2011 KIA CEED Owners Manual

85
Specifications & Consumer information
RECOMMENDED LUBRICANTS AND CAPACITIES
To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct
lubricants also help promote engine efficiency that results in improved fuel economy.
* 1
Refer to the recommended SAE viscosity numbers on the next page.
* 2
Engine oils labeled Energy Conserving Oil are now available. Along with other additional benefits, they contribute to fuel econo my by reducing the amount
of fuel necessary to overcome engine friction. Often, these improvements are difficult to measure in everyday driving, but in a year’s time, they can offer
significant cost and energy savings.
* 3
If the API service SM engine oil is not available in your country, you are able to use API service SL.
LubricantVolumeClassification
Engine oil *1 *2
(drain and refill) Recommends
- For Europe
Gasoline Engine
1.4L/1.6L3.3 l(3.5 US qt.)For Europe
API Service SM, ACEA A3 or above
Use the engine oils approved by KIA Motors.
Consult an authorized KIA dealer for details.
Except Europe
API Service SM* 3
, ILSAC GF-4 or above
2.0L4.0 l(4.2 US qt.)
Diesel Engine5.3 l(5.6 US qt.)With DPF (Diesel Particulate filter) ; ACEA C3
Without DPF (Diesel Particulate filter)
; API Service CH-4 or above, ACEA B4
Manual transaxle fluidGasoline Engine1.9 l(2.0 US qt.)API GL-4
SAE 75W-85 (fill for-life)
Diesel Engine1.9 l(2.0 US qt.)
Automatic transaxle fluid1.4L/1.6L6.8 l(7.2 US qt.)DIAMOND ATF SP-III,
SK ATF SP-III
2.0L6.6 l(6.9 US qt.)
Coolant
Gasoline
Engine1.4L/1.6L5.8~5.9 l(6.1~6.2 US qt.)
Ethylene glycol base for aluminum radiator 2.0L6.2~6.3 l(6.6~6.7 US qt.)
Diesel Engine6.3 l(6.7 US qt.)
Brake/Clutch fluid0.7~0.8 l(0.7~0.8 US qt.) FMVSS116 DOT-3 or DOT-4
Fuel53 l(14 US gal)-
ED(FL) ENG 8.QXP 10/28/2010 6:03 PM Page 5

Specifications & Consumer information
6
8
Recommended SAE viscosity
number
Engine oil viscosity (thickness) has an
effect on fuel economy and cold weather
operating (engine start and engine oil
flowability). Lower viscosity engine oils can
provide better fuel economy and cold
weather performance, however, higher vis-
cosity engine oils are required for satisfac-
tory lubrication in hot weather. Using oils of
any viscosity other than those recom-
mended could result in engine damage.
When choosing an oil, consider the range
of temperature your vehicle will be operat-
ed in before the next oil change. Proceedto select the recommended oil viscosity
from the chart.
CAUTION
Always be sure to clean the area
around any filler plug, drain plug, ordipstick before checking or drain-ing any lubricant. This is especially
important in dusty or sandy areas and when the vehicle is used onunpaved roads. Cleaning the plugand dipstick areas will prevent dirt
and grit from entering the engine and other mechanisms that couldbe damaged.
* 1
: For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE
0W-40, 5W-30, 5W-40 (API Service SM / ACEA A3 or above).
* 2
: For better fuel economy, it is recommended to use the engine oil of a viscosity grade SAE
5W-20,5W-30 (API SM / ILSAC GF-3 or above). However, if the engine oil is not available in
your country, select the proper engine oil using the engine oil viscosity chart.
* 3
: In Middle East, do not use the engine oil of viscosity grade SAE 5W-20.
* 4
: If your vehicle follows 30,000 km/ 1 year interval in normal maintenance schedule, use the
engine oil of viscosity grade, SAE 5W-30/40 or SAE 0W-30/40.
Temperature Range for SAE Viscosity Numbers
Temperature
Gasoline
Engine Oil * 1
(For Europe) °C
(°F)-30 -20 -10 0 10 20 30 40 50 -10 0 20 40 60 80 100 120
Diesel
Engine Oil * 45W-30
15W-40
10W-30
5W-40
0W-40, 5W-30, 5W-40
Gasoline
Engine Oil * 2
(Except Europe)20W-50
10W-30
15W-40
5W-20* 3
, 5W-30
0W-30, 0W-40
ED(FL) ENG 8.QXP 10/28/2010 6:03 PM Page 6

87
Specifications & Consumer information
The vehicle identification number (VIN) is
the number used in registering your car
and in all legal matters pertaining to its
ownership, etc.
The number is punched on the floor
under the passenger seat. To check the
number, remove the cover (1).VIN label (if equipped)
The VIN is also on a plate attached to the
top of the dashboard. The number on theplate can easily be seen through the
windshield from outside.The vehicle certification label attached
on the driver’s (or front passenger’s) side
center pillar gives the vehicle identifica-
tion number (VIN).
VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION
LABEL (IF EQUIPPED)
OED056002
OED056004 OED056005
OED056001
Type A
OED056003
Type B (if equipped)Identification label (if equipped)
Compliance label (if equipped)
VIN bar code (if equipped)
ED(FL) ENG 8.QXP 10/28/2010 6:04 PM Page 7

The tires supplied on your new vehicle
are chosen to provide the best perform-
ance for normal driving.
The tire label located on the driver's side
center pillar gives the tire pressures rec-
ommended for your car.
88
Specifications & Consumer information
OED056006
TIRE SPECIFICATION AND PRESSURE LABEL
1.4L/1.6L Gasoline engine
OFD087004/OFD087005
2.0L Gasoline engine
ENGINE NUMBER
Diesel engine
Type B
Type A
The engine number is stamped on the engine block as shown in the drawing. OFD087006/OFD081006
ED(FL) ENG 8.QXP 10/28/2010 6:04 PM Page 8

IIndex
ED(FL) Index.qxp 6/28/2010 11:04 AM Page 1

Index
2
I
Air bags ···········································································3-37
Air bag warning label................................................3-58
Air bag warning light ................................................3-40
Curtain air bag ..........................................................3-50
Driver's and passenger's front air bag ......................3-43
Passenger’s front air bag ON/OFF indicator ............3-47
Passenger’s front air bag ON/OFF switch ................3-46
Side impact air bag....................................................3-48
Air cleaner·······································································7-39
Alarm system ····································································4-8
Antenna ·········································································4-104
Anti-lock brake system (ABS) ·······································5-21
Appearance care······························································7-79 Exterior care ······························································7-79
Interior care ·······························································7-84
Armrest ···········································································3-14
Ashtray ············································································4-93
Audio system ································································4-104 Antenna ···································································4-104
Aux, USB and iPod ···················································4-96
Automatic climate control system ··································4-79 Air conditioning ························································4-85
Automatic heating and air conditioning····················4-80
Manual heating and air conditioning ························4-81
Automatic transaxle ························································5-12 Shift lock system ·······················································5-15 Barrier net ·······································································4-99
Battery ·············································································7-46
Battery saver function ·····················································4-59
Before driving ···································································5-3
Bottle holders, see cup holders ·······································4-49
Brake system ···································································5-18
Anti-lock brake system (ABS) ··································5-21
Electronic stability program (ESP) ···························5-23
Hill-start assist control (HAC) ··································5-27
Parking brake ····························································5-19
Power brakes ·····························································5-18
Vehicle stability management (VSM) ······················5-26
Brakes/clutch fluid ··························································7-34
Bulb replacement ····························································7-68 Front fog light bulb replacement ······························7-72
Headlight bulb replacement ······································7-69
High mounted stop light replacement ·······················7-77
Interior light bulb replacement··································7-78
License plate light bulb replacement ························7-77
Position light bulb replacement ································7-71
Rear combination light bulb replacement ·················7-74
Rear fog light bulb replacement································7-77Side repeater light bulb replacement·························7-72
Turn signal light bulb replacement ···························7-70
Bulb wattage ·····································································8-3
AB
ED(FL) Index.qxp 6/28/2010 11:04 AM Page 2

I3
Index
Capacities (Lubricants) ·····················································8-5 Care
Exterior care ······························································7-79
Interior care ·······························································7-84
Tire care ····································································7-49
Cargo weight ···································································5-53
Center console storage ····················································4-90
Central door lock switch ·················································4-11
Changing a tire with TPMS ············································6-18
Changing tires ···································································6-8Chains Tire chains ·································································5-42
Checking tire inflation pressure ······································7-50
Child restraint system ·····················································3-26 Tether anchor system ················································3-31
ISOFIX system ·························································3-32
Child-protector rear door lock ·······································4-13
Cigarette lighter ······························································4-93
Climate control air filter ·················································7-41
Climate control system (Automatic) ·····························4-79 Air conditioning ·······················································4-85Automatic heating and air conditioning ···················4-80
Manual heating and air conditioning ·······················4-81
Climate control system (Manual) ··································4-70 Air conditioning ·······················································4-75
Climate control air filter ··········································4-78 Heating and air conditioning·····································4-71
Clothes hanger ································································4-97
Combined instrument, see instrument cluster ················4-36
Cool box··········································································4-91Coolant ···········································································7-31
Cooling fluid, see engine coolant ··································7-31
Crankcase emission control system ·······························7-85
Cruise control system ····················································5-29
Cup holder ·····································································4-94
Curtain air bag ·······························································3-50
Dashboard, see instrument cluster ·································4-36 Dashboard illumination, see instrument panel illumination ·······················································4-38
Daytime running light ·····················································4-63
Defogging (Windshield) ················································4-87
Defroster ·········································································4-69 Outside mirror defroster ············································4-69
Rear window defroster ··············································4-69
Defrosting (Windshield) ················································4-87Dimensions ······································································8-2
Displays, see instrument cluster ····································4-36Display illumination, see instrument panel illumination ·······················································4-38
Door locks ·······································································4-10 Central door lock switch ··········································4-11
C
D
ED(FL) Index.qxp 6/28/2010 11:04 AM Page 3

Index
4
I
Child-protector rear door lock ··································4-13
Super lock system ·····················································4-11
Drinks holders, see cup holders ·····································4-94
Driver's air bag ·······························································3-43
Driving at night ······························································5-38
Driving in flooded areas ················································5-39
Driving in the rain ·························································5-39
Economical operation ····················································5-35
Electric chromic mirror (ECM) ·····································4-32
Electric power steering ··················································4-30
Electronic stability program (ESP) ·································5-23
Emergency starting ··························································6-4 Jump starting ······························································6-4
Push starting ·······························································6-5
Emergency tailgate safety release ··································4-15
Emergency towing ·························································6-22
Emergency while driving ·················································6-2
Emission control system ················································7-85 Crankcase emission control system ·························7-85
Evaporative emission control system ······················7-85
Exhaust emission control system ·····························7-86
Engine compartment ················································2-4, 7-2
Engine coolant ·······························································7-31
Engine number ·································································8-8
Engine oil ·······································································7-30 Engine overheats ······························································6-6
Engine temperature gauge ·············································4-39
Engine will not start ·························································6-3
Evaporative emission control system ····························7-85
Exhaust emission control system ···································7-86Explanation of scheduled maintenance items ················7-27
Exterior care ···································································7-79
Exterior features ···························································4-103
Roof rack ································································4-103
Flat tire ·············································································6-7 Changing tires ····························································6-8
Jack and tools ·····························································6-7
Removing and storing the spare tire ··························6-8
Floor mat anchor(s) ·······················································4-97Fluid Automatic transaxle fluid ··········································7-35
Washer fluid ······························································7-37
Brakes/clutch fluid ···················································7-34
Folding the rear seat ························································3-9
Front fog light ·································································4-62
Front fog light bulb replacement ···································7-72
Front seat adjustment ························································3-4
Fuel filler lid ··································································4-23
Fuel filter(for diesel) ······················································7-38
Fuel gauge ······································································4-39
E
F
ED(FL) Index.qxp 6/28/2010 11:04 AM Page 4
