2011 HONDA CROSSTOUR Owner's Manual (in English)

The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
Always use Honda Heavy Duty
Brake Fluid DOT 3. If it is not
available, you should use only DOT 3
or DOT 4 f luid, f rom a sealed
container, as a temporary
replacement. Using any non-Honda brake f luid can
cause corrosion and decrease the lif e
of the system. Have the brake
system f lushed and ref illed with
Honda Heavy Duty Brake Fluid
DOT 3 as soon as possible.
Brake f luid marked DOT 5 is not
compatible with your vehicle’s
braking system and can cause
extensive damage.
Check the f luid level in the brake
f luid reservoir monthly.
Independent of the Maintenance
Minder inf ormation, replace the
brake f luid every 3 years.
Brake Fluid
342
MAX
MIN
10/08/27 14:59:42 31TP6610_347
2011 Accord Crosstour

µµ
Always use Honda Power Steering
Fluid. You may use another power
steering f luid as an emergency
replacement, but have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently, and have
the system inspected as soon as
possible.
Pour the f luid slowly and caref ully
so you do not spill any. Clean up
any spills immediately; it could
damage components in the engine
compartment. Check the level on the side of the
reservoir when the engine is cold.
The f luid should be between the
UPPER LEVEL and LOWER LEVEL.
If not, add power steering f luid to the
UPPER LEVEL. The timing belt should be replaced
according to the Maintenance
Minder (see page ).
Replace the timing belt every 60,000
miles (100,000 km) if you regularly
drive your vehicle in any of the
f ollowing conditions:
In very high temperatures
(over 110°F, 43°C).
In very low temperatures
(under 20°F, 29°C).
Frequently towing a trailer. 331
Timing Belt
Power Steering Fluid
Power Steering Fluid, Timing Belt
Maint enance
343
UPPER LEVEL
LOWER LEVELTM
Turning the steering wheel to f ull lef t
or right lock and holding it there can
damage the power steering pump.
10/08/31 13:35:56 31TP6610_348
2011 Accord Crosstour

Your vehicle has halogen headlight
bulbs. When replacing a bulb, handle
it by its base, and protect the glass
f rom contact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean
cloth.Open the hood.
To change a bulb on the
passenger’s side, remove the
engine coolant reserve tank by
pulling it out of its stay.
Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustmentsshouldbedonebyyour
dealer or another qualif ied
technician.
1.
Headlight A iming
Replacing a Headlight Bulb
High Beam Headlight
Lights
344
STAYHalogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
10/08/27 15:00:00 31TP6610_349
2011 Accord Crosstour

Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.
Remove the bulb by turning it
approximately one-quarter turn
counterclockwise.Turn on the headlights to test the
new bulb.
Reinstall the engine coolant
reserve tank.
Push the electrical connector onto
the bulb. Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
3. 2. 4.
5.
6.
CONT INUED
Passenger’s side
Lights
Maint enance
345
TAB
ELECTRICAL CONNECTOR
BULB
10/08/27 15:00:08 31TP6610_350
2011 Accord Crosstour

To change the passenger’s side
bulb, start the engine, turn the
steering wheel all the way to the
lef t, and turn of f the engine. To
change the driver’s side bulb, turn
the steering wheel to the right.
Use a f lat-tip screwdriver to
remove the holding clip f rom the
inner f ender, and remove the
screw with a Phillips-head
screwdriver.Pull the inner f ender cover away
f rom the f ender and bumper.
Remove the electrical connector
f rom the bulb by pushing on the
tab to unlock it, then slide the
connector of f the bulb.
Remove the bulb by turning it
approximately one-quarter turn
counterclockwise. Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
Push the electrical connector onto
the bulb.
Turn on the headlights to test the
new bulb.
Put the inner f ender cover in place.
Install the holding clip. Lock it in
placebypushingonthecenter.
Tighten the screw securely.
3.
4.
5.
1.
2. 6.
7.
8.
9.
L ow Beam Headlight
Lights
346
BULB
TAB
SCREW HOLDING CLIP
ELECTRICAL CONNECTOR
10/08/27 15:00:18 31TP6610_351
2011 Accord Crosstour

Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To remove the burned out bulb,
push it in and turn it
counterclockwise until it unlocks.
Open the hood.
To change the turn signal bulb on
the passenger’s side, remove the
engine coolant reserve tank by
pulling it out of its stay. To change a bulb on the driver’s side,
remove the fastener with a flat-tip
screwdriver, and remove the splash
separator by pushing the tab. Then
remove the duct.
1. 2.
3.
CONT INUED
Lights
Replacing a Front T urn Signal/
Parking L ight Bulb
Maint enance
347
STAYDUCT
TAB
BULB
SOCKET
SPLASH
SEPARATOR
FASTENER
10/08/27 15:00:28 31TP6610_352
2011 Accord Crosstour

Install the new bulb and turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working. Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Reinstall the coolant reserve tank.Use a f lat-tip screwdriver to
remove the holding clip f rom the
inner f ender, and remove the
screw with a Phillips-head
screwdriver.
To change the bulb on the driver’s
side, start the engine, turn the
steering wheel all the way to the
right, then turn of f the engine. To
change the bulb on the passenger’s
side, turn the steering wheel to the
lef t.
Reinstall the splash separator and
duct securely. Reinstall the
f astener and secure it by pushing
on the head until it locks.
6.
1.
7. 5. 4.
2.
Passenger’s side
Driver’s Side
Replacing a Front Side Marker
Light Bulb
Lights
348
SCREW HOLDING CLIP
10/08/27 15:00:36 31TP6610_353
2011 Accord Crosstour

CONT INUED
Open the tailgate. Place a cloth on
the edge of the cover to prevent
scratches. Remove the covers by
caref ully prying on the edge with a
small f lat-tip screwdriver.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Put the inner f ender cover in place.
Install the holding clip. Lock it in
placebypushingonthecenter.
Tighten the screw securely.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the burned out bulb straight
out of its socket.
Push the new bulb straight into
the socket until it bottoms. 5.
6.
7.
1.
3.
4. Replacing Rear Bulbs
Lights
Maint enance
349
SOCKET
COVER
BULB
10/08/27 15:00:45 31TP6610_354
