2012 Citroen C3 PICASSO Owner's Manual

12
167
TECHNICAL DATA
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned
must be reduced by 10% for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient
temperature is above 37 °C, limit the towed load. *
For Russia only.

**
The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an
equal amount; warning, towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

WEIGHTS AND TOWED LOADS (in kg)



Petrol engines


VTi 95



VTi 115

*


VTi 120



VTi 115 *



VTi 120



Gearboxes


Manual



Manual



Electronic gearbox system
(6-speed)



Model codes:
SH...


8FP0



5FJ0 *



5FS0



5FJ8/P *



5FS8/P




- Unladen weight
1 201
1 204
1 205


- Kerb weight
1 276
1 279
1 280


- Payload
546
549
564


- Gross vehicle weight (GVW)
1 747
1 753
1 769


- Gross train weight (GTW)
on a 12 % gradient
2 597
2 603
2 619


- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient
850
850
850


- Braked trailer ** (with load transfer within
the GTW limit)
1 100
1 100
1 100


- Unbraked trailer
635
635
640


- Recommended nose weight
54
54
54

12
168
TECHNICAL DATA

MODELS:


ENGINE AND GEARBOX



Model codes:
SH...


8FN0/GPL



LPG ENGINE


VTi 95


Cubic capacity (cc)
1 397
Bore x stroke (mm)
77 x 75
Max. power: EU standard (kW)
70
Max. power speed (rpm)
6 000
Max torque: EU standard (Nm)
136
Max. torque speed (rpm)
4 000
Fuel
LPG/Unleaded
Catalytic converter
Yes

GEARBOX

Manual
(5-speed)

OIL CAPACITY (in litres)




Engine (with fi lter replacement)
4.25

12
169
TECHNICAL DATA


WEIGHTS AND TOWED LOADS (in kg)



LPG engines


VTi 95



Gearbox


Manual



Model codes:
SH...


8FN0/GPL




- Unladen weight
1 301


- Kerb weight
1 376


- Payload
446


- Gross vehicle weight (GVW)
1 747


- Gross train weight (GTW)
on a 12 % slope
2 597


- Braked trailer (within GTW limit)
on a 12 % slope
850


- Braked trailer * (with load transfer within
the GTW limit)
1 100


- Unbraked trailer
650


- Recommended nose weight
54

*

The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an
equal amount; warning, towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient
temperature is above 37 °C, limit the towed load.

12
170
TECHNICAL DATA

MODELS:


ENGINES AND GEARBOXES



Model codes:
SH...


9HP0



9HP8/P/S



9HR8



DIESEL ENGINES


HDi 90 PEF



e-HDi 90 PEF



HDi 110 PEF


Cubic capacity (cc)
1 560
1 560
1 560
Bore x stroke (mm)
75 x 88.3
75 x 88.3
75 x 88.3
Max power: EU standard (kW)
68
68
82
Max power engine speed (rpm)
4 000
4 000
3 600
Max torque: EU standard (Nm)
230
230
270
Max torque engine speed (rpm)
1 750
1 750
1 750
Fuel
Diesel
Diesel
Diesel
Catalytic converter
yes
yes
yes
Particle emission fi lter
yes
yes
yes

GEARBOXES

Manual (5-speed)
Electronic gearbox
system (6-speed)
Manual (6-speed)

OIL CAPACITIES (in litres)




Engine (with fi lter replacement)
3.75
3.75
3.75

.../S
: e-HDi model fi tted with Stop & Start.

12
171
TECHNICAL DATA

*
The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an
equal amount; warning, towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

WEIGHTS AND TOWED LOADS (in kg)



Diesel engines


HDi 90 PEF



e-HDi 90 PEF



HDi 110 PEF



Gearboxes


Manual



Electronic gearbox
system



Manual



Model codes:
SH...


9HP0



9HP8/P/S



9HR8




- Unladen weight
1 277
1 313
1 318


- Kerb weight
1 352
1 388
1 393


- Payload
502
498
489


- Gross vehicle weight (GVW)
1 779
1 811
1 807


- Gross train weight (GTW)
on a 12 % gradient
2 979
3 011
2 757


- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient


1 200
1 200
950


- Braked trailer * (with load transfer
with the GTW limit)
1 200
1 200
1 200


- Unbraked trailer
675
675
675


- Recommended nose weight
54
54
54
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient
temperature is above 37 °C, limit the towed load.

12
172
TECHNICAL DATA
DIMENSIONS (IN MM)

12
173
TECHNICAL DATA
IDENTIFICATION MARKINGS
Various visible markings for the identifi cation of your vehicle.

If the infl ation pressures are too low,
this increases fuel consumption.


The infl ation pressures must
be checked when the tyres are
cold, at least once a month.



A.
Vehicle Identifi cation Number (VIN)
on the front right door pillar.
This number is engraved on the
bodywork near the hinge.
For access to it, open the right-hand
door.
B.
VIN on the windscreen lower
crossmember.

The number is on a self-adhesive
label which is visible through the
windscreen.

C.
Manufacturer's label.

This number is indicated on a self-
destroying label affi xed to the centre
pillar, on the left-hand side.
D.
Tyre/paint label.

This label is affi xed to the centre pil-
lar, on the left-hand side.
It bears the following information:


- the tyre infl ation pressures with and
without load,

- the wheel rim and tyre sizes,

- the brands of tyre recommended by
the manufacturer,

- the infl ation pressure of the spare
wheel,

- the paint colour code.

174
