2011 SUBARU TRIBECA Owners Manual

14 &Interior
! Passenger compartment area
1) Seatbelt (page 1-17)
2) Lower anchorages for child restraint
system (page 1-38)
3) Center console (page 6-6)
4) Front seat (page 1-2)
5) Second-row seat (page 1-8)
6) Third-row seat (page 1-13)

1) Cargo area light (page 6-3)
2) Dome lights (page 6-2)
3) Second-row center seatbelt (page 1-24)
4) Sun visors (page 6-4)
5) Map light (page 6-3)
6) Top tether anchorages (second-row seat)(page 1-41)
7) Top tether anchorages (third-row seat) (page 1-42) 15
– CONTINUED –

16
1) Select lever (page 7-13)
2) Hazard warning flasher switch(page 3-5)
3) Multi function display (page 3-23)
4) Glove box (page 6-6)
5) Audio (page 5-1)
6) Climate control (page 4-1)
7) Cup holder (page 6-8)

&Instrument panel1) Door locks (page 2-5)
2) Illumination brightness control
(page 3-28)
3) Remote control mirror switch (page 3-41)
Power folding mirror switch (if equipped)
(page 3-42)
4) Windshield wiper deicer (page 3-35)
5) Traction Control system OFF switch (page 7-27)
6) Headlight beam leveler (if equipped) (page 3-29)
7) Light control switch (page 3-26)
8) Combination meter (page 3-5)
9) Wiper control lever (page 3-32)
10) Cruise control (page 7-30)
11) Horn (page 3-43)
12) SRS airbag (page 1-45)
13) Tilt steering (page 3-43)
14) Hood lock release knob (page 11-4)
15) Fuse box (page 11-35)
16) Power windows (page 2-21) 17
– CONTINUED –

18 &Light control and wiper control levers/switches
1) Parking light switch (page 3-31)
2) Windshield wiper (page 3-32)
3) Mist (page 3-33)
4) Windshield washer (page 3-34)
5) Rear window wiper and washer switch
(page 3-34)
6) Wiper intermittent time control switch (page 3-33)
7) Wiper control lever (page 3-33)
8) Light control switch (page 3-26)
9) Fog light switch (page 3-31)
10) Headlight ON/OFF (page 3-26)
11) Headlight flasher High/Low beam change (page 3-27)
12) Turn signal (page 3-28)

&Combination meter
! U.S.-spec. models1) Temperature gauge (page 3-9)
2) Tachometer (page 3-7)
3) Speedometer (page 3-6)
4) Fuel gauge (page 3-8)
5) Trip meter and odometer
(page 3-6/page 3-7)
6) Trip meter A/B selection and trip meter reset knob (page 3-7)
7) Select lever/Gear position indicator (page 3-20) 19
– CONTINUED –

20 !Except U.S.-spec. models
1) Temperature gauge (page 3-9)
2) Tachometer (page 3-7)
3) Speedometer (page 3-6)
4) Fuel gauge (page 3-8)
5) Trip meter and odometer
(page 3-6/page 3-7)
6) Trip meter A/B selection and trip meter reset knob (page 3-7)
7) Select lever/Gear position indicator (page 3-20)

&Warning and indicator lights
Mark Name Page
Driver ’s seatbelt warning
light 3-10
Front passenger
’s seat-
belt warning light 3-10
SRS airbag system
warning light 3-11
CHECK ENGINE warn-
ing light/Malfunction indi-
cator lamp3-12
Charge warning light 3-13
Oil pressure warning light 3-13
AT OIL TEMP warning light
3-13
/ABS warning light 3-15
/Brake system warning light
3-16
Door open warning light
3-17Mark Name Page
Low fuel warning light 3-17
AWD warning light 3-18
Vehicle Dynamics Con-
trol operation indicator light
3-18
Vehicle Dynamics Con-
trol warning light/Traction
Control system OFF in-
dicator light3-18
Security indicator light 3-19
Turn signal indicator lights
3-20
High beam indicator light 3-20
Front fog light indicator light3-21
Headlight indicator light 3-21
Cruise control indicator light3-20Mark Name Page
Cruise control set indica-
tor light
3-21
Low tire pressure warn-
ing light3-14
Passenger airbag ON in-
dicator light
3-12
Passenger airbag OFF
indicator light3-12
SPORT mode indicator light
3-20
Windshield washer fluid
warning light3-18
Rear differential oil tem-
perature warning light3-1421
– CONTINUED –
