EC-206
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0106 MANIFOLD ABSOL
UTE PRESSURE SENSOR
P0106 MANIFOLD ABSOLU TE PRESSURE SENSOR
DTC LogicINFOID:0000000006288274
DTC DETECTION LOGIC
NOTE:
If DTC P0106 is displayed with ot her DTC, first perform the trouble diagnosis for other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
If engine will not start or stops soon, wait at leas t 10 seconds with engine stopped (Ignition switch ON) instead
of running engine at idle speed.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode with CONSULT-III.
2. Start engine and warm it up to normal operating temperature.
3. Accelerate the vehicle from 0 to 88 km/h (0 to 55 MPH) under the following conditions: CAUTION:
Always drive at a safe speed.
NOTE:
 Accelerate with the accelerator pedal kept constant.
 The acceleration at engine speed 2,000 and 3,000 rpm allows easy diagnoses.
4. Check 1st trip DTC. WITHOUT CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Drive the vehicle under the following conditions.
3. With selector lever in D position, accelerate the v ehicle from 0 to 88 km/h (0 to 55 MPH) under the follow-
ing conditions:
CAUTION:
Always drive at a safe speed.
NOTE:
 Accelerate with the accelerator pedal kept constant.
 The acceleration at engine speed 2,000 and 3,000 rpm allows easy diagnoses.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0106 ABSL PRES SEN/CIRC
[Manifold absolute pressure (MAP)
circuit range/performance] A difference exceeding the specified
value develops between a value
transmitted from the manifold abso-
lute pressure (MAP) sensor to ECM
and an estimated intake pressure of
intake manifold calculated by ECM.  Harness or connectors
(The manifold absolute pressure
(MAP) sensor circuit is open or
shorted.)
 manifold absolute pressure (MAP)
sensor
 Intake air leaks
ACCEL SEN 1 1.4 – 2.0 V
Selector lever D position
Revision: 2010 May2011 QX56

P0106 MANIFOLD ABSOLUTE PRESSURE SENSOREC-207
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to
EC-207, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288275
1.CHECK INTAKE SYSTEM
Check the following for connection.
 Air duct
 Vacuum hoses
 Intake air passage between air duct and intake manifold.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK MANIFOLD ABSOLUTE PR ESSURE (MAP) SENSOR POWER SUPPLY CIRCUIT FOR OPEN
AND SHORT
1. Disconnect manifold absolute pressu re (MAP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between manifold absolute pr essure (MAP) sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR GR OUND CIRCUIT FOR OPEN AND
SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between manifold absolute pressure (MAP) sensor harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SE NSOR INPUT SIGNAL CIRCUIT FOR OPEN AND
SHORT
1. Check the continuity between manifold absolute pressure (MAP) sensor harness connector and ECM har-
ness connector.
Accelerator pedal position sensor 1 Ground Voltage (V)
Connector Terminal
E110 (Without ICC) 3
Ground 1.4 – 2.0
E67 (With ICC) 10
Manifold absolute pressure (MAP) sensor Ground Voltage (V)
Connector Terminal
F65 1 Ground Approx. 5
Manifold absolute pressure (MAP) sensor ECM Continuity
Connector Terminal Connector Terminal
F65 3 F110 70 Existed
Revision: 2010 May2011 QX56

EC-208
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0106 MANIFOLD ABSOL
UTE PRESSURE SENSOR
2. Also check harness for short to ground and power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
5.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
Refer to EC-208, "
Component Inspection (MAP Sensor)".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace manifold absolute pr essure (MAP) sensor. Refer to EM-30, "
Exploded View".
6.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspecti on (MAP Sensor)INFOID:0000000006288276
1.CHECK MAP SENSOR-I
1. Turn ignition switch OFF.
2. Start engine and warm it up to normal operating temperature.
3. Turn ignition switch OFF, wait at least 5 seconds and then turn ON.
4. Check the voltage between ECM harness connector terminals as follows.
NOTE:
 To avoid the influence of intake manifold vacuum, check the voltage 1 or more minutes past after engine
is stopped.
 Because the sensor is absolute pressure sens or, output value may differ depending on atmospheric
pressure and altitude.
5. Measure the atmospheric pressure. NOTE:
As the atmospheric pressure described on the synoptic chart is the value at sea level, compensate the
pressure with the following chart.
6. Check the manifold absolute pressure sensor value corresponding to the atmospheric pressure.
Manifold absolute pressure (MAP) sensor ECM
Continuity
Connector Terminal Connector Terminal
F65 2 F110 67 Existed
ECM
+–
Connector Terminal Connector Terminal F110 67 F110 70
Altitude (m) Compensated pressure (hPa)00
200 -24
400 -47
600 -70
800 -92
1000 -114
1500 -168
2000 -218
Revision: 2010 May2011 QX56

P0106 MANIFOLD ABSOLUTE PRESSURE SENSOREC-209
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace MAP sensor.
2.CHECK MAP SENSOR-II
1. Start engine and let it idle.
2. Check intake manifold vacuum.
3. Check the voltage between ECM harness connector terminals as per the following.
4. Confirm the difference of the voltage when engine is stopped and at idling is within the values shown in the following chart.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace MAP sensor.
Atmospheric pressure (hPa) Voltage (V)
800 3.1 – 3.7
850 3.3 – 3.9
900 3.5 – 4.1
950 3.8 – 4.3
1000 4.0 – 4.6
1050 4.2 – 4.8
JMBIA0870GB
ECM
+–
Connector Terminal Connector Terminal F110 67 F110 70
Intake manifold vacuum [kPA (mmHg)] Voltage difference (V) -40 (-300) 1.5 – 2.0
-53.3 (-400) 2.0 – 2.6
-66.7 (-500) 2.6 – 3.2 -80 (-600) 3.2 – 3.8
Revision: 2010 May2011 QX56

EC-210
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P010A MANIFOLD ABSOL
UTE PRESSURE SENSOR
P010A MANIFOLD ABSOLUTE PRESSURE SENSOR
DTC LogicINFOID:0000000006217792
DTC DETECTION LOGIC
NOTE:
If DTC P010A is displayed with DTC P0643, first perform the trouble diagnosis for DTC P0643.
Refer to EC-381, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 10 seconds.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-210, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217793
1.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR POWER SUPPLY CIRCUIT
1. Disconnect manifold absolute pressu re (MAP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between manifold absolute pr essure (MAP) sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR GROUND CIRCUIT FOR OPEN AND
SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between manifold absolute pressure (MAP) sensor harness connector and ECM har-
ness connector.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P010A ABSL PRES SEN/CIRC
[Manifold absolute pressure (MAP)
sensor circuit]  An excessively low voltage from
the sensor is sent to ECM.
 An excessively high voltage from the sensor is sent to ECM.  Harness or connectors
(Manifold absolute pressure sen-
sor circuit is shorted.)
 Manifold absolute pressure sensor
Manifold absolute pressure (MAP) sensor Ground Voltage (V)
Connector Terminal
F65 1 Ground Approx. 5
Manifold absolute pressure (MAP) sensor ECM Continuity
Connector Terminal Connector Terminal
F65 3 F110 70 Existed
Revision: 2010 May2011 QX56

P010A MANIFOLD ABSOLUTE PRESSURE SENSOREC-211
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
3.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SE
NSOR INPUT SIGNAL CIRCUIT FOR OPEN AND
SHORT
1. Check the continuity between manifold absolute pressure (MAP) sensor harness connector and ECM har-
ness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
Refer to EC-211, "
Component Inspection (MAP Sensor)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace manifold absolute pressure (MAP) sensor. Refer to EM-30, "
Exploded View".
5.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (MAP Sensor)INFOID:0000000006288358
1.CHECK MAP SENSOR-I
1. Turn ignition switch OFF.
2. Start engine and warm it up to normal operating temperature.
3. Turn ignition switch OFF, wait at least 5 seconds and then turn ON.
4. Check the voltage between ECM harness connector terminals as follows.
NOTE:
 To avoid the influence of intake manifold vacuum, check the voltage 1 or more minutes past after engineis stopped.
 Because the sensor is absolute pressure sens or, output value may differ depending on atmospheric
pressure and altitude.
5. Measure the atmospheric pressure. NOTE:
As the atmospheric pressure described on the synoptic chart is the value at sea level, compensate the
pressure with the following chart.
Manifold absolute pressure (MAP) sensor ECM Continuity
Connector Terminal Connector Terminal
F65 2 F110 67 Existed
ECM
+–
Connector Terminal Connector Terminal F110 67 F110 70
Altitude (m) Compensated pressure (hPa)00
200 -24
Revision: 2010 May2011 QX56

EC-212
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P010A MANIFOLD ABSOL
UTE PRESSURE SENSOR
6. Check the manifold absolute pressure sensor value corresponding to the atmospheric pressure.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace MAP sensor.
2.CHECK MAP SENSOR-II
1. Start engine and let it idle.
2. Check intake manifold vacuum.
3. Check the voltage between ECM harness connector terminals as per the following.
4. Confirm the difference of the voltage when engine is stopped and at idling is within the values shown in
the following chart.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace MAP sensor.
400 -47
600 -70
800 -92
1000 -114
1500 -168
2000 -218
Atmospheric pressure (hPa) Voltage (V)
800 3.1 – 3.7
850 3.3 – 3.9
900 3.5 – 4.1
950 3.8 – 4.3
1000 4.0 – 4.6
1050 4.2 – 4.8
Altitude (m) Compensated pressure (hPa)
JMBIA0870GB
ECM
+–
Connector Terminal Connector Terminal F110 67 F110 70
Intake manifold vacuum [kPA (mmHg)] Voltage difference (V) -40 (-300) 1.5 – 2.0
-53.3 (-400) 2.0 – 2.6
-66.7 (-500) 2.6 – 3.2 -80 (-600) 3.2 – 3.8
Revision: 2010 May2011 QX56

P0112, P0113 IAT SENSOREC-213
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0112, P0113 IAT SENSOR
DTC LogicINFOID:0000000006217795
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-213, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217796
1.CHECK INTAKE AIR TEMPERATURE SENSOR POWER SUPPLY CIRCUIT
1. Disconnect mass air flow (MAF) sensor (intake air temperature sensor is built-in) harness connector.
2. Turn ignition switch ON.
3. Check the voltage between MAF sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
2.CHECK INTAKE AIR TEMPERATURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between MAF sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0112 IAT SEN/CIRCUIT-B1
(Intake air temperature sensor
circuit low input) An excessively low voltage from the sensor
is sent to ECM.
 Harness or connectors
(The intake air temperature sensor cir-
cuit is open or shorted.)
 Intake air temperature sensor
P0113 IAT SEN/CIRCUIT-B1
(Intake air temperature sensor
circuit high input) An excessively high voltage from the sensor
is sent to ECM.
MAF sensor
Ground Voltage (V)
Connector Terminal
F31 2 Ground Approx. 5
MAF sensor ECM Continuity
Connector Terminal Connector Terminal
F 3 1 1 F 111 2 5 E x i s t e d
Revision: 2010 May2011 QX56
