13B-278
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V9 MR-372-J84-13B450$151.mif
DIESEL INJECTION
Fault finding – Interpretation of parameters13B
PR041TURBOCHARGING PRESSURE
PARAMETER
DEFINITIONThis parameter indicates the turbocharging pressure in mbar.
NOTESSpecial notes:
Only perform these tests if the parameters do not correspond with the system
operation programming.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
Conformity check with engine stopped and ignition on, or engine running, and engine coolant
temperature > 80°C
The turbocharging pressure value is PR041 = PR035 ± 0.20 bar
In the event of a fault, consult the interpretation of DF004 Turbocharging pressure sensor circuit.
EDC16C36_V44_PR041/EDC16C36_V4C_PR041/EDC16C36_V48_PR041/EDC16C36_V50_PR041/EDC16C36_V54_PR041/
EDC16C36_V58_PR041EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-282
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V9 MR-372-J84-13B450$151.mif
DIESEL INJECTION
Fault finding – Interpretation of parameters13B
PR051EGR VALVE POSITION FEEDBACK
PARAMETER
DEFINITIONThis parameter indicates the EGR valve opening ratio.
NOTESSpecial notes:
Only perform these tests if the parameters do not correspond with the system
operation programming.
There must be no present or stored faults.
Perform this fault finding procedure:
– after finding an inconsistency in the parameter,
– after a customer complaint (loss of power, smoke etc.).
– after interpretation of command AC103 EGR by-pass.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
Conformity check with engine stopped and ignition on, or engine running, and engine coolant
temperature > 80°C
This parameter indicates the EGR valve opening ratio.
In the event of a fault, consult the interpretation of faults DF209 EGR valve position sensor circuit and DF647
EGR valve position regulation.
EDC16C36_V44_PR051/EDC16C36_V4C_PR051/EDC16C36_V48_PR051/EDC16C36_V50_PR051/EDC16C36_V54_PR051/
EDC16C36_V58_PR051EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-286
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V9 MR-372-J84-13B450$151.mif
DIESEL INJECTION
Fault finding – Interpretation of parameters13B
PR058AIR TEMPERATURE
PARAMETER
DEFINITIONThis parameter indicates the air inlet temperature in °C.
NOTESSpecial notes:
Only perform these tests if the parameters do not correspond with the system
operation programming.
There must be no present or stored faults.
Perform this fault finding procedure:
– after finding an inconsistency in the parameter,
– after a customer complaint (e.g. lack of power).
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
Conformity check with engine stopped and ignition on
With the ignition on the inlet air temperature varies according to the exterior temperature.
Default value: 20°C
In the event of a fault, consult the interpretation of fault DF002 Air temperature sensor circuit.
Parameter PR059 ≈ PR064 Coolant temperature engine cold.
Conformity check with engine running, engine coolant temperature > 80°C
With the engine running at idle speed the inlet air temperature varies according to the engine coolant temperature.
Default value: 20°C
In the event of a fault, consult the interpretation of fault DF002 Air temperature sensor circuit.
EDC16C36_V44_PR058/EDC16C36_V4C_PR058/EDC16C36_V48_PR058/EDC16C36_V50_PR058/EDC16C36_V54_PR058/
EDC16C36_V58_PR058EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-288
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V9 MR-372-J84-13B450$151.mif
DIESEL INJECTION
Fault finding – Interpretation of parameters13B
PR063FUEL TEMPERATURE
PARAMETER
DEFINITIONThis parameter indicates the fuel temperature in °C.
NOTESSpecial notes:
Only perform these tests if the parameters do not correspond with the system
operation programming.
There must be no present or stored faults.
Perform this fault finding procedure:
– after finding an inconsistency in the parameter,
– after a customer complaint (e.g. lack of power).
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
Conformity check with engine stopped and ignition on, or engine running, and engine coolant
temperature > 80°C
This parameter indicates the fuel temperature: - 30°C < PR063 < 90°C
Default value: 100°C
In the event of a fault, see the interpretation of DF098 Fuel temperature sensor circuit.
EDC16C36_V44_PR063/EDC16C36_V4C_PR063/EDC16C36_V48_PR063/EDC16C36_V50_PR063/EDC16C36_V54_PR063/
EDC16C36_V58_PR063EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-290
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
V9 MR-372-J84-13B450$151.mif
DIESEL INJECTION
Fault finding – Interpretation of parameters13B
PR064COOLANT TEMPERATURE
PARAMETER
DEFINITIONThis parameter indicates the engine coolant temperature in °C.
NOTESSpecial notes:
Only perform these tests if the parameters do not correspond with the system
operation programming.
There must be no present or stored faults.
Perform this fault finding procedure:
– after finding an inconsistency in the parameter,
– after a customer complaint (e.g. lack of power).
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
Conformity check with engine stopped and ignition on
With the ignition on the coolant temperature varies according to the exterior temperature.
In the event of a fault, refer to the interpretation of DF001 Coolant temperature sensor circuit.
Parameter PR059 Air inlet temperature ≈ PR064 engine cold.
Conformity check with engine running, engine coolant temperature > 80°C
With the engine running at idle speed the coolant temperature varies according to the engine temperature.
In the event of a fault, refer to the interpretation of DF001 Coolant temperature sensor circuit.
EDC16C36_V44_PR064/EDC16C36_V4C_PR064/EDC16C36_V48_PR064/EDC16C36_V50_PR064/EDC16C36_V54_PR064/
EDC16C36_V58_PR064EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-308V9 MR-372-J84-13B450$152.mif
DIESEL INJECTION
Fault finding – Interpretation of parameters13B
PR132AIR FLOW
PARAMETER
DEFINITIONThis parameter indicates the inlet air flow in kg/h.
NOTESSpecial notes:
Only perform these tests if the parameters do not correspond with the system
operation programming.
No faults must be present.
Perform this fault finding procedure:
– after finding an inconsistency in the parameter,
– or after a customer complaint (lack of power, smoke etc.).
Use the Mégane II ph2, Scénic II ph2 Wiring Diagram Technical Note.
Conformity check with engine stopped and ignition on
PR132 = 0 kg/h
Conformity check with engine running, engine coolant temperature > 80°C
PR132 ≈ 60 kg/h
EDC16C36_V44_PR132/EDC16C36_V4C_PR132/EDC16C36_V48_PR132/EDC16C36_V50_PR132/EDC16C36_V54_PR132/
EDC16C36_V58_PR132
AFTER REPAIRCarry out a road test, then check with the diagnostic tool.
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-367
AFTER REPAIRRepeat the conformity check in the interpretation of statuses and parameters
V9 MR-372-J84-13B450$170.mif
DIESEL INJECTION
Fault finding – Interpretation of commands13B
AC004TURBOCHARGING SOLENOID VALVE
NOTESPerform this fault finding procedure:
– following interpretation of an unresolved fault or
– after processing the interpretation of PR041 Turbocharging pressure or
– after a customer complaint (loss of power, smoke etc.).
Ignition on and engine stopped.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
1. The following procedure is for checking that the turbocharger and its control circuit are working
properly.
Check the sealing of the high pressure air circuit, run test 3 Low pressure circuit check
Pipe not joined or pierced, pressure sensor disconnected or poorly fitted (seal present), exchanger pierced.
To test the exchanger: stabilise the engine speed between 3500 and 4000 rpm with the vehicle stopped and check
that there are no leaks.
Measure the resistance of the turbocharging pressure solenoid valve between the following connections:
– Connection code 3MG,
– Connection code 3FB,
of component 1475.
Replace the solenoid valve if its resistance is not: 20 Ω ± 2 at +23°C.
Check the continuity, insulation, and the absence of interference resistance on the following connections:
– Connection code 3MG between components 1475 and 120.
– Connection code 3FB between components 1475 and 983.
Run command AC004, if a faint whistling noise is heard along with a clicking from the solenoid valve, go to step
2, otherwise check the operation of the computer output stage:
Vehicle under + after ignition feed, clear the faults displayed by the diagnostic tool.
With the voltmeter in the direct current position:
With the turbocharging solenoid valve connected, connect the voltmeter earth lead to connection 3MG of
component 1475 and the positive lead to connection3FB.
Run command AC004, the voltmeter should display four successive voltages of 2.4 V ± 0.2 V.
If the measurement is not correct, contact the Techline.
EDC16C36_V44_AC004/EDC16C36_V4C_AC004/EDC16C36_V48_AC004/EDC16C36_V50_AC004/EDC16C36_V54_AC004/
EDC16C36_V58_AC004EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-369
AFTER REPAIRRepeat the conformity check in the interpretation of statuses and parameters
V9 MR-372-J84-13B450$170.mif
DIESEL INJECTION
Fault finding – Interpretation of commands13B
AC011RAIL PRESSURE REGULATOR
NOTESPerform this fault finding procedure:
– following interpretation of an unresolved fault
– following an inconsistency recorded in the parameters,
– following a customer complaint (starting problems, engine speed instability, injection
noise).
Ignition on and engine stopped.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
Step 1
Check the continuity and absence of interference resistance on the following connections:
– Connection code 3HI between components 1105 and 120.
– Connection code 3FB between components 1105 and 983.
Run command AC011. If there is a slight whistling noise and clicking from the pressure regulator, go to step 2,
otherwise, check that the computer output stage is operating correctly:
Vehicle under + after ignition feed, clear the faults displayed by the diagnostic tool.
With the voltmeter in the direct current position:
With the pressure regulator connected, connect the voltmeter earth lead to connection 3HI of component 1105
and the positive lead to connection 3FB.
Run command AC011; the voltmeter should display four successive voltages of 2.2 V ± 0.2 V.
If the measurement is not correct, contact the Techline.
STEP 2
EDC16C36_V44_AC011/EDC16C36_V4C_AC011/EDC16C36_V48_AC011/EDC16C36_V50_AC011/EDC16C36_V54_AC011/
EDC16C36_V58_AC011EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58
