2011 VOLKSWAGEN TOUAREG Owners Manual

Sun visor adjustment:
x Flip the sun visor down toward the windshield.
x Lift out of mounting and move toward the doors ⇒ fig. 87 (1).
x Rotate the sun visor toward the door.
Vanity mirror and lighting
A vanity mirror is behind a cover in the sun visor. When the cover is slid open (2), the light comes on.
The light goes out when you shut the cover or if you flip the sun visor up again.
The vanity mirror light goes out after several minutes. This helps to prevent unnecessary drain on the vehicle battery.
Windshield made of heat-insulating glass

Fig. 89 Heat-reflective windshield with communications window (blue shaded area).

Rear side window sunshade

Fig. 90 Sunshade in the rear right window.

Windshield wiper and washer

Lights
up
Possible cause Proper response
F Rain sensor malfunction.
Switch ignition off and on again.
If the indicator light comes on
again and stays on, contact an
authorized Volkswagen dealer or
an authorized Volkswagen Ser-
vice Facility
U Windshield and/or rear win-
dow wiper malfunction.
Switch ignition off and on again.
If the indicator light comes on
again and stays on, contact an
authorized Volkswagen dealer or
an authorized Volkswagen Ser-
vice Facility
Y Windshield and rear window
washer fluid level too low.
Refill windshield washer reservoir
at the next opportunity

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 91 Operating the front windshield wiper.

Fig. 92 Operating the rear wiper.

x If the ignition is switched off while the wipers are running, the wipers will continue at the same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recom-mends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can be scratched.
The windshield wipers work only if the ignition is switched on and the engine hood is closed. The windshield wipers turn off automatically when the engine hood is opened. The rear windshield wipers turn off automatically when the rear hatch is opened.
If the front wipers are on, the rear wiper is switched on automatically whenever the car is put into reverse.
If the windshield wiper lever is in the rear window intermittent wiping position ⇒ fig. 92 (6) when the ignition is switched off and back on or the engine is started, rear window wiper action does not resume until the windshield wipers are activated. This is to keep the wiper from working when the window is dry. By switching rear window intermittent wiping off and then back on, you can override this feature and activate the rear window wiper immediately.
The intermittent wiping for the front windshield depends on the driving speed. The higher the speed, the faster the wipers move.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
If the front wipers are on, the rear wiper is switched on automatically when backing up.
Windshield wiper functions

Wiper performance in different situations:
During automatic
wipe/wash:
While the washer system is working, the
climate control system switches to recircula-
tion for about 30 seconds to help prevent the
washer fluid odor from entering the vehicle
interior.
During intermittent wiping: Speed-dependent interval control: The high-
er the vehicle speed, the faster the wipers
move.

Heated washer nozzles
The heating thaws frozen washer nozzles, but not the fluid supply hoses. When the ignition is switched on, the heat applied to the washer nozzles is automatically regulated depending on the outside air temperature.
Headlight washer system
The headlight washer system cleans the headlight lens.
If the ignition and the headlights (high or low beams) are switched on, the headlights are cleaned the first time and every fifth time the front windshield washers are activated. This happens only when the low or high beams are on when the windshield wiper lever is pulled towards the steering wheel. How-ever, the headlights must still be washed by hand periodically (for instance, during fueling) in order to get rid of hard-to-remove dirt (like insect splatter).
To help make sure that the headlight washer system works during winter weather, always keep the headlight washer nozzles free of snow and remove any ice with a deicer spray before driving. Use a deicer spray to remove any ice.
If there is something on the windshield, the wiper will try to wipe it away. If it continues to block the wiper, the wiper will stop moving. Remove the obstacle and switch the wiper on again.

Windshield wiper service position

Fig. 93 Windshield wiper in service position.
