See page 154 for information on
cargo loading. Keep the tailgate and
the hatch closed at all times while
driving to avoid damaging them, and
to prevent exhaust gas from getting
into the interior. SeeCarbon
Monoxide Hazard on page 52. Seat Adjustments
See pages 11
－13 for important safety
information and warnings about how to properly position seats and seat-backs.Make all seat adjustments before you
start driving.
Front SeatTo adjust the seat forward and
backward, pull up on the bar under
the seat cushion's front edge. Try to
move the seat to make sure it is
locked in position.
CONTINUED
Door Locks, Seats
83
Instruments and Controls
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

To change the seat-back angle of the
front seat, pull up on the lever on the
outside of the seat bottom. Adjust the
seat-back and make sure it locks into
position.
Rear SeatTo change the angle of the rear seat-
back, pull the strap at the inside edge
of the seat cushion, make sure the
seat-back locks into position.Driver's Seat Height Adjustment
To adjust the height of the driver's
seat, turn the dial on the outside of
the seat bottom.
SEAT-BACK ADJUSTMENT STRAP
Seats8410/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Front Seat ArmrestsOn EX modelEach front seat has an armrest on the
side of the seat-back. To use it, pivot
it down.Head Restraints
See page 13 for important safety
information and a warning aboutimproperly positioning head restraints.Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers from the likelihood of
whiplash and other injuries.
They are most effective when you
adjust them so the center of the back
of the occupant's head rests against
the center of the restraint.
CONTINUED
Seats
85
Instruments and Controls
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Adjusting the Head RestraintThe head restraints in the front and
rear seating positions adjust for
height. You need both hands to
adjust the restraint. To raise it, pull
upward. To lower the restraint, push
the release button sideways and
push the restraint down.
Removing the Head RestraintTo remove a head restraint for
cleaning or repair, pull it up as far as
it will go. Push the release button,
then pull the restraint out of the seat-
back.
Failure to reinstall the head
restraints can result in severe
injury during a crash.
Always replace the head
restraints before driving.
When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
Make sure the head restraint locks in
position when you reinstall it.
RELEASE BUTTON
Front
Rear
CUSHION
RELEASE
BUTTON
SEAT-BACK
LEGS
Seats8610/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Reclining the Front SeatsYou can recline the seat-backs on the
front seats so they are level with the
rear seat cushions, making a large
cushioned area. To do this:
1. Remove the head restraints fromthe front seats (see page 85), and
store them in the side pockets of
the cargo area. 2. Adjust the front seats forward as
far as possible. Pull up the seat-
back angle adjustment lever and
pivot the seat-back backward until
it is level with the rear seat
cushion.
3. Move the front seat backward until it touches the rear seat.
4. Adjust the rear seat-back to the desired position.
Reverse this procedure to return the
front and rear seats to the upright
position. Make sure you install the
head restraints and the seats are
locked securely before driving.
When you return the seat-back to its
upright position, hold the seat-back
to keep it from going up too quickly.
Seats
87
Instruments and Controls
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Folding the Rear Seats
To create more cargo space, you can
fold up each rear seat to each side
wall separately.1. Lower the head restraint to its lowest position.
2. Pull the seat-back adjustment strapat the inside edge of the seat
cushion and push the seat-back
backward as far as it will go.
3. Pull the release strap on the seatsupport, and pivot the seat toward
the vehicle's side wall.
SEAT-BACK ADJUSTMENT STRAP
RELEASE STRAP
Seats8810/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

4. A fastening strap is attached to theinside of the seat cushion. While
pushing the seat up and toward the
side wall, hook the fastening strap
to the grab rail.
5. Fold down the seat support. Reverse this procedure to return the
rear seat to the upright position.
When not in use, store the fastening
strap hook in the fabric pocket on the
bottom of the seat cushion. Make
sure the seat is locked securely.
GRAB RAIL
FASTENING STRAP
SEAT SUPPORT
Seats
89
Instruments and Controls
10/08/06 08:34:41 11 ELEMENT MMC North America Owner's Man 50 31SCV680 enu

Removing the Rear SeatsBoth seats can be removed to give
more cargo capacity. To remove a
seat:1. Pull the release strap on the seat support to unlock the seat support.
2. Remove the cover between theseat cushion and the side wall by
pulling the tab and pulling the
cover straight up.
3. Push the lock lever forward tounlock the seat and fold down the
seat support.
RELEASE STRAP
TAB
COVER
LOCK LEVER STEEL HANDLE
