EC-60
< SYSTEM DESCRIPTION >[VK56VD]
DIAGNOSIS SYSTEM (ECM)
DIAGNOSIS DESCRIPTION : Malf unction Indicator Lamp (MIL)
INFOID:0000000006217727
DESCRIPTION
The MIL is located on the instrument panel.
1. The MIL will light up when the ignition switch is turned ON with-
out the engine running. This is a bulb check.
If the MIL does not light up, refer to EC-515, "
Component Func-
tion Check".
2. When the engine is started, the MIL should go off. If the MIL remains on, the on board diagnostic system has
detected an engine system malfunction.
On Board Diagn osis FunctionINFOID:0000000006217728
ON BOARD DIAGNOSIS ITEM
The on board diagnostic system has the following functions.
BLUB CHECK MODE
Description
This function allows damage inspection in the MIL bulb (blown, open circuit, etc.).
Operation Procedure
1. Turn ignition switch ON.
2. The MIL on the instrument panel should stay ON.
If it remains OFF, check MIL circuit. Refer to EC-515, "
Diagnosis Procedure".
SRT STATUS MODE
Description
This function allows to read if ECM has completed t he self-diagnoses of major emission control systems and
components. For SRT, refer to EC-58, "
DIAGNOSIS DESCRIPTION : Syst em Readiness Test (SRT) Code".
Operation Procedure
1. Turn ignition switch ON and wait 20 seconds.
2. SRT status is indicated as shown blow.
 ECM continues to illuminate MIL if all SRT codes are set.
SEF217U
Diagnostic test mode Function
Bulb check MIL can be checked.
SRT status ECM can read if SRT codes are set.
Malfunction warning If ECM detects a malfunction, it illuminates or blinks MIL to inform the driver that a malfunction has been detected.
Self-diagnostic results DTCs or 1st trip DTCs stored in ECM can be read.
Accelerator pedal released po-
sition learning ECM can learn the accelerator pedal released position. Refer to
EC-146, "
Description".
Throttle valve closed position
learning ECM can learn the throttle valve closed position. Refer to
EC-147, "
Description".
Idle air volume learning ECM can learn the idle air volume. Refer to EC-148, "
Description".
VVEL control sh aft position
sensor adjustment The initial position of the VVEL control shaft position sensor can be adjusted. Refer to
EC-150, "
De-
scription".
Revision: 2010 May2011 QX56

EC-70
< SYSTEM DESCRIPTION >[VK56VD]
DIAGNOSIS SYSTEM (ECM)
*: The item is indicated, but not used.
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
ACTIVE TEST MODE
Test Item
ECM TEMP 1
°C or °F  Displays a temperature calculated from a signal of
ECM temperature sensor 1.
ECM TEMP 2 °C or °F  Displays a temperature calculated from a signal of
ECM temperature sensor 2.
FUEL PUMP DUTY %  The control condition of the fuel pump control mod-
ule (FPCM) (determined by ECM according to the
input signals) is indicated.
Monitored item Unit Description Remarks
TEST ITEM CONDITION JUDGMENT CHECK ITEM (REMEDY)
VENT CON-
TROL/V  Ignition switch: ON (Engine
stopped)
 Turn solenoid valve ON and OFF with the CONSULT-III and listen
to operating sound. Solenoid valve makes an operating
sound.
 Harness and connectors
 Solenoid valve
ENG COOLANT
TEMP  Engine: Return to the original
non-standard condition
 Change the engine coolant tem- perature using CONSULT-III. If malfunctioning symptom disap-
pears, see CHECK ITEM.  Harness and connectors
 Engine coolant temperature sen-
sor
 Fuel injector
FUEL INJEC-
TION  Engine: Return to the original
non-standard condition
 Change the amount of fuel injec- tion using CONSULT-III. If malfunctioning symptom disap-
pears, see CHECK ITEM.
 Harness and connectors
 Fuel injector
 Air fuel ratio (A/F) sensor 1
FUEL/T TEMP
SEN  Change the fuel tank temperature using CONSULT-III.
PURG VOL
CONT/V  Engine: After warming up, run en-
gine at 1,500 rpm.
 Change the EVAP canister purge
volume control solenoid valve
opening percent using CON-
SULT-III. Engine speed changes according to
the opening percent.
 Harness and connectors
 Solenoid valve
FAN DUTY CON-
TROL* Ignition switch: ON
 Change duty ratio using CON-
SULT-III. Cooling fan speed changes.  Harness and connectors
 Cooling fan motor
 Cooling fan relay
 Cooling fan control module
 IPDM E/R
ALTERNATOR
DUTY Engine: Idle
 Change duty ratio using CON-
SULT-III. Battery voltage changes.  Harness and connectors
 IPDM E/R
Alternator
POWER BAL-
ANCE  Engine: After warming up, idle the
engine.
 A/C switch OFF
 Selector lever: P or N
 Cut off each injector signal one at a time using CONSULT-III. Engine runs rough or stops.
 Harness and connectors
 Compression
 Fuel injector
 Power transistor
Spark plug
 Ignition coil
IGNITION TIM-
ING  Engine: Return to the original
non-standard condition
 Timing light: Set
 Retard the ignition timing using
CONSULT-III. If malfunctioning symptom disap-
pears, see CHECK ITEM.
 Perform Idle Air Volume Learning.
Revision: 2010 May2011 QX56

EC-92
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
142
(R/W) 175
(B) Fuel pump control module
(FPCM) check
Input[When cranking engine] 0 V
[Engine is running]
 Warm-up condition
 Idle speed
9 V
143
(L/Y) 150
(R) EVAP control system pressure
sensor
Input [Ignition switch: ON] 1.8 - 4.8 V
144
(O/B) 150
(R) Refrigerant pressure sensor Input [Engine is running]
 Warm-up condition
 Both A/C switch and blower fan mo-
tor switch: ON (Compressor oper-
ates) 1.0 - 4.0 V
146 (L) — CAN communication line — — —
147
(G/Y) 175
(B) ASCD/ICC brake switch Input [Ignition switch: ON]
 Brake pedal: Slightly depressed
0 V
[Ignition switch: ON]
 Brake pedal: Fully released BATTERY VOLTAGE
(11 - 14 V)
150 (R) —Sensor ground
(Refrigerant pressure sensor/
Battery current sensor/EVAP
control system pressure sensor) —— —
151 (P) — CAN communication line — — —
156 (L) 175
(B) Power supply
for ECM (Back-
up) Input [Ignition switch: OFF] BATTERY VOLTAGE
(11 - 14 V)
158
(W/B) 175
(B) Stop lamp switch Input [Ignition switch: OFF]
 Brake pedal: Fully released
0 V
[Ignition switch: OFF]
 Brake pedal: Slightly depressed BATTERY VOLTAGE
(11 - 14 V)
161 (R/W) — ENG communication line — — —
163
(L/G) 175
(B) ECM relay (Self shut-off) Output [Engine is running]
[Ignition switch: OFF]
 A few seconds after turning ignition
switch OFF 0 - 1.5 V
[Ignition switch: OFF]
 More than a few seconds after turn- ing ignition switch OFF BATTERY VOLTAGE
(11 - 14 V)
165
(GR/ R) —
NOTE:
Not used —— —
166 (W) — ENG communication line — — —
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ – Signal name Input/
Output
Revision: 2010 May2011 QX56

EC-140
< BASIC INSPECTION >[VK56VD]
BASIC INSPECTION
2. Rev engine between 2,000 and 3,000 rpm 2 or 3 times under no
load, then run engine at idle speed for approximately 1 minute.
3. Check idle speed.
For procedure, refer to EC-530, "
Inspection".
For specification, refer to EC-538, "
Idle Speed".
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 4.
4.PERFORM ACCELERATOR PEDAL RE LEASED POSITION LEARNING
1. Stop engine.
2. Perform EC-146, "
Work Procedure".
>> GO TO 5.
5.PERFORM THROTTLE VALVE CL OSED POSITION LEARNING
Perform EC-147, "
Work Procedure".
>> GO TO 6.
6.PERFORM IDLE AIR VOLUME LEARNING
Perform EC-148, "
Work Procedure".
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO 7.
NO >> Follow the instruction of Idle Air Volume Learning. Then GO TO 4.
7.CHECK IDLE SPEED AGAIN
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed. For procedure, refer to EC-530, "
Inspection".
For specification, refer to EC-538, "
Idle Speed".
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Check the Following.
 Check camshaft position sensor and circuit. Refer to EC-303, "
DTC Logic".
 Check crankshaft position sensor and circuit. Refer to EC-299, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace malfunctioning part. Then GO TO 4.
9.CHECK ECM FUNCTION
1. Substitute with a non-malfunctioning ECM to check EC M function. (ECM may be the cause of the incident,
although this is rare.)
2. Perform initialization of IVIS (NATS) system and regist ration of all IVIS (NATS) ignition key IDs. Refer to
SEC-51, "
ECM : Work Procedure".
>> GO TO 4.
10.CHECK IGNITION TIMING
1. Run engine at idle.
2. Check ignition timing with a timing light. For procedure, refer to EC-531, "
Inspection".
PBIA8513J
Revision: 2010 May2011 QX56

BASIC INSPECTIONEC-141
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
For specification, refer to
EC-538, "Ignition Timing".
Is the inspection result normal?
YES >> GO TO 19.
NO >> GO TO 11.
11 .PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
1. Stop engine.
2. Perform EC-146, "
Work Procedure".
>> GO TO 12.
12.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Perform EC-147, "
Work Procedure".
>> GO TO 13.
13.PERFORM IDLE AIR VOLUME LEARNING
Perform EC-148, "
Work Procedure".
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO 14.
NO >> Follow the instruction of Idle Air Volume Learning. Then GO TO 4.
14.CHECK IDLE SPEED AGAIN
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed. For procedure, refer to EC-530, "
Inspection".
For specification, refer to EC-538, "
Idle Speed".
Is the inspection result normal?
YES >> GO TO 15.
NO >> GO TO 17.
15.CHECK IGNITION TIMING AGAIN
1. Run engine at idle.
2. Check ignition timing with a timing light. For procedure, refer to EC-531, "
Inspection".
For specification, refer to EC-538, "
Ignition Timing".
Is the inspection result normal?
YES >> GO TO 19.
NO >> GO TO 16.
16.CHECK TIMING CHAIN INSTALLATION
Check timing chain installation. Refer to EM-62, "
Removal and Installation".
Is the inspection result normal?
YES >> GO TO 17.
NO >> Repair the timing chain installation. Then GO TO 4.
17.DETECT MALFUNCTIONING PART
Check the following.
 Check camshaft position sensor and circuit. Refer to EC-303, "
DTC Logic".
 Check crankshaft position sensor and circuit. Refer to EC-299, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 18.
NO >> Repair or replace malfunctioning part. Then GO TO 4.
18.CHECK ECM FUNCTION
1. Substitute with a non-malfunctioning ECM to check EC M function. (ECM may be the cause of the incident,
although this is rare.)
Revision: 2010 May2011 QX56

EC-148
< BASIC INSPECTION >[VK56VD]
IDLE AIR VOLUME LEARNING
IDLE AIR VOLUME LEARNING
DescriptionINFOID:0000000006217750
Idle Air Volume Learning is a function of ECM to learn
the idle air volume that keeps engine idle speed within
the specific range. It must be perfo rmed under the following conditions:
 Each time the electric throttle control actuator or ECM is replaced.
 Idle speed or ignition timing is out of the specification.
Work ProcedureINFOID:0000000006217751
1.PRECONDITIONING
Check that all of the following conditions are satisfied.
Learning will be cancelled if any of the follo wing conditions are missed for even a moment.
 Battery voltage: More than 12.9 V (At idle)
 Engine coolant temperature: 70 - 105 °C (158 - 221 °F)
 Selector lever position: P or N
 Electric load switch: OFF
(Air conditioner, headlamp, rear window defogger)
On vehicles equipped with daytime light systems, if the parking brake is applied before the engine is
started the headlamp will not illuminate.
 Steering wheel: Neutral (Straight-ahead position)
 Vehicle speed: Stopped
 Transmission: Warmed-up
- With CONSULT-III: Drive vehicle until “ATF TEMP 2” in “DATA MONITOR” mode of “A/T” system indicates
less than 0.9 V.
- Without CONSULT-III: Drive vehicle for 10 minutes.
Will CONSULT-III be used?
YES >> GO TO 2.
NO >> GO TO 3.
2.PERFORM IDLE AIR VOLUME LEARNING
WITH CONSULT-III
1. Perform Accelerator Pedal Released Position Learning. Refer to EC-146, "
Work Procedure".
2. Perform Throttle Valve Closed Position Learning. EC-147, "
Work Procedure".
3. Start engine and warm it up to normal operating temperature.
4. Select “IDLE AIR VOL LEARN” in “WORK SUPPORT” mode.
5. Touch “START” and wait 20 seconds.
Is
“CMPLT” displayed on CONSULT-III screen?
YES >> GO TO 4.
NO >> GO TO 5.
3.PERFORM IDLE AIR VOLUME LEARNING
WITHOUT CONSULT-III
NOTE:
 It is better to count the ti me accurately with a clock.
 It is impossible to switch the di agnostic mode when an accelerator pedal position sensor circuit has
a malfunction.
1. Perform Accelerator Pedal Released Position Learning. Refer to EC-146, "
Work Procedure".
2. Perform Throttle Valve Closed Position Learning. EC-147, "
Work Procedure".
3. Start engine and warm it up to normal operating temperature.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Confirm that accelerator pedal is fully releas ed, turn ignition switch ON and wait 3 seconds.
6. Repeat the following procedure quickly 5 times within 5 seconds.
- Fully depress the accelerator pedal.
- Fully release the accelerator pedal.
7. Wait 7 seconds, fully depress the accelerator pedal for approx. 20 seconds until the MIL stops blinking
and turns ON.
8. Fully release the accelerator pedal within 3 seconds after the MIL turns ON.
Revision: 2010 May2011 QX56

FUEL PRESSUREEC-153
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
FUEL PRESSURE
Work ProcedureINFOID:0000000006217756
FUEL PRESSURE RELEASE
WITH CONSULT-III
1. Turn ignition switch ON.
2. Perform “FUEL PRESSURE RELEASE” in
“WORK SUPPORT” mode with CONSULT-III.
3. Start engine.
4. After engine stalls, crank it two or three times to release all fuel pressure.
5. Turn ignition switch OFF.
WITHOUT CONSULT-III
1. Remove fuel pump fuse in IPDM E/R. NOTE:
 For the fuse number, refer to EC-114, "
Wiring Diagram".
 For the fuse arrangement, refer to PG-143, "
Fuse, Connector and Terminal Arrangement".
2. Start engine.
3. After engine stalls, crank it two or three times to release all fuel pressure.
4. Turn ignition switch OFF.
5. Reinstall fuel pump fuse after servicing fuel system.
LOW FUEL PRESSURE CHECK
CAUTION:
 Before disconnecting fuel line, release fuel pressure from fuel line to eliminate danger.
 The fuel hose connection method used when taking fuel pressure check must not be used for other
purposes.
 Do not perform fuel pressure check with electrical syst ems operating (i.e. lights, rear defogger, A/C,
etc.) Fuel pressure gauge may indicate false readin gs due to varying engine load and changes in
manifold vacuum.
NOTE:
Prepare pans or saucers under the disconnected fuel line because the fuel may spill out.
1. Release fuel pressure to zero.
2. Prepare fuel hose for fuel pressure check (B) and fuel tube adapter [SST (KV10118400)] (D), then connect fuel pressure
gauge (A).
CAUTION:
 Use suitable fuel hose for fuel pressure check (genuine
NISSAN fuel hose without quick connector).
 To avoid unnecessary force or tension to hose, use mod-
erately long fuel hose for fuel pressure check.
 Do not use the fuel hose for checking fuel pressure with damage or cracks on it.
 Use Pressure Gauge to check fuel pressure.
3. Disconnect fuel feed hose from fuel tube. Refer to EM-43, "
Exploded View".
CAUTION:
Do not twist or kink fuel hose because it is plastic hose.
To quick connector
To fuel tube (engine side)
C : Hose clamp
PBIB2982E
Revision: 2010 May2011 QX56

P0441 EVAP CONTROL SYSTEMEC-315
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
4. Start engine and let it idle.
Never depress accelerator pedal even slightly.
5. Check vacuum gauge indication before 60 seconds pass after starting engine.
6. Rev engine up to 2,000 rpm after 100 seconds pass after starting engine.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 4.
4.CHECK EVAP PURGE LINE
1. Turn ignition switch OFF.
2. Check EVAP purge line for improper connection or disconnection. Refer to FL-10, "
Hydraulic Layout".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair EVAP purge line.
5.CHECK EVAP PURGE HOSE AND PURGE PORT
1. Disconnect purge hoses connected to EVAP service port ( A)
and EVAP canister purge volume control solenoid valve ( B).
2. Blow air into each hose and EVAP purge port ( C).
3. Check that air flows freely.
Is the inspection result normal?
YES-1 >> With CONSULT-III: GO TO 6.
YES-2 >> Without CONSULT-III: GO TO 7.
NO >> Repair or clean hoses and/or purge port.
6.CHECK EVAP CANISTER PURGE VO LUME CONTROL SOLENOID VALVE
WITH CONSULT-III
1. Start engine.
2. Perform “PURG VOL CONT/V” in “ACTIVE TEST” mode with CONSULT-III. Check that engine speed var-
ies according to the valve opening.
Does engine speed vary according to the valve opening?
YES >> GO TO 8.
NO >> GO TO 7.
7.CHECK EVAP CANISTER PURGE VO LUME CONTROL SOLENOID VALVE
Refer to EC-320, "
Component Inspection (EVAP Canister Purge Volume Control Solenoid Valve)".
Is the inspection result normal?
Vacuum should not exist.
Vacuum should exist.
SEF367U
SEF368U
Revision: 2010 May2011 QX56
