Overview of information and warning symbols09

* Option/accessory, for more information, see Introduction.345 Introduction
The symbols in the vehicle's various displays
are divided into three main categories:
•Warning symbols
•Indicator symbols
•Information symbols
The following tables list the most common
symbols, their meaning and the pages in this
manual that provide more detailed information.
Warning symbol
The red warning symbol lights up to
indicate a problem related to safety and/or
drivability. A message will also appear in the
main instruments panel's display.
Information symbol
The information symbol lights up and a
text message is displayed to provide the driver
with necessary information about one of the
vehicle's systems.
Symbols in the main instrument panel
Warning symbols
SymbolDescriptionP.
no.
Low oil pressure78
A
Parking brake78
SRS airbags78
Seat belt reminder79
Generator not charg-
ing79
A
Fault in the brake sys-
tem79
Warning symbol79
ACanadian models
Indicator symbols
SymbolDescriptionP.
no.
Fault in the Active
Bending Light
(ABL)*system77
A
Malfunction indicator
light77
A
Anti-lock brake sys-
tem (ABS)77
Rear fog light on77
Stability system
(DSTC), Hill Descent
Control, Trailer Stabil-
ity Assist*77
Tire pressure monitor-
ing sensor (TPMS)77
Low fuel level77

09 Specifications
Overview of information and warning symbols 09
346* Option/accessory, for more information, see Introduction.
SymbolDescriptionP.
no.
Information symbol,
see text in information
display77
High beam indicator76
Left turn signal indica-
tor76
Right turn signal indi-
cator76
ACanadian models
Other information symbols
SymbolDescriptionP.
no.
Adaptive Cruise Con-
trol *151,
157
Adaptive Cruise Con-
trol *151,
157
Adaptive Cruise Con-
trol *, Distance Alert*151,
157,
159
SymbolDescriptionP.
no.
Adaptive Cruise Con-
trol *, Distance Alert*151,
157,
159
Adaptive Cruise Con-
trol *151,
157
Adaptive Cruise Con-
trol *, Distance Alert*151,
157,
159
Adaptive Cruise Con-
trol *, Distance Alert*151,
157,
159
Adaptive Cruise Con-
trol*151,
157
Radar sensor*155
Camera*
Laser sensor*171
SymbolDescriptionP.
no.
Collision Warning with
Full Auto-brake and
Pedestrian Detection*173
Driver Alert System*175
Active Bending Lights
(ABL)*90
Fuel filler door (arrow
indicates it is on right
side of vehicle)76
Rain sensor*95
Driver Alert System*176
Driver Alert System*,
Lane Departure Warn-
ing*178

09 Specifications
Overview of information and warning symbols09
* Option/accessory, for more information, see Introduction.347
SymbolDescriptionP.
no.
Driver Alert System*,
Lane Departure Warn-
ing*178
Adaptive Cruise Con-
trol *151,
157
Information symbols in the center
console display
SymbolDescriptionP.
no.
Audio files219
CD folder219
Video files219
Bluetooth-connected
cell phone230
BluetoothTM hands-
free230
HD radio
Park Assist*181
Information symbols in the ceiling
console
SymbolDescriptionP.
no.
Seat belt reminder19
Occupant Weight
Sensor26

09 Specifications
Volvo programs 09
348
Volvo On Call Roadside Assistance
Your new Volvo comes with a four year ON
CALL roadside assistance. Additional informa-
tion, features, and benefits are described in a
separate information package in your glove
compartment.
If you require assistance, dial:
In the U.S. 1-800-638-6586 (1-800-63-
VOLVO)
In Canada 1-800-263-0475
Technician certification
In addition to Volvo factory training, Volvo sup-
ports certification by the National Institute for
Automotive Service Excellence (A.S.E.). Certi-
fied technicians have demonstrated a high
degree of competence in specific areas.
Besides passing exams, each technician must
also have worked in the field for two or more
years before a certificate is issued. These pro-
fessional technicians are best able to analyze
vehicle problems and perform the necessary
maintenance procedures to keep your Volvo at
peak operating condition.

09 Specifications
09
349
