2011 VOLKSWAGEN TOUAREG Owners Manual

x If necessary activate “wait for incoming Bluetooth connections”.
x Hold the mobile phone in your hand ready to enter the password within the time limit.
x Select the mobile phone from the device list in the vehicle by pressing the corresponding function key.
x Select the required pairing protocol below the mobile phone found.
x On the mobile phone, confirm the connection queries from the vehicle if required.
x Confirm the 4-digit password displayed on the Infotainment System screen.
x Enter the password on the mobile phone within 30 seconds.27.
x Confirm password entry.
x If necessary, confirm further queries on the mobile phone.
Pairing procedure if a mobile phone has already been paired with the telephone control
x Set the Bluetooth connection to visible on the mobile phone ⇒  step 1.
x Switch on the ignition.
x Access the SETUP main menu with the SETUP Infotainment button.
x Press the Telephone function key.
x Press the Bluetooth settings function key.
x In the Bluetooth settings menu, press the Search for Bluetooth devices function key.
x If necessary, confirm the query about whether Bluetooth has been activated on the mobile phone with Next .
x Carry out pairing as described ⇒  step 3.
Failed pairing
There is no limit on the number of attempts to pair the device with the telephone control.
Linking will not be successful if the password input time limit is exceeded or if the PIN code is entered incorrectly.
Restart linking if the process fails despite correct entries.
Copying telephone directory to the telephone control
Once pairing has been successfully completed, the telephone directory entries from the mobile phone27 are loaded automatically into the data memory of the telephone control. Depending on the number of entries copied, the process can take several minutes.
The telephone directory memory of the telephone control is limited to 5000 entries. Each user profile can be assigned a maximum of 2000 entries as well as 100 user-created or edited entries.
Automatic connection to a paired mobile phone

The telephone control can be used as soon as the PHONE main menu is displayed on the Infotain-ment System screen.
When connecting automatically, the system will first search for the telephone that was last used in order to reconnect it with the telephone control. If this mobile phone is not in the Bluetooth range, the system will start to search for the mobile phone (user) that was used before it.
x Switch on the ignition.
x Enter the PIN code if it is not stored in the telephone control28.
Requirements for automatic connection
d The mobile phone needs to have already been paired with the telephone control.
d The mobile phone must be switched on and contain a valid SIM card to make telephone calls.
d Bluetooth must be activated on the mobile phone.
d The mobile phone should have no connection to another Bluetooth device.
d The mobile phone must be within the Bluetooth range of the telephone control.
d The ignition must be switched on.
d The mobile phone must have been last connected to the telephone control or another mobile phone connected via Bluetooth is no longer in the Bluetooth range of the telephone control or its Bluetooth feature has been switched off.
If the automatic connection is made during an active telephone call, the telephone control can only make a connection via HFP. Change the Bluetooth connection to rSAP in order to use all tele-phone control functions.
If a Bluetooth connection cannot be set up even though all requirements are fulfilled or if the telephone control does not function “normally”, the mobile phone's system may have crashed. Re-move the battery and insert again. Switch the mobile phone back on and try to establish a Bluetooth connection.
Volkswagen recommends not switching on authorization on the mobile phone so that you confirm the connection queries again before each automatic connection setup.
28 country specific

Basic functions

Fig. 231 Telephone main menu: Connection established.

Function key: Effect
o: Open the number pad to enter a telephone number
Call lists : Opens a pop-up window for selection of a call list for calls
missed, dialed or received on the telephone control
SMS31: Opens a pop-up window with the following options:
Inbox : Displays received SMS.
Templates : Selection of available templates for sending SMS.
Extras : Opens a pop-up window with the following options:
Display off : Switches off the display. Press one of the Infotainment
buttons or the screen to switch on again.
Conference details29: Opens a list of the parties in a current confer-
ence call
Mute : Switches the microphone off during a telephone call, so that the
person on the line cannot hear what is being said in the vehicle.
]: Opens the telephone directory of the paired mobile phone to select a
telephone number

31 Dependent on mobile phone and country.

Entering a telephone number and taking a call

Fig. 232 Entering a telephone number.

Stored telephone numbers

Fig. 234 Displaying a telephone directory entry.
