2011 INFINITI QX56 sunroof

RF-22
< DTC/CIRCUIT DIAGNOSIS >
SUNROOF SWITCH
4. Check continuity between sunroof motor assembly harness connector and ground.
Is the inspection result normal?
YES >> Replace sunroof motor assembly. Refer to RF-36, "Removal and Installation".
NO >> Repair or replace harness or connector.
5.CHECK SUNROOF SWITCH
Check sunroof switch.
Refer to RF-22, "
Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Replace sunroof switch. Refer to RF-41, "
Removal and Installation".
Component InspectionINFOID:0000000006141237
SUNROOF SWITCH
1.CHECK SUNROOF SWITCH
1. Turn ignition switch OFF.
2. Disconnect sunroof switch connector.
3. Check continuity sunroof switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace sunroof switch. Refer to RF-41, "
Removal and Installation".
Sunroof motor assembly Sunroof switch
Continuity
Connector Terminal Connector Terminal
R4 5
R16 1
Existed
10 3
Sunroof motor assembly GroundContinuity
Connector Terminal
R4 5
Not existed
10
Terminals Condition Continuity
1 2 Sunroof switch is operated
TILT DOWN or SLIDE OPEN Existed
Other than above Not existed
3 Sunroof switch is operated
TILT UP or SLIDE CLOSE Existed
Other than above Not existed
Revision: 2010 May2011 QX56

SUNROOF DOES NOT OPERATE PROPERLYRF-23
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
RF
N
O P
SYMPTOM DIAGNOSIS
SUNROOF DOES NOT OPERATE PROPERLY
DescriptionINFOID:0000000006141238
 When auto operation does not operated.
 When does not stop fully open or fully closed operation.
Diagnosis ProcedureINFOID:0000000006141239
1.PERFORM INITIALIZATION PROCEDURE
Initialization procedure is executed and operation is confirmed.
Refer to RF-17, "
ADDITIONAL SERVICE WHEN REPLACING CO NTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK SUNROOF MOTOR ASSEMBLY POWER SUPPLY AND GROUND CIRCUIT
Check sunroof motor assembly power supply and ground circuit.
Refer to RF-18, "
DiagnosisProcedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK VEHICLE SPEED SIGNAL CIRCUIT
Check vehicle speed signal circuit.
Refer to RF-20, "
DiagnosisProcedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK SUNROOF SWITCH
Check sunroof switch.
Refer to RF-21, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> GO TO 1.
Revision: 2010 May2011 QX56

RF-24
< SYMPTOM DIAGNOSIS >
SUNROOF DOES NOT OPERATE ANTI-PINCH FUNCTION
SUNROOF DOES NOT OPERATE ANTI-PINCH FUNCTION
Diagnosis ProcedureINFOID:0000000006141240
1.PERFORM INITIALIZATION PROCEDURE
Initialization procedure is exec uted and operation is confirmed.
Refer to RF-17, "
ADDITIONAL SERVICE WHEN REPLACING CO NTROL UNIT : Special Repair Require-
ment".
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace sunroof motor assembly.
Revision: 2010 May2011 QX56

SQUEAK AND RATTLE TROUBLE DIAGNOSESRF-29
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
RF
N
O P
3. Trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, se curing, or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof / headlining area can of ten be traced to one of the following items:
1. Sunroof lid, rail, linkage, or seals making a rattle or light knocking noise
2. Sunvisor shaft shaking in the holder
3. Front or rear windshield touching headlining and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
SEATS
When isolating seat noise it is important to note the position the seat is in and the load placed on the seat
when the noise occurs. These conditions should be duplic ated when verifying and isolating the cause of the
noise.
Causes of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of thes e incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component mounted to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator mounting pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move, or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs c an usually be made by moving, adjusting, securing, or
insulating the component causing the noise.
Revision: 2010 May2011 QX56

RF-32
< REMOVAL AND INSTALLATION >
GLASS LID
REMOVAL AND INSTALLATION
GLASS LID
Exploded ViewINFOID:0000000006141245
1. Glass lid 2. TORX bolt 3. Side trim
4. Rear drain connector 5. Rear drain hose 6. Sunroof bracket (LH,RH)
7. Front drain hose 8. Front drain connector 9. Sunroof motor assembly
10. Sunroof unit assembly
JMKIA5212ZZ
Revision: 2010 May2011 QX56

GLASS LIDRF-33
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
RF
N
O P
Removal and InstallationINFOID:0000000006141246
CAUTION:
 Always work with a helper.
 Fully close the glass lid, before removal, th en never operate sunroof motor after removal.
REMOVAL
1. Remove the side trims (LH, RH).
2. Remove the TORX bolts (A) and remove glass lid.
INSTALLATION
CAUTION:
After installing the glass lid, perform the leak test and check the there is no malfunction.
NOTE:
After installation carry out fitting adjustment. Refer to RF-33, "
Adjustment".
Install in the reverse order of removal.
AdjustmentINFOID:0000000006141247
Glass lid Adjustment and Surface Mismatch Adjustment
1. Remove side trims.
2. After loosening glass lid from TORX bolts (left and right).
3. Adjust glass lid from outside of vehicle so it resembles “A – A”,“B – B”“C – C”.
JMKIA0029ZZ
JMKIA5137ZZ
1. Roof panel 2. Glass lid
Portion a (Clearance) b (S urface height difference)
A – A 0.6 – 2.2 mm (0.024 – 0.087 in) −
1.5) – (+1.5) mm
[( −0.059) – (+0.059) in]
Revision: 2010 May2011 QX56

RF-34
< REMOVAL AND INSTALLATION >
GLASS LID
4. To prevent glass lid from moving after adjustment, first tighten the TORX bolts of front left, and then
tighten the TORX bolts of rear right.
5. Tighten remaining TORX bolts, being careful to prevent glass lid from moving.
6. Tilt glass lid up and down several times to check that it moves smoothly.
NOTE:
After adjustment the sunroof unit assembly, perform additional service. Refer to RF-17, "
ADDITIONAL SER-
VICE WHEN REPLACING CONTROL UNIT : Description".
B – B 0.6 – 2.2 mm (0.024 – 0.087 in)
−
1.5) – (+1.5) mm
[( −0.059) – (+0.059) in]
C – C 0.6 – 2.2 mm (0.024 – 0.087 in) −
1.5) – (+1.5) mm
[( −0.059) – (+0.059) in]
Revision: 2010 May2011 QX56

SUNROOF MOTOR ASSEMBLYRF-35
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
RF
N
O P
SUNROOF MOTOR ASSEMBLY
Exploded ViewINFOID:0000000006141248
1. Glass lid 2. TORX bolt 3. Side trim
4. Rear drain connector 5. Rear drain hose 6. Sunroof bracket (LH,RH)
7. Front drain hose 8. Front drain connector 9. Sunroof motor assembly
10. Sunroof unit assembly
JMKIA5212ZZ
