2011 INFINITI QX56 height

CCS-72
< BASIC INSPECTION >[ICC]
LASER BEAM AIMING ADJUSTMENT
LASER BEAM AIMING ADJUSTMENT
DescriptionINFOID:0000000006224293
OUTLINE OF LASER BEAM AIMING ADJUSTMENT
Always adjust the laser beam aiming after removing and installing or replacing the ICC sensor.
CAUTION:
The system does not operate normally
unless the laser beam aiming adjustment is performed. Always
perform it.
1. Set the ICC target board [SST: KV99110100 (J-45718)] to the correct position in front of the vehicle.
2. Set the laser beam aiming mode (“LASER BEAM AD JUST” on “Work support”) with CONSULT-III, and
then perform the adjustment according to the displa y. (Manually turn the up-down direction adjusting
screw for vertical adjustment. ICC sensor adjusts the automatic aiming for the horizontal direction.)
CAUTIONARY POINT FOR LASER BEAM AIMING ADJUSTMENT
CAUTION:
 For laser beam aiming adjustment, choose a level location where a view can be obtained without any
obstruction as far as 12 m (39 ft) or more in the forward direction.
 Adjust laser beam aiming for 5 second s or more after starting engine.
 Adjust the laser beam aiming with CONSULT-III. (The laser beam aiming cannot be adjusted without
CONSULT-III.)
 Never enter the vehicle during laser beam aiming adjustment.
 Never look directly into the laser beam sour ce (ICC sensor body window) during laser beam aiming
adjustment.
 Laser beam aiming adjustment is performed at idle. At this time, turn the headlamps OFF.
Work Procedure (Preparation)INFOID:0000000006224294
1.ADVANCE PREPARATION FOR LASER BEAM AIMING ADJUSTMENT
1. Adjust all tire pressure to the specified value.
2. Empty the vehicle. (Remove any luggage from the passenger compartment, luggage room, etc.)
3. Shift the selector lever to “P” pos ition, and release the parking brake.
4. Fully fill the fuel tank, and then check that t he coolant and oils are filled up to correct level.
5. Clean off the ICC sensor body window with a soft cloth.
>> Go to CCS-72, "
Work Procedure (Setting The ICC Tar-
get Board)".
Work Procedure (Setting The ICC Target Board)INFOID:0000000006224295
DESCRIPTION
Accurate adjustment of the laser beam requires t hat the ICC target board be accurately positioned.
CAUTION:
If the laser beam is adjusted with the ICC target board in the incorrect position, the ICC system does
not function normally.
1.ICC TARGET BOARD HEIGHT ADJUSTMENT
1 : ICC sensor
JSOIA0372ZZ
Revision: 2010 May2011 QX56

CCS
LASER BEAM AIMING ADJUSTMENTCCS-73
< BASIC INSPECTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
1. Attach the ruler (2) at 14 mm (0.55 in) (H) below the center (A) of\
the ICC target board (1).
2. Adjust the ICC target board height to the position aligning the ruler (1) upper side tip with the center of laser beam axis (A).
NOTE:
 The center of laser beam axis (A) is located at 38 mm (1.5 in) (W)
from the left end of ICC sensor and 22 mm (H) (0.87 in) from above
when viewed from the front of the vehicle.
 To identify the laser beam axis center (A) easily, prepare a piece of paper (B) cut to the size of 38 mm (1.5 in) (W) × 22 mm (0.87 in)
(H) and attach it on the lower left point of the ICC sensor (1).
>> GO TO 2.
2.ADJUSTING SIDE POSITION OF ICC TARGET BOARD
3: Adjust nut
b: 90 °
JPOIA0215ZZ
2 : ICC sensor
JSOIA0351ZZ
B : Up-down direction adjusting screw
JSOIA0216ZZ
JSOIA0217ZZ
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ICC SENSOR)DAS-89
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
DIAGNOSIS SYSTEM (ICC SENSOR)
CONSULT-III Function (LASER)INFOID:0000000006228055
APPLICATION ITEMS
CONSULT-III performs the following functions via CAN communication with ADAS control unit and the com-
munication with ICC sensor.
WORK SUPPORT
Laser Beam Adjust
Refer to CCS-72, "Description".
SELF DIAGNOSTIC RESULT
Refer to CCS-55, "DTC Index".
DATA MONITOR
Diagnosis mode Description
Work Support It can monitor the adjustment direction indication in order to perform the laser beam aiming operation
smoothly
Self Diagnostic Result Displays malfunctioning system memorized in ICC sensor
Data Monitor Displays real-time input/output data of ICC sensor
Ecu Identification Displays ICC sensor part number
CAN Diag Support Monitor The results of transmit/receive diagnosis of ITS communication can be read
Work support items Description
LASER BEAM ADJUST Outputs laser beam, calculates dislocation of the beam, and indicates adjustment direction
Monitored item
[Unit] Description
VHCL SPEED SE
[km/h] or [mph] Vehicle speed judged from a vehicle speed signal read by the ICC sensor via ITS communica-
tion is displayed [ADAS control unit receives a vehicle speed signal from ABS actuator and
electric unit (control unit) via CAN communication and transmits the calculated vehicle speed
to ICC sensor via ITS communication]
YAW R AT E
[deg/s] Indicates yaw rate read from ADAS control unit through ITS communication (ADAS control unit
receives yaw rate signal from ABS actuator and electric unit (control unit) via CAN communi-
cation and transmits yaw rate calculated by the ADAS control unit)
Yaw rate judged from a yaw rate signal read by ICC sensor via ITS communication is displayed
[ADAS control unit receives a yaw
rate signal from ABS actuator and electric unit (control unit)
via CAN communication and transmits the calculated yaw rate to ICC sensor via ITS commu-
nication]
PWR SUP MONI
[V] Indicates IGN voltage input by ICC sensor
DISTANCE
[m] Indicates the distance from the vehicle ahead
RELATIVE SPD
[m/s] Indicates the relative speed of the vehicle ahead
LASER OFFSET
[m] NOTE:
The item is indicated, but not used
LASER HEIGHT
[m] NOTE:
The item is indicated, but not used
STEERING ANGLE
[deg] The steering angle is displayed
STRG ANGLE SPEED
[deg/s] The steering angle speed is displayed
Revision: 2010 May2011 QX56

DAS-104
< ECU DIAGNOSIS INFORMATION >[DCA]
ICC SENSOR
ICC SENSOR
Reference ValueINFOID:0000000006228056
VALUES ON THE DIAGNOSIS TOOL
TERMINAL LAYOUT
PHYSICAL VALUES
Monitor item Condition Value/Status
VHCL SPEED SE While driving Value of vehicle
speed signal
(wheel speed)
YAW RATE While driving Vehicle stopped 0.0
Vehicle turning right Positive value
Vehicle turning left Negative value
PWR SUP MONI Ignition switch ON Power supply
voltage value of ICC sensor
DISTANCE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the dis-
tance from the
preceding vehi- cle
When a vehicle ahead is not detected 0.0
RELATIVE SPD Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the rel-
ative speed
When a vehicle ahead is not detected 0.0
LASER OFFSET NOTE:
The item is indicated, but not used
—
LASER HEIGHT NOTE:
The item is indicated, but not used —
STEERING ANGLE Ignition switch ON When setting the steering wheel in straight-ahead posi-
tion
0.0
When turning the steering wheel 90 ° rightward +90
When turning the steering wheel 90 ° leftward -90
STRG ANGLE
SPEED Ignition switch ON At the time of turning the steering wheel Steering wheel
turning speed is
displayed
L/R ADJUST Ignition switch ON At the completion of laser beam adjustment Horizontal cor-
rection value is
displayed
U/D ADJUST Ignition switch ON At the completion of laser beam adjustment Vertical correc-
tion value is dis-
played
JPOIA0105ZZ
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ICC SENSOR)DAS-235
< SYSTEM DESCRIPTION > [FCW]
C
D
E
F
G H
I
J
K L
M B
N P A
DIAGNOSIS SYSTEM (ICC SENSOR)
CONSULT-III Function (LASER)INFOID:0000000006228179
APPLICATION ITEMS
CONSULT-III performs the following functions via CAN communication with ADAS control unit and the com-
munication with ICC sensor.
WORK SUPPORT
Laser Beam Adjust
Refer to CCS-72, "Description".
SELF DIAGNOSTIC RESULT
Refer to CCS-55, "DTC Index".
DATA MONITOR
Diagnosis mode Description
Work Support It can monitor the adjustment direction indication in order to perform the laser beam aiming operation
smoothly
Self Diagnostic Result Displays malfunctioning system memorized in ICC sensor
Data Monitor Displays real-time input/output data of ICC sensor
Ecu Identification Displays ICC sensor part number
CAN Diag Support Monitor The results of transmit/receive diagnosis of ITS communication can be read
Work support items Description
LASER BEAM ADJUST Outputs laser beam, calculates dislocation of the beam, and indicates adjustment direction
Monitored item
[Unit] Description
VHCL SPEED SE
[km/h] or [mph] Vehicle speed judged from a vehicle speed signal read by the ICC sensor via ITS communica-
tion is displayed [ADAS control unit receives a vehicle speed signal from ABS actuator and
electric unit (control unit) via CAN communication and transmits the calculated vehicle speed
to ICC sensor via ITS communication]
YAW R AT E
[deg/s] Indicates yaw rate read from ADAS control unit through ITS communication (ADAS control unit
receives yaw rate signal from ABS actuator and electric unit (control unit) via CAN communi-
cation and transmits yaw rate calculated by the ADAS control unit)
Yaw rate judged from a yaw rate signal read by ICC sensor via ITS communication is displayed
[ADAS control unit receives a yaw
rate signal from ABS actuator and electric unit (control unit)
via CAN communication and transmits the calculated yaw rate to ICC sensor via ITS commu-
nication]
PWR SUP MONI
[V] Indicates IGN voltage input by ICC sensor
DISTANCE
[m] Indicates the distance from the vehicle ahead
RELATIVE SPD
[m/s] Indicates the relative speed of the vehicle ahead
LASER OFFSET
[m] NOTE:
The item is indicated, but not used
LASER HEIGHT
[m] NOTE:
The item is indicated, but not used
STEERING ANGLE
[deg] The steering angle is displayed
STRG ANGLE SPEED
[deg/s] The steering angle speed is displayed
Revision: 2010 May2011 QX56

DAS-248
< ECU DIAGNOSIS INFORMATION >[FCW]
ICC SENSOR
ICC SENSOR
Reference ValueINFOID:0000000006228180
VALUES ON THE DIAGNOSIS TOOL
TERMINAL LAYOUT
PHYSICAL VALUES
Monitor item Condition Value/Status
VHCL SPEED SE While driving Value of vehicle
speed signal
(wheel speed)
YAW RATE While driving Vehicle stopped 0.0
Vehicle turning right Positive value
Vehicle turning left Negative value
PWR SUP MONI Ignition switch ON Power supply
voltage value of ICC sensor
DISTANCE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the dis-
tance from the
preceding vehi- cle
When a vehicle ahead is not detected 0.0
RELATIVE SPD Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When a vehicle ahead is detected
Displays the rel-
ative speed
When a vehicle ahead is not detected 0.0
LASER OFFSET NOTE:
The item is indicated, but not used
—
LASER HEIGHT NOTE:
The item is indicated, but not used —
STEERING ANGLE Ignition switch ON When setting the steering wheel in straight-ahead posi-
tion
0.0
When turning the steering wheel 90 ° rightward +90
When turning the steering wheel 90 ° leftward -90
STRG ANGLE
SPEED Ignition switch ON At the time of turning the steering wheel Steering wheel
turning speed is
displayed
L/R ADJUST Ignition switch ON At the completion of laser beam adjustment Horizontal cor-
rection value is
displayed
U/D ADJUST Ignition switch ON At the completion of laser beam adjustment Vertical correc-
tion value is dis-
played
JPOIA0105ZZ
Revision: 2010 May2011 QX56

DAS
PRE-INSPECTION FOR DIAGNOSISDAS-335
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
PRE-INSPECTION FOR DIAGNOSIS
Inspection ProcedureINFOID:0000000006223729
1.CHECK CAMERA LENS AND WINDSHIELD
Are camera lens and windshield contaminated with foreign materials?
YES >> Clean camera lens and windshield.
NO >> GO TO 2.
2.CHECK LANE CAMERA UNIT INSTALLATION CONDITION
Check lane camera unit installation condition (install ation position, properly tightened, a bent bracket).
Is it properly installed?
YES >> GO TO 3.
NO >> Install lane camera unit properly, and perform camera aiming. Refer to DAS-340, "
Description".
3.CHECK VEHICLE HEIGHT
Check vehicle height. Refer to FSU-21, "
Wheel Height".
Is vehicle height appropriate?
YES >> INSPECTION END
NO >> Repair vehicle to appropriate height.
Revision: 2010 May2011 QX56

DAS
CAMERA AIMING ADJUSTMENTDAS-341
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
>> Go to DAS-341, "Work Procedure (Target Setting)".
Work Procedure (Target Setting)INFOID:0000000006223736
CAUTION:
 Perform this operation in a horizo ntal position where there is a clear view for 5 m (16.4 ft) forward
and 3 m (9.84 ft) wide.
 Place the target in a well-lig hted location. (Poor lighting may make it hard to adjust.)
 The target may not be detected when there is a ligh t source within 1.5 m (4.92 ft) from either side and
within 1 m (3.28 ft) upward/downward from the target.
 Check the location of the sun. (S unlight should not shine directly on the front of the vehicle.)
 The target may not be detected when there is the same pattern of black and white as the target when
the pattern is within 1 m (3.28 ft) from either si de and upward/downward position from the target. (It
is desirable that the vehicle is positioned on the opposite side of a single-color wall.)
1.TARGET SETTING
1. Mark points “A”, “B”, “C” and “D”at the center of the lateral sur- face of each wheels.
NOTE:
Hang a string with a cone from the fender so as to pass through
the center of wheel, and then mark a point at the center of the
lateral surface of the wheel.
2. Draw line “LH” passing through points “A” and “B” on the left side
of vehicle.
NOTE:
Approximately 4 m (13.12 ft) or mo re from the front end of vehi-
cle.
1.Board 2.String 3.Cone
: Target mark
Diameter of a target (D) : 200 mm (7.87 in)
Height of a target center (H) : 1450 mm (57.09 in)
Width between a right target cen-
ter from a left target center (W) : 600 mm (23.62 in)
“A” – “E” (“C” – “F”) : 3850 mm (151.57 in)
PKIB4694E
JSOIA0360GB
Revision: 2010 May2011 QX56
