2011 INFINITI QX56 door

WCS-44
< SYMPTOM DIAGNOSIS >
THE LIGHT REMINDER WARNING DOES NOT SOUND
SYMPTOM DIAGNOSIS
THE LIGHT REMINDER WARNING DOES NOT SOUND
DescriptionINFOID:0000000006222532
Light reminder warning chime does not sound even though headlamp is illuminated.
Diagnosis ProcedureINFOID:0000000006222533
1.CHECK COMBINATION SWITCH (LIGHTING SWITCH) OPERATION
Check that the headlamps operate normally by operat ing the combination switch (lighting switch).
Do they operate normally?
YES >> GO TO 2.
NO >> Refer to EXL-113, "
Symptom Table".
2.CHECK DRIVER SIDE DOOR SWITCH SIGNAL CIRCUIT
Perform the check for the driver side door switch signal circuit. Refer to DLK-117, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK DRIVER SIDE DOOR SWITCH
Perform a unit check for the driver side door switch. Refer to DLK-119, "
Component Inspection".
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-81, "Removal and Installation".
NO >> Replace driver side door switch. Refer to DLK-254, "
Removal and Installation".
Revision: 2010 May2011 QX56

COMPONENT PARTSWW-5
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006300448
1. IPDM E/R Refer to PCS-4, "
Component Parts
Location"
2. BCM
Refer to BCS-4, "
BODY CONTROL
SYSTEM : Component Parts Loca-
tion"
3. TCM
Refer to TM-10, "
A/T CONTROL
SYSTEM : Componen t Parts Loca-
tion"
4. Light & rain sensor 5. Combination switch 6. Washer level switch
7. Washer pump 8. Headlamp washer pump 9. Headlamp washer relay
10. Front wiper motor 11. Rear wiper motor
A. Behind front fender protector (RH) B. Engine room (LH) C. Cowl top, left side of engine room
D. Back door finisher inside
JMLIA0976ZZ
Revision: 2010 May2011 QX56

WW-14
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)INFOID:0000000006349813
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
×: Applicable item
*: This item is indicated, but not used.
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on
CONSULT-III.
Diagnosis mode Function Description
Work Support Changes the setting for each system function.
Self Diagnostic Result Displays the diagnosis results judged by BCM. Refer to BCS-57, "
DTCIndex".
CAN Diag Support Monitor Monitors the reception status of CAN communication viewed from BCM. Refer to CONSULT-III opera-
tion manual.
Data Monitor The BCM input/output signals are displayed.
Active Test The signals used to activate ea ch device are forcibly supplied from BCM.
Ecu Identification The BCM part number is displayed.
Configuration  Read and save the vehicle specification.
 Write the vehicle specification when replacing BCM.
System Sub system selection item Diagnosis mode
Work Support Data Monitor Active Test
Door lock DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ×××
— AIR CONDITONER* ××
 Intelligent Key system
 Engine start system INTELLIGENT KEY
×××
Combination switch COMB SW ×
Body control system BCM ×
IVIS IMMU ×××
Interior room lamp battery saver BATTERY SAVER ×××
Back door TRUNK ×
Vehicle security system THEFT ALM ×××
RAP system RETAINED PWR ×
Signal buffer system SIGNAL BUFFER ××
Revision: 2010 May2011 QX56

WW-18
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (IPDM E/R)
DIAGNOSIS SYSTEM (IPDM E/R)
Diagnosis DescriptionINFOID:0000000006349814
AUTO ACTIVE TEST
Description
In auto active test, the IPDM E/R sends a drive signal to the following systems to check their operation.
 Oil pressure warning lamp
 Rear window defogger
 Front wiper (LO, HI)
 Parking lamp
 License plate lamp
 Tail lamp
 Side marker lamp
 Front fog lamp
 Headlamp (LO, HI)
 A/C compressor (magnet clutch)
Operation Procedure
CAUTION:
Never perform auto active test in the following conditions.
 Engine is running.
 CONSULT-III is connected.
1. Close the hood and lift the wiper arms from the windshield. (Prevent windshield damage due to wiper
operation)
NOTE:
When auto active test is performed with hood opened, sprinkle water on windshield beforehand.
2. Turn the ignition switch OFF.
3. Turn the ignition switch ON, and within 20 seconds, pr ess the driver door switch 10 times. Then turn the
ignition switch OFF.
CAUTION:
Close passenger door.
4. Turn the ignition switch ON within 10 seconds. Af ter that the horn sounds once and the auto active test
starts.
CAUTION:
Engine starts when igniti on switch is turned ON while brake pedal is depressed.
5. The oil pressure warning lamp starts blinking when the auto active test starts.
6. After a series of the following operations is repeated 3 times, auto active test is completed.
NOTE:
 When auto active test has to be cancelled halfway through test, turn the ignition switch OFF.
 When auto active test is not activated, door swit ch may be the cause. Check door switch. Refer to DLK-117,
"ComponentFunctionCheck".
Inspection in Auto Active Test
When auto active test is actuated, the following operation sequence is repeated 3 times.
Operation
sequence Inspection location Operation
1 Oil pressure warning lamp Blinks continuously during operation of auto active test
2 Rear window defogger 10 seconds
3 Front wiper LO for 5 seconds → HI for 5 seconds
4 Parking lamp
 License plate lamp
 Tail lamp
 Side marker lamp
 Front fog lamp 10 seconds
Revision: 2010 May2011 QX56

DIAGNOSIS SYSTEM (IPDM E/R)WW-19
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Concept of auto active test
 IPDM E/R starts the auto active test with the door
switch signals transmitted by BCM via CAN communica-
tion. Therefore, the CAN communication line between IPDM E/R and BCM is considered normal if the auto
active test starts successfully.
 The auto active test facilitates troubleshooting if any systems controlled by IPDM E/R cannot be operated.
Diagnosis chart in auto active test
5 Headlamp LO for 10 seconds →HI ON ⇔ OFF 5 times
6 A/C compressor (magnet clutch) ON ⇔ OFF 5 times
Operation
sequence Inspection location Operation
JMMIA0492GB
Symptom Inspection contents Possible cause
Rear window defogger does not operate Perform auto active test.
Does the rear window defog-
ger operate?YES BCM signal input circuit
NO  Rear window defogger
 Rear window defogger
ground circuit
 Harness or connector be- tween IPDM E/R and rear
window defogger
 IPDM E/R
Any of the following components do not operate
Parking lamp
 License plate lamp
Tail lamp
 Side marker lamp
 Front fog lamp
 Headlamp (HI, LO)
 Front wiper (HI, LO) Perform auto active test.
Does the applicable system
operate?YES BCM signal input circuit
NO  Lamp or motor
 Lamp or motor ground cir-
cuit
 Harness or connector be- tween IPDM E/R and appli-
cable system
 IPDM E/R
A/C compressor does not operate Perform auto active test.
Does the magnet clutch oper-
ate?YES
 A/C auto amp. signal input
circuit
 CAN communication signal
between A/C auto amp. and
ECM
 CAN communication signal
between ECM and IPDM E/
R
NO  Magnet clutch
 Harness or connector be-
tween IPDM E/R and mag-
net clutch
 IPDM E/R
Revision: 2010 May2011 QX56

WW-74
< REMOVAL AND INSTALLATION >
REAR WIPER ARM
REAR WIPER ARM
Exploded ViewINFOID:0000000006220420
Removal and InstallationINFOID:0000000006220421
REMOVAL
1. Operate rear wiper to the auto stop position.
2. Remove rear wiper arm cover.
3. Remove rear wiper arm mounting nut.
4. Remove wiper arm from the vehicle.
INSTALLATION
1. Clean wiper arm mount as shown in the figure to prevent nutfrom being loosened.
2. Operate the rear wiper motor to the auto stop position.
3. Adjust the rear wiper blade position. Refer to WW-74, "
Adjust-
ment".
4. Install the rear wiper arm by tightening the mounting nut.
5. Inject the washer fluid.
6. Operate the rear wiper to the auto stop position.
7. Check that the rear wiper blades stop at the specified position.
8. Install the rear wiper arm cover.
AdjustmentINFOID:0000000006220422
REAR WIPER BLADE POSITION ADJUSTMENT
Set the wiper blade top on the defrosting wire (A) (c learance between the end of back door glass and the top
of wiper blade center).
1. Rear wiper motor 2. Pivot seal 3. Rear wiper arm
4. Rear wiper arm cover 5. Rear wiper blade
Refer to GI-4, "
Components" for symbols in the figure.
JMLIA0942GB
SKIA0082J
Revision: 2010 May2011 QX56

WW-76
< REMOVAL AND INSTALLATION >
REAR WIPER MOTOR
REAR WIPER MOTOR
Exploded ViewINFOID:0000000006220423
Removal and InstallationINFOID:0000000006220424
REMOVAL
1. Remove rear wiper arm. Refer to WW-74, "Removal and Installation".
2. Remove back door finisher inner. Refer to INT-39, "
Removal and Installation".
3. Disconnect rear wiper motor connector.
4. Remove rear wiper motor mounting bolts.
5. Remove rear wiper motor from the vehicle.
6. Remove the pivot seal.
INSTALLATION
Install in the reverse order of removal.
1. Rear wiper motor 2. Pivot seal 3. Rear wiper arm
4. Rear wiper arm cover 5. Rear wiper blade
Refer to GI-4, "
Components" for symbols in the figure.
JMLIA0942GB
Revision: 2010 May2011 QX56
