2011 Ram 3500 Diesel Supplement

Maintenance Log and Service Chart (Diesel Engines)
Noise Systems Maintenance Chart and Service Log — Insert Month, Day, Year under column mileage closest to
the mileage at which service was performed.
MILES 7,500 15,000 22,500 30,000 37,500 45,000 52,500 60,000
KILOMETERS 12 000 24 000 36 000 48 000 60 000 72 000 84 000 96 000
Exhaust
system-inspect
Air cleaner
assembly-
inspect
ODOMETER
READING
PERFORMED
BY
PERFORMED
AT
128 MAINTAINING YOUR VEHICLE

Noise Systems Maintenance Chart and Service Log — Insert Month, Day, Year under column mileage closest to
the mileage at which service was performed.
MILES 67,500 75,000 82,500 90,000 97,500 105,000 112,500 120,000
KILOMETERS 108 000 120 000 132 000 144 000 156 000 168 000 180 000 192 000
Exhaust
system-inspect
Air cleaner
assembly-
inspect
ODOMETER
READING
PERFORMED
BY
PERFORMED
AT
6
MAINTAINING YOUR VEHICLE 129

FLUID CAPACITIES
U.S.Metric
Fuel (Approximate)
2500/3500 Shortbed Models 34 Gallons129 Liters
2500/3500 Longbed Models 35 Gallons132 Liters
Standard Rear Tank – Chassis Cab Only 52 Gallons197 Liters
Optional Midship Tank – Chassis Cab Only 22 Gallons83 Liters
Diesel Exhaust Fluid Tank (Approximate) – Chassis
Cab Only 8 Gallons
30 Liters
Engine Oil with Filter
6.7L Turbo Diesel Engine 12 Quarts11.4 Liters
Cooling System
6.7L Turbo Diesel Engine (MOPAR Engine Coolant/
Antifreeze 5 Year/100,000 Mile Formula or equivalent) 5.7 Gallons
21.4 Liters
130 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
ComponentFluid, Lubricant, or Genuine Part
Engine Coolant MOPARAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy-
brid Organic Additive Technology) or equivalent.
Engine Oil In ambient temperatures below 0°F (-18°C), 5W-40 syntheticengine oil
that meets Chrysler Materials Standard MS-10902 and the API CJ-4 engine
oil category is required. In ambient temperatures above 0°F (-18°C),
15W-40 engine oil that meets Chrysler Materials Standard MS-10902 and
the API CJ-4 engine oil category is required.
Engine Oil Filter MOPAREngine Oil Filter or equivalent.
Engine Fuel Filter MOPARFuel Filter or equivalent. Must meet 5 micron rating. Using a
fuel filter that does not meet the manufacturers filtration and water
separating requirements can severely impact fuel system life and reli-
ability.
Crankcase Ventilation Filter MOPAR CCV Filter or equivalent.
6
MAINTAINING YOUR VEHICLE 131

ComponentFluid, Lubricant, or Genuine Part
Fuel Selection Use good quality diesel fuel from a reputable supplier in your vehicle.
Federal law requires that you must fuel this vehicle with Ultra Low Sul-
fur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use
of Low Sulfur Highway Diesel fuel (500 ppm Sulfur maximum) to avoid
damage to the emissions control system. For most year-round service, No.
2 diesel fuel meeting ASTM specification D-975 Grade S15 will provide
good performance. If the vehicle is exposed to extreme cold (below 20°F
or -7°C), or is required to operate at colder-than-normal conditions for
prolonged periods, use climatized No. 2 diesel fuel or dilute the No. 2
diesel fuel with 50% No. 1 diesel fuel. This will provide better protection
from fuel gelling or wax-plugging of the fuel filters. This vehicle is fully
compatible with biodiesel blends up to 5% biodiesel meeting ASTM
specification D-975.
Diesel Exhaust Fluid – Chassis Cab
Only MOPAR
Diesel Exhaust Fluid (API Certified) (DEF) or equivalent that
has been API Certified to the ISO 22241 standard. Use of fluids not API
Certified to ISO 22241 may result in system damage.
132 MAINTAINING YOUR VEHICLE

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission – If
Equipped (Six-Speed 68RFE) – Ram
Truck Only MOPAR
ATF+4Automatic Transmission Fluid or equivalent licensed
ATF+4 product.
Automatic Transmission – If
Equipped (Six-Speed AS68RC) –
Chassis Cab Only MOPAR
AS68RC Automatic Transmission Fluid or equivalent.
Clutch Linkage MOPARMulti-Purpose Grease, NLGI Grade 2 E.P. or equivalent.
Manual Transmission (G-56) – If
Equipped MOPAR
ATF+4Automatic Transmission Fluid or equivalent licensed
ATF+4 product.
6
MAINTAINING YOUR VEHICLE 133

MAINTENANCE SCHEDULES
CONTENTS
Maintenance Schedule .................. 136
▫ Oil Change Indicator System ............ 137▫
Perform Service Indicator .............. 138
▫ Required Maintenance Intervals .......... 138
7
