2011 INFINITI QX56 relay

PG-8
< SYSTEM DESCRIPTION >
COMPONENT PARTS
Always confirm the lever is fully released (loosened) before attempti ng to disconnect or connect these
connectors to avoid damage to th e connector housing or terminals.
Standardized RelayINFOID:0000000006275748
NORMAL OPEN, NORMAL CLOSED AND MIXED TYPE RELAYS
Relays can mainly be divided into three types: normal open, normal closed and mixed type relays.
TYPE OF STANDARDIZED RELAYS
LKIA0670E
1. Control unit with single lever
A. Fasten
B. Loosen
C. Lever 2. Control unit with dual levers
A. Levers
B. Fasten
C. Loosen 3. SMJ connector
A. Lever
B. Fasten
C. Loosen
SEL881H
Revision: 2010 May2011 QX56

PG
FUSE, FUSIBLE LINK AND RELAY BOXPG-141
< WIRING DIAGRAM >
C
DE
F
G H
I
J
K L
B A
O P
N
FUSE, FUSIBLE LINK AND RELAY BOX
Fuse and Fusible Link ArrangementINFOID:0000000006275754
JCMWM8469GB
Revision: 2010 May2011 QX56

PG-142
< WIRING DIAGRAM >
FUSE, FUSIBLE LINK AND RELAY BOX
JCMWM8470GB
Revision: 2010 May2011 QX56

PWO-4
< SYSTEM DESCRIPTION >[POWER SOCKET]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006023314
1. Console power socket (cup holder) 2. Front power socket 3. Accessory relay (2)
4. Console power socket (rear) 5. Luggage room power socket
A. Behind cluster lid C finisher
JSMIA0260ZZ
Revision: 2010 May2011 QX56

SCS-2
ACCUMULATOR ......................................................34
ACCUMULATOR : Exploded View .........................35
ACCUMULATOR : Removal and Installation ..........35
ACCUMULATOR : Inspection ................................38
ACCUMULATOR : Disposal ...................................38
PPMU, MIDDLE TUBE ASSEMBLY, PPMU PIPE ...38
PPMU, MIDDLE TUBE ASSEMBLY, PPMU PIPE
: Exploded View ......................................................
39
PPMU, MIDDLE TUBE ASSEMBLY, PPMU PIPE
: Removal and Installation ......................................
39
PPMU, MIDDLE TUBE ASSEMBLY, PPMU PIPE
: Inspection .............................................................
43
PPMU, MIDDLE TUBE ASSEMBLY, PPMU PIPE
: Disposal ................................................................
43
REAR TUBE ASSEMBLY ...................................... ...43
REAR TUBE ASSEMBLY : Exploded View ............44
REAR TUBE ASSEMBLY : Removal and Installa-
tion ....................................................................... ...
44
REAR TUBE ASSEMBLY : Inspection ...................46
AIR LEVELIZER CONTROL SYSTEM
PRECAUTION ....... ....................... ...............
47
PRECAUTIONS .............................................. ...47
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. ...
47
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect ..................................
47
Precaution for Procedure without Cowl Top Cover ...48
Precaution for Air Levelizer Control System ...........48
SYSTEM DESCRIPTION ............................49
DESCRIPTION ................................................ ...49
Description ........................................................... ...49
COMPONENT PARTS .......................................50
Component Parts Location .................................. ...50
Component Description ..........................................50
Air Levelizer Control Module ..................................51
Vehicle Height Sensor ............................................51
Air Compressor .......................................................51
Air Compressor Relay ............................................51
CK SUSP Indicator Lamp .......................................51
STRUCTURE AND OPERATION ......................52
Rear Shock Absorber .......................................... ...52
Vehicle Height Sensor ............................................53
SYSTEM .......................................................... ...54
System Diagram .................................................. ...54
System Description .................................................54
Fail-safe ..................................................................55
DIAGNOSIS SYSTEM (AIR LEVELIZER
CONTROL MODULE) ........................................
56
CONSULT-III Function ........................................ ...56
ECU DIAGNOSIS INFORMATION .............58
AIR LEVELIZER CONTROL MODULE .......... ...58
Reference Value .................................................. ...58
Fail-safe ..................................................................59
DTC Inspection Priority Chart .................................59
DTC Index ...............................................................59
WIRING DIAGRAM ....................................61
AIR LEVELIZER CONTROL SYSTEM ........... ...61
Wiring Diagram .................................................... ...61
BASIC INSPECTION ..................................65
DIAGNOSIS AND REPAIR WORKFLOW ...... ...65
Work Flow ............................................................ ...65
Diagnostic Work Sheet ...........................................66
STANDARD VEHICLE HEIGHT SETTING .......67
Description ........................................................... ...67
Work Procedure ......................................................67
DTC/CIRCUIT DIAGNOSIS ........................69
C1801 VHCL HEIGHT SENSOR .................... ...69
DTC Logic ............................................................ ...69
Diagnosis Procedure ..............................................69
Component Inspection ............................................70
C1802 AIR SUS COMPRS RELAY ...................72
DTC Logic ............................................................ ...72
Diagnosis Procedure ..............................................72
C1803 AIR SUSPENSION EXH SOL ................74
DTC Logic ............................................................ ...74
Diagnosis Procedure ..............................................74
Component Inspection ............................................75
C1804 VHCL HEIGHT ADJ UP .........................77
DTC Logic ............................................................ ...77
Diagnosis Procedure ..............................................77
Component Inspection (Air Compressor Relay) .....79
Component Inspection (Air Compressor) ............. ...79
C1805 VHCL HEIGHT ADJ DOWN ...................80
DTC Logic ............................................................ ...80
Diagnosis Procedure ..............................................80
C1806 VHCL HEIGHT SEN FIX ........................81
DTC Logic ............................................................ ...81
Diagnosis Procedure ...............................................81
C1807 VHCL HEIGHT SEN VOLT ....................82
DTC Logic ............................................................ ...82
Diagnosis Procedure ..............................................82
C1808 AIR SUS COMPRS FNCTN ...................84
DTC Logic ............................................................ ...84
Diagnosis Procedure ..............................................84
U1000 CAN COMM CIRCUIT ............................87
Revision: 2010 May2011 QX56

SCS-50
< SYSTEM DESCRIPTION >[AIR LEVELIZER CONTROL SYSTEM]
COMPONENT PARTS
COMPONENT PARTS
Component Parts LocationINFOID:0000000006256040
Component DescriptionINFOID:0000000006256041
1. Combination meter
Refer to MWI-6, "
METER SYSTEM
: Component Parts Location".2. CK SUSP indicator lamp 3. Air levelizer control module
4. Air compressor relay 5. Air chamber 6. Air compressor
7. Vehicle height sensor
A. Inside of luggage side finisher low- er (LH) B. Engine room (RH) C. Rear shock absorber
D. Vehicle rear (LH)
JSEIA0223GB
Component parts Reference
Air levelizer control module SCS-51, "
Air Levelizer Control Module"
Vehicle height sensorSCS-51, "Vehicle Height Sensor"
Air compressor
SCS-51, "Air Compressor"Exhaust solenoid
Revision: 2010 May2011 QX56

COMPONENT PARTSSCS-51
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Air Levelizer Control ModuleINFOID:0000000006256042
 Operates ON/OFF of air compressor (exhaust solenoid) , according to signal from vehicle height sensor.
 Transmits CK SUSP indicator lamp signal to the combination meter via CAN communication, when setting of standard vehicle height is incomplete.
 If malfunction is detected, the syste m enters fail-safe mode. Refer to SCS-59, "
Fail-safe".
Vehicle Height SensorINFOID:0000000006256043
Measures vehicle height of vehicle rear and transmits th is information to air levelizer control module according
to electric signal.
Air CompressorINFOID:0000000006256044
Operates according to signal from air levelizer control module via air compressor relay, and charges air in air
chamber of rear shock absorber.
EXHAUST SOLENOID
Operates according to signal from air levelizer control module, and discharges air in air chamber of rear shock
absorber.
Air Compressor RelayINFOID:0000000006256045
Turns ON according to signal from air levelizer control module, and operates air compressor.
CK SUSP Indicator LampINFOID:0000000006256046
 Turns ON for 2 seconds when ignition switch is turned ON, for the purpose of bulb check.
 Turns ON when setting of standard vehicle height is incomplete.
NOTE:
Does not turn ON when the system is malfunctioning.
Air compressor relay SCS-51, "Air Compressor Relay"
CK SUSP indicator lampSCS-51, "CK SUSP Indicator Lamp"
Component parts Reference
Revision: 2010 May2011 QX56

SYSTEMSCS-55
< SYSTEM DESCRIPTION > [AIR LEVELIZER CONTROL SYSTEM]
C
D
F
G H
I
J
K L
M A
B
SCS
N
O P
Vehicle height raises [When starting engi
ne, if vehicle height of vehicle rear continues for 30 seconds or more in a
status that is 15 mm (0.59 in) or less than standard vehicle height]
1. Vehicle height sensor detects vehicle height status, and transmits this information to air levelizer control
module.
2. Air levelizer control module turns air compressor relay ON and operates air compressor.
3. Air compressor charges air in air chamber of shock absorber.
4. Vehicle height raises, and control is complete when status is −1 mm ( −0.04 in) of standard vehicle height
value.
Vehicle height lowers [When starting engine, if vehicle height of vehicle rear continues for 30 seconds or more in a
status that is 15 mm (0.59 in) or more of standard vehicle height]
1. Vehicle height sensor detects vehicle height status, and transmits this information to air levelizer control
module.
2. Air levelizer control module turns exhaust solenoid of air compressor ON.
3. Air compressor discharges air from air chamber of shock absorber.
4. Vehicle height lowers, and control is complete when st atus is +1 mm (+0.04 in) of standard vehicle height.
Fail-safeINFOID:0000000006256051
If malfunction is detected, control stops.
The system may enter fail-safe mode under certain conditions (for example, over-laden conditions) when elec-
tronic circuit is normal.
In this case, always check that the system re turns to normal by starting engine after unloading load.
JSEIA0221GB
Revision: 2010 May2011 QX56
