P0703 BRAKE SWITCH B ............................. ...60
Description ........................................................... ...60
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
60
On Board Diagnosis Logic ......................................60
Possible Cause .......................................................60
DTC Confirmation Procedure .................................60
Diagnosis Procedure ..............................................60
P0705 TRANSMISSION RANGE SWITCH A ....62
Description ..............................................................62
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
62
On Board Diagnosis Logic ......................................62
Possible Cause .......................................................62
DTC Confirmation Procedure .................................62
Wiring Diagram - CVT - TR/SW ..............................63
Diagnosis Procedure ..............................................64
Component Inspection ............................................65
P0710 TRANSMISSION FLUID TEMPERA-
TURE SENSOR A ..............................................
67
Description ........................................................... ...67
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
67
On Board Diagnosis Logic ......................................67
Possible Cause .......................................................67
DTC Confirmation Procedure .................................67
Wiring Diagram - CVT - FTS ...................................68
Diagnosis Procedure ..............................................69
Component Inspection ............................................70
P0715 INPUT SPEED SENSOR A ....................72
Description ........................................................... ...72
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
72
On Board Diagnosis Logic ......................................72
Possible Cause .......................................................72
DTC Confirmation Procedure .................................72
Wiring Diagram - CVT - PRSCVT ...........................73
Diagnosis Procedure ..............................................74
P0720 OUTPUT SPEED SENSOR ....................76
Description ........................................................... ...76
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
76
On Board Diagnosis Logic ......................................76
Possible Cause .......................................................76
DTC Confirmation Procedure .................................76
Wiring Diagram - CVT - SESCVT ...........................77
Diagnosis Procedure ........................................... ...78
P0725 ENGINE SPEED .....................................81
Description ........................................................... ...81
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
81
On Board Diagnosis Logic ......................................81
Possible Cause .......................................................81
DTC Confirmation Procedure .................................81
Diagnosis Procedure ..............................................81
P0730 INCORRECT GEAR RATIO ...................83
Description ........................................................... ...83
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
83
On Board Diagnosis Logic ......................................83
Possible Cause .......................................................83
DTC Confirmation Procedure ..................................83
Diagnosis Procedure ...............................................83
P0740 TORQUE CONVERTER .........................84
Description ........................................................... ...84
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
84
On Board Diagnosis Logic ......................................84
Possible Cause .......................................................84
DTC Confirmation Procedure ..................................84
Wiring Diagram - CVT - TCV ..................................85
Diagnosis Procedure ...............................................86
Component Inspection ............................................87
P0744 TORQUE CONVERTER .........................89
Description ........................................................... ...89
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
89
On Board Diagnosis Logic ......................................89
Possible Cause .......................................................89
DTC Confirmation Procedure ..................................89
Diagnosis Procedure ...............................................89
P0745 PRESSURE CONTROL SOLENOID A ...91
Description ........................................................... ...91
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
91
On Board Diagnosis Logic ......................................91
Possible Cause .......................................................91
DTC Confirmation Procedure ..................................91
Wiring Diagram - CVT - LPSV ................................92
Diagnosis Procedure ............................................ ...93
Component Inspection ............................................94
P0746 PRESSURE CONTROL SOLENOID A ...96
Description ........................................................... ...96
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
96
On Board Diagnosis Logic ......................................96
Possible Cause .......................................................96
DTC Confirmation Procedure ..................................96
Diagnosis Procedure ...............................................96
P0776 PRESSURE CONTROL SOLENOID B ...98
Description ........................................................... ...98
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ...
98
On Board Diagnosis Logic ......................................98
Possible Cause .......................................................98
DTC Confirmation Procedure ..................................98
Diagnosis Procedure ...............................................98
P0778 PRESSURE CONTROL SOLENOID B ..100
Description ........................................................... .100
Revision: May 2010 2011 Versa

CVT-4
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
135
Wiring Diagram - CVT - ODSW .............................136
Diagnosis Procedure .............................................136
Component Inspection ...........................................138
SHIFT POSITION INDICATOR CIRCUIT ........140
Description ........................................................... ..140
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
140
Diagnosis Procedure .............................................140
TROUBLE DIAGNOSIS FOR SYMPTOMS .....141
Wiring Diagram - CVT - NONDTC ....................... ..141
O/D OFF Indicator Lamp Does Not Come On .......143
Engine Cannot Be Started in "P" and "N" Position ..145
In "P" Position, Vehicle Moves Forward or Back-
ward When Pushed ...............................................
145
In "N" Position, Vehicle Moves ............................ ..146
Large Shock "N" → "R" Position .......................... ..146
Vehicle Does Not Creep Backward in "R" Position ..147
Vehicle Does Not Creep Forward in "D" or "L" Po-
sition ......................................................................
148
Vehicle Speed Does Not Change in "L" Position ...149
Vehicle Speed Does Not Change in overdrive-off
mode ......................................................................
150
Vehicle Speed Does Not Change in "D" Position ..151
Vehicle Does Not Decelerate by Engine Brake .....151
CVT SHIFT LOCK SYSTEM ........................... .153
Description ........................................................... ..153
Shift Lock System Electrical Parts Location ..........154
Wiring Diagram - CVT - SHIFT ..............................155
Diagnosis Procedure .............................................155
TCM ..................................................................159
Removal and Installation ..................................... ..159
SHIFT CONTROL SYSTEM ............................160
Removal and Installation ..................................... ..160
CVT Shift Selector Disassembly and Assembly ....163
Shift Selector Handle Removal and Installation ....163
Adjustment of CVT Position ................................. ..164
Checking of CVT Position ......................................164
KEY INTERLOCK CABLE ...............................166
Removal and Installation ..................................... ..166
PRIMARY SPEED SENSOR ...........................169
Exploded View ..................................................... ..169
Removal and Installation .......................................169
Inspection ............................................................. .169
SECONDARY SPEED SENSOR ......................170
Exploded View ..................................................... .170
Removal and Installation .......................................170
Inspection ............................................................. .170
AIR BREATHER HOSE ....................................171
Removal and Installation .......................................171
OIL PAN .......................................................... ..172
Exploded View ..................................................... .172
Removal and Installation .......................................172
Inspection ............................................................. .173
DIFFERENTIAL SIDE OIL SEAL .....................174
Removal and Installation .......................................174
CVT OIL WARMER SYSTEM ......................... ..175
WATER HOSE ........................................................ .175
WATER HOSE : Exploded View ...........................175
WATER HOSE : Removal and Installation ...........175
WATER HOSE : Inspection ..................................176
CVT FLUID COOLER HOSE .................................. .176
CVT FLUID COOLER HOSE : Exploded View .....177
CVT FLUID COOLER HOSE : Removal and In-
stallation ................................................................
177
CVT FLUID COOLER HOSE : Inspection .............179
CVT OIL WARMER ................................................ .179
CVT OIL WARMER : Exploded View ....................179
CVT OIL WARMER : Removal and Installation ....179
CVT OIL WARMER : Inspection .......................... .179
TRANSAXLE ASSEMBLY ...............................180
Removal and Installation .......................................180
SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................. ..
183
General Specification ........................................... .183
Vehicle Speed When Shifting Gears .....................183
Stall Speed ............................................................183
Line Pressure ........................................................183
Solenoid Valves ....................................................184
CVT Fluid Temperature Sensor ............................184
Primary Speed Sensor ..........................................184
Secondary Speed Sensor .................................... .184
Removal and Installation .......................................184
Revision: May 2010 2011 Versa

INDEX FOR DTCCVT-5
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
SERVICE INFORMATION
INDEX FOR DTC
Alphabetical IndexINFOID:0000000005928718
NOTE:
If DTC “U1000” is displayed with other DTCs, fi rst perform the trouble diagnosis for DTC “U1000”.
Refer to CVT-56
.
*1: These numbers are prescribed by SAE J2012.
*2: Models without ABS does not indicate.
DTC No. IndexINFOID:0000000005928719
NOTE:
If DTC “U1000” is displayed with other DTCs, fi rst perform the trouble diagnosis for DTC “U1000”.
Refer to CVT-56
.
Items
(CONSULT-III screen terms) DTC
Reference page
OBD-II
Except OBD-II
CONSULT-III GST*
1 CONSULT-III only
“TRANSMISSION”
BRAKE SWITCH B —P0703 CVT-60
CAN COMM CIRCUIT U1000 U1000 CVT-56
CONTROL UNIT (CAN)—U1010 CVT-59
ENGINE SPEED —P0725 CVT-81
FLUID PRESS LOW —P0868C V T- 111
FLUID PRESS SEN/SW A P0840P0840CVT-105
FLUID PRESS SEN/SW A —P0841CVT-109
FLUID TEMP SENSOR A P0710P0710CVT-67
INCORRECT GR RATIO —P0730 CVT-83
INPUT SPEED SENSOR A P0715P0715CVT-72
LINE PRESS CONTROL —P1745CVT-128
OUTPUT SPEED SENSOR P0720P0720CVT-76
PC SOLENOID A P0745P0745CVT-91
PC SOLENOID A P0746P0746CVT-96
PC SOLENOID B P0776P0776CVT-98
PC SOLENOID B P0778P0778CVT-100
SLCT SOLENOID P1740P1740CVT-124
SPEED SENSOR —P1723CVT-121
STEP MOTOR P1777P1777CVT-129
STEP MOTOR P1778P1778CVT-133
TCM —P1701CVT-113
THROTTLE CONTROL SIG —P1726CVT-123
T/M RANGE SENSOR A P0705P0705CVT-62
TORQUE CONVERTER P0740P0740CVT-84
TORQUE CONVERTER P0744 P0744 CVT-89
TP SENSOR —P1705CVT-117
VEHICLE SPEED*2— P1722CVT-119
Revision: May 2010 2011 Versa

CVT-6
< SERVICE INFORMATION >[RE0F08B]
INDEX FOR DTC
*1: These numbers are pr
escribed by SAE J2012.
*2: Models without ABS does not indicate.
DTC
Items
(CONSULT-III screen terms) Reference page
OBD-II
Except OBD-II
CONSULT-III GST*
1CONSULT-III only
“TRANSMISSION”
— P0703 BRAKE SWITCH B CVT-60
P0705P0705 T/M RANGE SENSOR A CVT-62
P0710P0710 FLUID TEMP SENSOR A CVT-67
P0715P0715 INPUT SPEED SENSOR A CVT-72
P0720P0720 OUTPUT SPEED SENSOR CVT-76
—P0725 ENGINE SPEED CVT-81
—P0730 INCORRECT GR RATIO CVT-83
P0740P0740 TORQUE CONVERTER CVT-84
P0744 P0744 TORQUE CONVERTER CVT-89
P0745P0745 PC SOLENOID A CVT-91
P0746P0746 PC SOLENOID A CVT-96
P0776P0776 PC SOLENOID B CVT-98
P0778P0778 PC SOLENOID B CVT-100
P0840P0840 FLUID PRESS SEN/SW A CVT-105
—P0841 FLUID PRESS SEN/SW A CVT-109
—P0868 FLUID PRESS LOW C V T- 111
—P1701 TCM CVT-113
—P1705 TP SENSOR CVT-117
—P1722
VEHICLE SPEED*2CVT-119
— P1723 SPEED SENSOR CVT-121
—P1726 THROTTLE CONTROL SIG CVT-123
P1740P1740 SLCT SOLENOID CVT-124
—P1745 LINE PRESS CONTROL CVT-128
P1777P1777 STEP MOTOR CVT-129
P1778P1778 STEP MOTOR CVT-133
U1000U1000 CAN COMM CIRCUIT CVT-56
—U1010 CONTROL UNIT(CAN) CVT-59
Revision: May 2010 2011 Versa

CVT SYSTEMCVT-21
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
Hydraulic Control SystemINFOID:0000000005928735
TCM FunctionINFOID:0000000005928736
The function of the TCM is to:
• Receive input signals sent from various switches and sensors.
• Determine required line pressure, shifting point, and lock-up operation.
• Send required output signals to the step motor and the respective solenoids.
CONTROL SYSTEM OUTLINE
The CVT senses vehicle operating conditions through various sensors. It always controls the optimum shift
position and reduces shifting and lock-up shocks.
AWDIA0768GB
SENSORS (or SIGNAL)
⇒TCM
⇒ACTUATORS
Transmission range switch
Accelerator pedal position signal
Closed throttle position signal
Engine speed signal
CVT fluid temperature sensor
Vehicle speed signal
Overdrive control signal
Stop lamp switch signal
Primary speed sensor
Secondary speed sensor
Secondary pressure sensor Shift control
Line pressure control
Primary pressure control
Secondary pressure control
Lock-up control
Engine brake control
Vehicle speed control
Fail-safe control
Self-diagnosis
CONSULT-III co
mmunication
line
Duet-EA control
CAN system
On board diagnosis Step motor
Torque converter clutch solenoid
valve
Lock-up select solenoid valve
Line pressure solenoid valve
Secondary pressure solenoid
valve
Shift position indicator
O/D OFF indicator lamp
Starter relay
Revision: May 2010
2011 Versa

CVT SYSTEMCVT-23
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
*1: Input by CAN communications.
*2: Output by CAN communications.
*3: If these input and output signals are different, the TCM triggers the fail-safe function.
Line Pressure and Secondary Pressure ControlINFOID:0000000005928739
• When an input torque signal equivalent to the engine drive force is sent from the ECM to the TCM, the TCM
controls the line pressure solenoid valve and secondary pressure solenoid valve.
• This line pressure solenoid controls the pressure regulat or valve as the signal pressure and adjusts the pres-
sure of the operating oil discharged from the oil pump to the line pressure most appropriate to the driving
state. Secondary pressure is cont rolled by decreasing line pressure.
NORMAL CONTROL
Optimize the line pressure and secondary pressure, dependi ng on driving conditions, on the basis of the throt-
tle position, the engine speed, the primary pulley (input ) revolution speed, the secondary pulley (output) revo-
lution speed, the brake signal, the transmission range switch signal, the lock-up signal, the voltage, the target
gear ratio, the fluid temperat ure, and the fluid pressure.
FEEDBACK CONTROL
When controlling the normal fluid pressure or the sele cted fluid pressure, the secondary pressure can be set
more accurately by using the fluid pressure sensor to detect the secondary pressure and controlling the feed-
back.
Shift ControlINFOID:0000000005928740
In order to select the gear ratio which can obtain the dr iving force in accordance with driver's intention and the
vehicle condition, TCM monitors the driving conditions, such as the vehicle speed and the throttle position and
selects the optimum gear ratio, and determines the gear change steps to the gear ratio. Then send the com-
Out-
putSte p mo tor
XX
TCC solenoid valve XXX
Lock-up select solenoid valve XXX
Line pressure solenoid valve XXX X
Secondary pressure solenoid valve XX X
O/D OFF indicator signal
(*2)XX
Control item
Fluid
pressure
control Select con-
trol Shift control
Lock-up
control CAN com-
munication
control Fail-safe
function
(*3)
SCIA1846E
Revision: May 2010 2011 Versa

TROUBLE DIAGNOSISCVT-51
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O PBRAKE SWITCH B When the brake switch does not switch to ON or OFF P0703—CVT-60
T/M RANGE SEN-
SOR A When TCM does not receive the the correct voltage signal
(based on the gear position) from the switch
P0705 P0705
CVT-62
FLUID TEMP
SENSOR ADuring running, the CVT fluid temperature sensor signal volt-
age is excessively high or low
P0710 P0710
CVT-67
INPUT SPEED
SENSOR A• Primary speed sensor signal is not input due to an open cir-
cuit
• An unexpected signal is input when vehicle is being driven P0715 P0715
CVT-72
OUTPUT SPEED
SENSOR• Signal from secondary speed sensor not input due to open
or short circuit
• Unexpected signal input during running P0720 P0720
CVT-76
ENGINE SPEED• TCM does not receive the CAN communication signal from
the ECM
• Engine speed is too low while driving P0725 —
CVT-81
INCORRECT GR
RATIOUnexpected gear ratio detected
P0730—CVT-83
TORQUE CON-
VERTER Normal voltage not applied to solenoid due to open or short
circuit
P0740 P0740
CVT-84
TORQUE CON-
VERTER• CVT cannot perform lock-up even if electrical circuit is good
• TCM detects as irregular by comparing difference value
with slip rotation
• There is big difference engine speed and primary speed when TCM lock-up signal is on P0744 P0744
CVT-89
PC SOLENOID A• Normal voltage not applied to solenoid due to open or short
circuit
• TCM detects as irregular by comparing target value with monitor value P0745 P0745
CVT-91
PC SOLENOID AUnexpected gear ratio was detected in the LOW side due to
excessively low line pressure
P0746 P0746
CVT-96
PC SOLENOID BSecondary pressure is too high or too low compared with the
commanded value while driving
P0776 P0776
CVT-98
PC SOLENOID B• Normal voltage not applied to solenoid due to cut line,
short, or the like
• TCM detects as irregular by comparing target value with
monitor value P0778 P0778
CVT-100
FLUID PRESS
SEN/SW ASignal voltage of the secondary pressure sensor is too high
or too low while driving
P0840 P0840
CVT-105
FLUID PRESS
SEN/SW ASecondary fluid pressure is too high compared with the com-
manded value while driving
P0841
—CVT-109
FLUID PRESS
LOW Secondary fluid pressure is too low compared with the com-
manded value while driving
P0868
—C V T- 111
TCM • When the power supply to the TCM is cut OFF, for example
because the battery is removed, and the self-diagnosis
memory function stops
• This is not a malfunction message (Whenever shutting OFF a power supply to the TCM, this message appears on
the screen) P1701
—CVT-113
TP SENSOR TCM does not receive the proper accelerator pedal position
signals (input by CAN communication) from ECM
P1705
—CVT-117
Items (CONSULT-
III screen terms) Malfunction is detected when... TCM self-di-
agnosis OBD-III (DTC)
Reference page
“TRANSMIS-
SION” with
CONSULT-III MIL indicator
lamp*1, “EN-
GINE” with
CONSULT-III
or GST
Revision: May 2010 2011 Versa
