A minus sign in front of the number of miles (kilometers) or days means that service is overdue. Service since --- mi or --- days (Service since --- km or --- days) is shown
on the display ⇒ fig. 316.
The service reminder disappears after a few seconds when the engine is running or the OK button on the multi-function steering wheel has been pushed.

Volkswagen Information System

▪ Hybrid
▪ Tire pressure
▪ Display since start
▪ Display since refuel
▪ Display long-term
▪ Digital speed (digital speed display).
Navigation
Audio
▪ Source list
– DAB
– FM
– AM
– Radio memory
– HDD
– SD
– DVD
– USB
– Bluetooth
– TV tuner
– TV station memory
– External AV source
Telephone
▪ Directory
▪ Dialed numbers
▪ Missed calls
▪ Received calls
Using the instrument cluster menus

Fig. 17 Right side of the multi-function steering wheel: Controls for the menus in the instrument cluster.

x To access a menu item, press the OK button.
Displaying a sub-menu
x Press the ' button on the multi-function steering wheel to access a submenu.
x Press the * or + buttons until the menu item you want is highlighted. The highlighted menu item is between the two horizontal lines.
x Highlight or confirm the selection with the OK button.
If you make no selection within about 10 seconds, the screen switches back to the previous menu.
Returning to the main menu
x Press the

Menu Function See
Vehicle
Display of current warnings or text messages
and other system components depending on
the equipment level.
Information and settings for the multi-function
indicator (MFI).

Vehicle menu

Menu Function
Display
long-term
Trip memory: Display and storage of the accumulated
driving and fuel consumption data of any number of
single trips up to a total driving time of either 19 hours
and 59 minutes or 99 hours and 59 minutes, and up to a
total distance of either 1,999.9 miles (1,999.9 km) or
9,999 miles (9,999 km), depending on the instrument
cluster version. If one of the stored values is exceeded,
then the memory is automatically cleared and starts
again from 0.
Digital
speed
Switch the digital speed on or off.
Shows the current vehicle speed in digital form.
Alt. speed
display
Switch the second speed on or off.
Shows the current vehicle speed in digital form.
Back The display switches back to the main menu.

Possible displays
When selecting 1 of the 3 trip memories Display since start, Display since refuel, or Display long-term, you can access the following submenus:

Submenu Function
Travel time Driving time in hours (h) and minutes (min) cor-
responding to the trip memories Display
since start, Display since refuel, or
Display long-term (toggle).
Current consump-
tion
Current fuel consumption in miles per gallon
(l/100 km) while driving. When units are set to
miles, dashes appear instead of a number when
the engine is running and the vehicle is standing
still. When units are set to kilometers, the display
shows liters consumed per hour when the engine
is running and the vehicle is standing still.

Submenu Function
Average consump-
tion
Average fuel consumption in miles per gallon
(l/100 km) on trips per trip memories is displayed
once the vehicle has been driven about 330 feet
(100 m). Until then, dashes appear instead of a
number. The value displayed is updated every 5
seconds.
Range Estimated distance in miles (km) that the vehicle
can go with the fuel left in the tank the way you
are currently driving. Takes account of the cur-
rent fuel consumption, among other things.
Distance Distance driven in miles (km) from the time the
ignition was switched on.
Average speed The average speed is displayed after the ignition
is switched on and the vehicle has been driven
about 300 feet (100 m). Up to this point, dashes
appear instead of a number. The value displayed
is updated every 5 seconds.
AdBlue
This display appears when the AdBlue fuel range
falls to about 1500 miles (2400 km) and then
provides current information as the range contin-
ues to diminish. You must refuel with AdBlue
within this range

Switching between the displays
x Press the * or + button on the multi-function steering wheel.
Clearing a memory manually
x Select the memory that you want to clear
x Press and hold the OK button on the multi-function steering wheel for about 2 seconds.
