thanisbeinggeneratedandensuresanopti­
malstateofchargeforthebattery.
iTips
-But evenenergymanagementcannot
negatethelimitsofphysics. Consider
thatthepowerandlifeofabatteryare
limited.
-
Ifstartingability isthreatened,youare
informedbyawarningqpage160,
Driver natification
intheinstrument
c/uster display.
Whatyoushouldknow
Thehighest priarityisgiventomaintaining
starting capability.
Thebatteryisseverelytaxedinshort-distance
driving,incitytrafficandduringthecoldtime
ofyear.Abundantelectricalenergyisre­
quired,
butonly alittleisgenerated.Itisalso
critical
iftheengineisnotrunningandelectri­
cal
componentsareturnedon. Inthisin­
stanceenergyisbeingconsumedbutnoneis
being
generated.
ItisinpreciselythesesituationsthatyouwiII
noticeenergymanagementactivelyregulat­
ingthedistributionofenergy.
Vehiclestandsforanextendedperiod
Ifyoudonotdriveyourvehicle overaperiod
ofseveral daysorweeks, electricalcompo­
nentsaregraduallyeutbackorswitchedoff.
This
reducesenergyconsumptionandmain­
tainsstartingcapability overalongerperiod.
Take into
considerationthatwhenyouunlock
your vehicle,
someconvenience functions,
such as
theremotekeyorpowerseatadjust­
ment,maynotbeavailable. Theconvenience
functionswillbeavailable againwhenyou
turnontheignitionandstarttheengine.
Withtheengineturnedoff
Ifyoulistentotheradio, forexample,with
theengineturnedoff,thebatteryisbeingdis­
charged.
Ifstartingcapabilityisjeopardizedduetoen­
ergy
consumption,amessageappearsinthe
driverinformationdisplay.
Youhavetostarttheenginetochargethe
battery.
Withtheenginerunning
Althoughelectricalenergyisgeneratedwh en
thevehicle isbeing driven,thebatterycanbe­
comedischarged.Thishappensmostlywhen
little
energyisbeinggeneratedandagreat
dealconsumedandthebattery'sstateof
chargeisnotoptimal.
Tobringtheenergybalanceback intoequili­
brium,
consumerswhich require especially
large
amountsofenergyaretemporarilyeut
back
orswitchedoff. Heatingsystemsinpar­
ticularrequire agreatdealofenergy.Ifyou
notice,forexample,thattheheatedseats*or
theheatedrearwindowarenotheating,they
have
beentemporarilyeutbackorswitched
off.
Thesesystemswill beavailable againas
soonastheenergybalancehasbeenrestored.
Youwillalsonoticethatengineidlespeedhas
beenincreased slightly.Thisisnormalandnot
a
causefor concern.Byincreasingengineidle
speedtheadditionalene"rgyrequired isgener­
atedandthebatteryischarged.
Drivernotificationintheinstrument~
clusterdisplay•
Ifbatterypowerdropsintotherangewhereit
can limittheabilityoftheenginetostart,this
isshownintheinstrumentclusterdisplay
with
thefollowing drivermessage:
ri1Lowbatterycharge:batterywillbe
chargedwhiledriving
This notification remindsyou
thatthestarting
capability
oftheenginemay belimited.As
soonasyoustartdrivingagain,thebattery
willberechargedandthenotification willgo
out.
Drivernotificationappearsandgoesout
again
Ifthisdriver notificationappearsaftertheig­
nition is
turnedonorwhile drivinganditgoes
outagainafterawhile,thebatteryhasbeen
adequatelyrecharged.
Drivernotificationappearsanddoesnot
gooutagain
Ifthisdriver notificationappearsaftertheig­
nition
isturnedonorwhile drivinganddoes
notgooutagain,thebattery'sstateofcharge
isnotintheoptimalrange.Startingabilityis
restricted. Havethebatterycheckedassoon
aspossible byanauthorizedAudidealeror
qualified workshop.
Intelligenttechnology16l
