Page 4409 of 5598
DESCRIPTIONSCS-49
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
SYSTEM DESCRIPTION
DESCRIPTION
DescriptionINFOID:0000000006256039
Corrects sinkage of vehicle rear that occurs in laden or towing conditions.
Maintains vehicle height at a constant level and improv es riding comfort by charging or discharging air in air
chamber of rear shock absorber, according to signal from vehicle height sensor installed to rear suspension.
Revision: 2010 May2011 QX56
Page 5072 of 5598
STR-4
< PREPARATION >
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000006275531
Commercial Service ToolsINFOID:0000000006275532
Tool number
(Kent-Moore No.) Tool name Description
—
(J-44373 Model MCR620)
Starting/Charging System Tester Tests starting and charging systems.
For operating instructio
ns, refer to Technical
Service Bulletin.
SEL403X
Tool name Description
Power tool Loosening bolts, nuts and screws
PIIB1407E
Revision: 2010 May2011 QX56
Page 5080 of 5598

STR-12
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORKFLOW
NOTE:
To ensure a complete and thorough diagnosis, the battery, starter motor and alternator test segments must be
done as a set from start to finish.
1.DIAGNOSIS WITH STARTING /CHARGING SYSTEM TESTER
Perform the starting system test with Starting/Char ging System Tester (SST: J-44373). For details and operat-
ing instructions, refer to Technical Service Bulletin.
Te s t r e s u l t
CRANKING VOLTAGE NORMAL>>GO TO 2.
CRANKING VOLTAGE LOW>>GO TO 5.
CHARGE BATTERY>>Perform the slow battery charging procedure. (Initial rate of charge is 10A for 12
hours.) Perform battery test again. Re fer to Technical Service Bulletin.
REPLACE BATTERY>>Before replacing battery, clean t he battery cable clamps and battery posts. Perform
battery test again. Refer to Technical Service Bu lletin. If second test result is “REPLACE BAT-
TERY”, then do so. Perform battery test again to confirm repair.
2.CRANKING CHECK
Check that the starter motor operates correctly.
Does the engine crank normally?
YES >> GO TO 3.
NO >> GO TO 4.
3.ENGINE START CHECK
Check that the engine starts.
Does the engine start?
YES >> Starter motor is OK. INSPECTION END
NO >> Perform further diagnosis of engine mechanical or engine control system. Refer EM and EC sec-
tions. Once resolved, perform battery test again.
4.STARTER MOTOR ACTIVATION
Check that the starter motor operates.
Does the starter motor turn?
YES >> Check ring gear and starter motor drive pinion. Once resolved, perform battery test again.
NO >> GO TO 7.
5.COMPARISON BETWEEN ENGINE COOLANT AND CRANKING VOLTAGE
Compare the engine coolant temperature and the cranking voltage with the specifications.
Minimum Specification of Cranking Voltage Referencing Coolant Temperature
Is the voltage less than the specified value?
YES >> GO TO 7.
NO >> GO TO 6.
6.STARTER OPERATION
Check the starter operation status.
Does the starter motor turn smoothly?
YES >> Starter motor is OK. INSPECTION END
NO >> GO TO 7.
7.“B” TERMINAL CIRCUIT INSPECTION
Check “B” terminal circuit. Refer to STR-14, "
Diagnosis Procedure".
Is
“B” terminal circuit normal?
Engine coolant temperature [ °C ( °F)] Voltage [V]
− 30 to −20 ( −22 to −4) 8.6
− 19 to −10 ( −2 to 14) 9.1
− 9 to 0 (16 to 32) 9.5
More than 1 (More than 34) 9.9
Revision: 2010 May2011 QX56
Page 5097 of 5598
PREPARATIONTM-9
< PREPARATION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Commercial Service ToolINFOID:0000000006226737
*: Always check with the Parts Department for the latest parts information. Tool name
Description
Power tool Loosening bolts and nuts
Drift
a: 22 mm (0.87 in) dia. Installing manual shaft oil seals
Drift
a: 64 mm (2.52 in) dia. Installing rear oil seal (4WD)
Pin punch
a: 4 mm (0.16 in) dia. Remove retaining pin
1. 315268E000* O-ring
2. 310811EA5A*
Charging pipe A/T fluid changing and adjustment
PBIC0190E
NT083
SCIA5338E
NT410
JSDIA1332ZZ
Revision: 2010 May2011 QX56
Page 5182 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-94
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
A/T FLUID
ChangingINFOID:0000000006226791
CAUTION:
Use only Genuine NISSAN Matic S ATF. Never mix with other ATF.
Using ATF other than Genuine N INFINITI QX56 2011 Factory Service Manual
TM-94
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
A/T FLUID
ChangingINFOID:0000000006226791
CAUTION:
Use only Genuine NISSAN Matic S ATF. Never mix with other ATF.
Using ATF other than Genuine N](/manual-img/42/57033/w960_57033-5181.png)
TM-94
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
A/T FLUID
ChangingINFOID:0000000006226791
CAUTION:
Use only Genuine NISSAN Matic S ATF. Never mix with other ATF.
Using ATF other than Genuine NI
SSAN Matic S ATF will cause deteri oration in driveability and A/T
durability, and may damage the A/T, which is not covered by the INFINITI new vehicle limited war-
ranty.
When filling ATF, be careful not to scatte r heat generating parts such as exhaust.
1. Step 1
a. Install the O-ring (315268E000) (A) to the charging pipe (310811EA5A) (B).
2. Step 2
a. Use CONSULT-III to check that the ATF temperature is 40 °C (104 °F) or less.
b. Lift up the vehicle.
c. Remove the drain plug from the oil pan, and then drain the ATF.
d. When the ATF starts to drip, temporarily tighten the drain plug to the oil pan. NOTE:
Never replace drain plug and drain plug gasket with new ones yet.
e. Remove overflow plug from oil pan.
f. Install the charging pipe (A) to the overflow plug hole. CAUTION:
Tighten the charging pipe by hand.
g. Install the bucket pump hose (B) to the charging pipe. CAUTION:
Insert the bucket pump hose all the way to the end of the
charging pipe.
h. Fill approximately 3 liters (3-1/8 US qt, 2-5/8 lmp qt) of the ATF.
i. Remove the bucket pump hose to remove the charging pipe, and then temporarily tighten the overflow plug to the oil pan.
CAUTION:
Quickly perform the procedur e to avoid ATF leakage from
the oil pan.
j. Lift down the vehicle.
k. Start the engine and wait for approximately 3 minutes.
l. Stop the engine.
3. Step 3
a. Repeat “Step 2”.
4. Final Step
a. Use CONSULT-III to check that the ATF temperature is 40 °C (104 °F) or less.
b. Lift up the vehicle.
c. Remove the drain plug from the oil pan, and then drain the ATF.
Recommended fluid and fluid capacity : Refer to TM-296, "General Specification".
JSDIA1334ZZ
JSDIA1335ZZ
Revision: 2010 May2011 QX56
Page 5183 of 5598
![INFINITI QX56 2011 Factory Service Manual
A/T FLUIDTM-95
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
d. When the ATF starts to drip, tighten the drain plug to the oil pan to the specified torque. Refer to TM-182,
"Ex INFINITI QX56 2011 Factory Service Manual
A/T FLUIDTM-95
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
d. When the ATF starts to drip, tighten the drain plug to the oil pan to the specified torque. Refer to TM-182,
"Ex](/manual-img/42/57033/w960_57033-5182.png)
A/T FLUIDTM-95
< BASIC INSPECTION > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
d. When the ATF starts to drip, tighten the drain plug to the oil pan to the specified torque. Refer to TM-182,
"Exploded View".
CAUTION:
Never reuse drain plug and drain plug gasket.
e. Remove overflow plug from oil pan.
f. Install the charging pipe (A) to the overflow plug hole. CAUTION:
Tighten the charging pipe by hand.
g. Install the bucket pump hose (B) to the charging pipe. CAUTION:
Insert the bucket pump hose all the way to the end of the
charging pipe.
h. Fill approximately 3 liters (3-1/8 US qt, 2-5/8 lmp qt) of the ATF.
i. Remove the bucket pump hose to remove the charging pipe, and then temporarily tighten the overflow plug to the oil pan.
CAUTION:
Quickly perform the procedure to avoid ATF leakage from
the oil pan.
j. Lift down the vehicle.
k. Start the engine.
l. Make the ATF temperature approximately 40 °C (104 °F).
NOTE:
The ATF level is greatly affected by the temperat ure. Always check the ATF temperature on “ATF TEMP
1” of “Data Monitor” using CONSULT-III.
m. Park vehicle on level surface and set parking brake.
n. Shift the selector lever through each gear pos ition. Leave selector lever in “P” position.
o. Lift up the vehicle when the ATF temperature reaches 40 °C (104 °F), and remove the overflow plug from
the oil pan.
CAUTION:
Perform “Step 4-o” with the engine at idle.
p. When the ATF starts to drip, tighten the overflow plug to the oil pan to the specified torque. Refer to TM-
182, "Exploded View".
CAUTION:
Never reuse overflow plug.
AdjustmentINFOID:0000000006226792
CAUTION:
Use only Genuine NISSAN Matic S ATF. Never mix with other ATF.
Using ATF other than Genuine NI SSAN Matic S ATF will cause deteri oration in driveability and A/T
durability, and may damage the A/T, which is not covered by the INFINITI new vehicle limited war-
ranty.
When filling ATF, be careful not to sca tter heat generating parts such as exhaust.
Always maintain the ATF temperature within between 35 °C (95 °F) and 45 °C (113 °F) while checking
with CONSULT-III when the ATF level adjustment is performed.
JSDIA1335ZZ
Recommended fluid and fluid capacity : Refer to TM-296, "General Specification".
Revision: 2010 May2011 QX56
Page 5184 of 5598
![INFINITI QX56 2011 Factory Service Manual
TM-96
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
1. Install the O-ring (315268E000) (A) to the charging pipe
(310811EA5A) (B).
2. Start the engine.
3. Make the ATF temperature approximately 40 °C INFINITI QX56 2011 Factory Service Manual
TM-96
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
1. Install the O-ring (315268E000) (A) to the charging pipe
(310811EA5A) (B).
2. Start the engine.
3. Make the ATF temperature approximately 40 °C](/manual-img/42/57033/w960_57033-5183.png)
TM-96
< BASIC INSPECTION >[7AT: RE7R01B]
A/T FLUID
1. Install the O-ring (315268E000) (A) to the charging pipe
(310811EA5A) (B).
2. Start the engine.
3. Make the ATF temperature approximately 40 °C (104 °F).
NOTE:
The ATF level is greatly affected by the temperature. Always
check the ATF temperature on “ATF TEMP 1” of “Data Monitor”
using CONSULT-III.
4. Park vehicle on level surface and set parking brake.
5. Shift the selector lever through each gear position. Leave selec- tor lever in “P” position.
6. Lift up the vehicle.
7. Check the ATF leakage from transmission.
8. Remove overflow plug from oil pan.
9. Install the charging pipe (A) to the overflow plug hole. CAUTION:
Tighten the charging pipe by hand.
10. Install the bucket pump hose (B) to the charging pipe. CAUTION:
Insert the bucket pump hose all the way to the end of the
charging pipe.
11. Fill approximately 0.5 liters (1/2 US qt, 1/2 lmp qt) of the ATF.
12. Check that the ATF leaks when removing the charging pipe and the bucket pump hose. If the A TF does not leak, refill the ATF.
CAUTION:
Perform “Step 12” with the engine at idle.
13. When the ATF starts to drip, tighten the overflow pl ug to the oil pan to the specified torque. Refer to TM-
182, "Exploded View".
CAUTION:
Never reuse overflow plug.
JSDIA1334ZZ
JSDIA1335ZZ
Revision: 2010 May2011 QX56
