Downloaded from www.Manualslib.com manuals search engine IfthebrakefluidlevelfalLsconsiderablybe­
Lowthe"MIN" mark,thebrakewarning/indi-
catorlight(U.s.models:,Canadian
models:.)willcomeonqpage14.Donot
continuetooperatethevehicle. Thecomplete
brakesystemshouldbethoroughlychecked
byanauthorizedAudidealerorotherquali­
fied facility
andthecausecorrected.Ifthe
brakefLuidLevelistoolow,thebrakewarning/
indicator lightwillilluminate.Contactanau­
thorizedAudidealerimmediately.
Changing brakefluid
Havethebrake fluidchanged byan experi­
enced technician.
Brakefluidabsorbsmoisturefromtheair.If
thewatercontentinthebrakefluidistoo
high, corrosioninthebrakesystemmayresult
afteraperiodoftime.The boilingpointofthe
brake fluidwillalsodecreaseconsiderablyand
decreasebrakingperformance.
Therefore,thebrake fluidmustbechanged
everytwoyears.Always usenew brake fluid
which
conformstoFederal MotorVehicle
Standard"FMVSS116DOT4".
Thebrake fluidreservoir canbedifficultto
reach,therefore,werecommendthatyou
have
thebrake fluidchangedbyyourauthor­
izedAudi deaLer. Yourdealerhasthecorrect
tools,therightbrakefluidandtheknow-how
todothisforyou.
&.WARNING
- Brake fluidispoisonous.
Itmustbestor­
ed onlyintheclosed originalcontainer
outofthereachofchiLdren!
- Brake failure can
resultfromoldorinap­
propriatebrakefluid. Observethesepre­
cautions:
- Use only brake fluid
thatmeetsSAE
specification]1703andconformsto
Federal MotorVehicleStandard116.
Always checkwithyourauthorizedAudi
dealertomakesureyouareusingthe
correctbrake fluid.Thecorrecttypeof
brake fluidisalsoindicated onthe
brakefluidreservoir.
- The brake fluid
mustbenew. Heavy use
ofthebrakes cancauseavaporLockif
thebrake fluidisleftinthesystemtoo
long.Thiscanseriouslyaffecttheeffi­
ciency
ofthebrakesaswellasyour
safety.This could resuLtinanaccident.
CDNote
Brake fluidwill
damagethepaintofyour
vehicle.
@lForthesakeoftheenvironment
Because
oftheproblemofproperdisposal
ofbrake fluidaswell asthespecialtools
requiredandthenecessaryexpertise,we
recommendthatyouhavethebrakefLuid
changedbyyourauthorizedAudi deaLer.
Battery
General information •
Your vehicle
isequippedwithaspeciaL bat­
tery,
anAGMbattery.Thisbatteryis located
intheluggagecompartmentandmustbe re­
placed with
anoriginalequipmentbattery.
Under
normaloperatingconditions,thebat­
teryismaintenance-free.
Havethebatterycheckedwhenyoutakeyour
vehicle
inforservice.YOlr"arewell advisedto
replace abatterythatisoldèr-thanSyears.
Disconnecting thebattery terminaIs
Somevehiclefunctions(powerwindowregu­
lators,forexample)arelostifthebatteryter­
minalsaredisconnected.Thesefunctionshave
toberelearnedafterthebatteryterminalsare
connectedagain.Topreventthis,thebattery
shouldonly bedisconnectedfromthevehicle
electricalsystemwhenabsolutelynecessary
for repairs.
Vehicles notdriven forlong periods
Ifyouaregoingtoletyourvehiclestandfora
longtimeandnotdriveit,youshouldremern­
berthereareelectricalcomponentswhich are~
stillfunctioningandtheywilldrawenergy
fromthebatteryanddrain it,forexample,the
engine immobilizer.Topreventthis,youcan
either
chargethebatteryoccasionallytokeep
it
ingood working condition oryou candis­
connect
thenegativecableonthebattery.
Winter operation
During
thewintermonths,batterycapacity
tendstodecreaseastemperaturesdrop. This
isbecausemorepowerisaLsoconsumedwhile
starting,andtheheadlights,rearwindow de­
fogger,
etc.,areusedmoreoften.
Avoidunnecessarypowerconsumption,par­
ticularly
incity traffic orwhentraveling only
shortdistances.LetyourauthorizedAudi
dealer check
thecapacityofthevehicle bat­
tery before
wintersetsinqpage196.Awell
charged
batterywillnotonlypreventstarting
problems whentheweatheriscold,butwill
also
lastlonger.
Replacing battery
Thenewbatterymusthavethesamecapaci­
ty,voltage(12volts),amperage,construction
andplugsealing,astheoriginalbattery.Spec­
ifications
arelisted onthebatteryhousing.
Batteries specially
developedbyAudifulfill
the
maintenance,output,andsafetyrequire­
ments.
When installing
thebattery,makesuretheig­
nition
andailelectricalconsumersareswitch­
edoffq(j).
Werecommendthatyou usemaintenance­
freeorcycle-resistant/leak-proofbatteries
accordingtothestandardsTL82S06(from
December
1997)andVW7SO73(fromAu­
gUst2001).
Replacingthebatteryshouldbe carriedbya
qualified workshop. Pleasefollowtheinstruc­
tions on
thebatterycover.
CDNote
-Allworkonthebatteryrequirestechni­
calknowledge. PleasecontactanAudi
dealershiporanotherauthorizedfacility
Checkingandfilling19:
forquestionsaboutthebattery-danger
ofacidburnsandexplosionhazard!
- The
batterymustnotbeopened!Donot
trytochangethebattery'sliquid level,
otherwisedetonatinggaswillescape
fromthebattery-explosion hazard!
- The
AGMbatteryintheluggagecom­
partmentcannotleak,becausetheelec­
trolyteforthisbatteryisabsorbedinto a
special
glassmat.This leak-proofbattery
mustnotbereplace withaconventional
battery.
-Makesuretheventilationhose onthe
sideofthebatteryisconnected,other­
wisefumesorbatteryacidcanleakout.
-Batteryholderandterminalsalways
have
tobesecured correctly.
- Bèfore allwork on
thebatteryfollowthe
warnings belowq.&inWorkingonthe
batteryonpage 194.
eForthe sakeoftheenvironment
Because
oftheproblemofproperdisposal
ofabattery,werecommendyourauthor­
ized Audidealerchangethebatteryfor
you.Batteriescontainsulfuric acidand
leadandmustalwaysbedisposedofprop­
erly
incompliancewithall environmental
regulations.Disposingofvehiclebatteries
improperlyisverydangeroustotheenvi­
ronment.Makesurethattheremovedbat­
terycannotoverbalance,otherwisesulfu­
ric acid
mightescape!
iTips
Ifyourvehicleisleftstandingforseveral
weeksatextremelylowtemperatures,the
vehiclebatteryshouldberemovedand
storedwhereitwillnotfreeze. Thiswill
preventitfrombeingdamagedandhaving
tobereplaced.
