linings, hoses and parking brake
Inspect cabin air filter (if equipped)
Inspect engine cooling system strength and hoses
Inspect exhaust system and heat shields
Inspect front axle and U-joints; lubricate if
equipped with grease fittings (4WD vehicles)
Inspect half-shaft boots (if equipped)
Inspect steering linkage, ball joints, suspension,
tie-rod ends, driveshaft and U-joints; lubricate if
equipped with grease fittings
Inspect wheels and related components for
abnormal noise, wear, looseness or drag
Reset your Intelligent Oil Life Monitor™ after each engine oil and filter
change; refer to theInstrument Clusterchapter in yourOwner’s
Guide.
Do not exceed one year or 10,000 miles (16,000 km) between
service intervals
Scheduled Maintenance Guide
74
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)

Additional maintenance items
1
Miles (x 1,000) 15 22.5 30 45 60 67.5 75 90 105 112.5 120 135 150
Kilometers (x 1,000) 24 36 48 72 96 108 120 144 160 172 184 206 240
Inspect engine and secondary cooling system
concentration (freeze-point protection), additive
strength (corrosion inhibitor), coolant level and hoses
2
• ••• ••• •••
Replace engine- and frame-mounted fuel filters
3
••• • • •
Replace climate-controlled seat filter (if equipped)•• • • •
Replace air inlet foam filter Replace at 45,000 miles (72,000 km), 97,500 miles
(156,000 km) and 150,000 miles (240,000 km)
Replace front wheel bearing grease and grease seal if
non-sealed bearings are used (2WD vehicles)••
Inspect accessory drive belt(s)
4
•
Change rear axle fluid (Dana axles; refer toSpecial
operating conditions)Replace at 100,000 miles (160,000 km), then at
150,000 miles (240,000 km)
Change engine coolant and secondary coolant5
Change automatic transmission fluid and filter on
6–speed TorqShifttransmission•
Change front axle fluid (4WD vehicles)•
Change transfer case fluid (4WD vehicles)•
Scheduled Maintenance Guide
75
2012 Diesel(67l)
Supplement(supplement), 1st Printing
Arabic_(LHD)(gc_lhd)
