2011 Lancia Delta Owner handbook (in English)

Owner Handbook

Dear Customer,
We would like to congratulate and thank you for choosing LANCIA.
We have written this handbook to help you get familiar with all the features of your car.
You should read it right through before taking to the road for the first time.
It contains important information, advice and instructions for the use of the car which will help you get the very best
out of your LANCIA.
This booklet also provides a description of special features, essential information for the correct care and mainte-
nance of your LANCIA as well as safe driving tips.
Read the warnings and indications, marked with the following symbols:
personal safety;
car safety;
environmental protection.
The enclosed Warranty Booklet lists the services that LANCIA offers to its Customers:
– the Warranty Certificate with terms and conditions for maintaining its validity;
– the range of additional services available to LANCIA Customers.
We are sure that these will help you get in touch with your new car and further appreciate it and the care provided
by the people at LANCIA.
Enjoy reading and happy motoring!
This Owner Handbook describes all versions of the LANCIA Delta;
please consider only the information relevant to your version, engine and configuration.

REFUELLING
Petrol engines:exclusively refuel the car with un-
leaded petrol with a RON no lower than 95.
Diesel engines:refuel only with diesel fuel conform-
ing to the European specification EN590.
The use of other products or mixtures may damage the engine
beyond repair and consequently invalidate the warranty due
to the damage caused.
STARTING THE ENGINE
Petrol engines:make sure that the handbrake is en-
gaged, place the gear lever in neutral, fully depress the
clutch without depressing the accelerator, then turn the
ignition key to AV Vand release it as soon as the en-
gine has started.
Diesel engines:turn the ignition key to MARand wait for the
warning lights
Yandmto switch off; turn the ignition key
AVV and release it as soon as the engine starts.
PARKING ON FLAMMABLE MATERIAL
The catalytic converter develops high temperatures
during operation. Do not park the car on grass, dry
leaves, pine needles or other flammable material: fire
hazard.
RESPECTING THE ENVIRONMENT
The car is fitted with a system that allows continuous
diagnosis of the components correlated with emissions
to ensure better respect for the environment.ELECTRICAL ACCESSORIES
If, after buying the car, you decide to add electrical ac-
cessories (that may gradually drain the battery), visit
aLancia Dealership. They can calculate the overall
electrical requirement and check that the car’s elec-
tric system can support the required load.
CODE CARD
Keep the card in a safe place, not in the car. We rec-
ommend that you always carry the electronic code pro-
vided on the CODE card with you, in case you need
to perform an emergency start.
SCHEDULED SERVICING
Correct car maintenance is essential to ensure that the
performance, safety features, environmental friendli-
ness and low running costs are unchanged over the
years.
THE OWNER HANDBOOK CONTAINS…
... important information and warnings on the correct
use and maintenance of your car over time as well as
safe driving tips. Pay special attention to the symbols
"(personal safety) #(environmental protection)
â(car safety).
Refer to the “Instrument panel warning lights” chapter in this
handbook if the message “See Handbook” appears on the dis-
play.
READ THIS CAREFULLY!
K



Knowing your car
Safety
Starting and driving
In an emergency
Servicing and maintenance
Technical specifications
List of contents1
2
3
4
5
6
7
SUMMARY

page intentionally left blank

KNOWING YOUR CAR5
1
Instrument panel ........................................ 6
Control panel and instruments ................... 7
Display ...................................................... 21
Menu items ................................................ 26
Trip Computer ........................................... 36
Symbols ..................................................... 38
Lancia Code system ................................... 39
Keys ........................................................... 40
Alarm ........................................................ 43
Ignition device ........................................... 46
Seats .......................................................... 47
Headrest .................................................... 50
Steering wheel ............................................ 51
Rear view mirrors ...................................... 51
Climatic comfort ........................................ 53
Manual climate control system ................... 54
Automatic dual zone climate control system . 56
External lights ........................................... 62
Window washing ........................................ 65
Cruise Control ............................................ 68
Roof lights ................................................. 70
Controls ..................................................... 72
Fuel cut-off system .................................... 75Interior fittings ........................................... 76
Sunroof ...................................................... 81
Doors ......................................................... 84
Power windows .......................................... 87
Boot ........................................................... 91
Bonnet ....................................................... 99
Roof rack/ski rack ..................................... 101
Headlights ................................................. 102
DST system ................................................ 104
SPORT function ......................................... 104
Reactive Suspension System ....................... 106
Driving Advisor .......................................... 107
Advanced ESP system ................................ 112
Start&Stop system ..................................... 117
EOBD system ............................................. 122
“Dualdrive” electric power steering system ... 122
TPMS system ............................................. 124
Parking sensors .......................................... 127
Magic Parking ............................................ 130
Accessories purchased by the owner ........... 144
Refuelling the car ....................................... 145
Protecting the environment ........................ 148

6KNOWING YOUR CAR
INSTRUMENT PANEL
The presence and position of the controls, instruments and gauges may vary depending on the version.
1. Diffuser for sending air to the side windows – 2. Adjustable and directable air diffuser – 3. Exterior lights control
lever – 4. Instrument panel – 5. Windscreen wiper/rear window wiper/trip computer control lever – 6. Adjustable
and directable air diffusers – 7. Hazard warning lights switch – 8. Front passenger air bag – 9. Glove compartment
10. Controls in the dashboard – 11. Climate control system controls – 12. Ignition key and starting device – 13. Dri-
ver’s air bag – 14. Driver’s knee bag (for versions/markets, where provided) – 15. Steering wheel locking lever
16. Fuse box access flap – 17. Bonnet release lever.
fig. 1L0E0001m

1
KNOWING YOUR CAR7
CONTROL PANEL AND INSTRUMENTS
Versions with multifunction display
A Speedometer (speed indicator)
B Fuel gauge with reserve warning light
C Engine coolant temperature gauge with overheating warning light
D Rev counter
E Multifunction display
mcWarning lights present on diesel versions only.
IMPORTANT The type and background colour of the instruments can vary between different versions.
L0E0002mfig. 2
