2011 HONDA CROSSTOUR Owner's Manual (in English)

To select a memorized position, do
this:Make sure the parking brake is set
and the shif t lever is in Park.
Press the desired memory button
(1 or 2) until you hear a beep, then
release the button.
To cancel the storing procedure
after pressing the SET button, press
the SET button again within 5
seconds.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button.
All stored driving positions will be
lost if your vehicle’s battery goes
dead or is disconnected.
1.
2. Selecting a Memorized Position
Driving Position Memory System
102
MEMORY BUTTONS
10/08/27 14:27:34 31TP6610_107
2011 Accord Crosstour

If desired, you can use the
adjustment switches to change the
positions of the seat or outside
mirrors af ter they are in their
memorized positions. If you change
the memorized position, the
indicator in the memory button will
go out. To keep this driving position
f or later use, you must store it in the
driving position memory.
To stop the system’s automatic
adjustment, do any of these actions:
Press any button on the control
panel: SET, 1, or 2.
Push any of the adjustment
switches f or the seat.
Shif t out of Park.
Adjust the outside mirrors.
The system will move the seat and
outside mirrors to the memorized
positions. The indicator in the
selected memory button will f lash
during movement. When the
adjustments are complete, you will
hear two beeps, and the indicator will
remain on.
Driving Position Memory System
Inst rument s and Cont rols
103
10/08/27 14:27:40 31TP6610_108
2011 Accord Crosstour

The inside mirror can automatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this f eature.
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has day and night
positions. The night position reduces
glare f rom headlights behind you.
Flip the tab on the bottom edge of
the mirror to select the day or night
position.
EX model
EX-L models
Mirrors
104
AUTO BUTTON
INDICATOR SENSOR
TAB
There is also a sensor on the back of
the mirror. Items hung on the mirror
may block this sensor and af f ect its
perf ormance.
10/08/27 14:27:46 31TP6610_109
2011 Accord Crosstour

Turn the ignition switch to the ON
(II) position.
Move the selector switch to L
(driver’s side) or R (passenger’s
side).Push the appropriate edge of the
adjustment switch to move the
mirrorright,left,up,ordown.
When you f inish, move the
selector switch to the center (off)
position. This turns the
adjustment switch of f to keep your
settings.
To turn the feature off, place the
switch in the center position. To tilt the passenger’s mirror,
place the switch in the right
position. To tilt the driver’s mirror, place
the selector switch in the left
position.
Both outside door mirrors have a
reverse tilt f eature. When in reverse,
the selected mirror will tilt down
slightly to improve your view as you
parallel park. Shif ting out of reverse
will return the mirror to its original
position.
Outside mirror positions can be
stored in the driving position
memory system (see page ).
1. 3.
2. 4.
101
EX-L models
Adjusting the Power Mirrors Reverse Tilt Door Mirror
Mirrors
Inst rument s and Cont rols
105
SELECTOR SWITCH
ADJUSTMENT SWITCH
10/08/27 14:27:56 31TP6610_110
2011 Accord Crosstour

Turn the ignition switch to the ON
(II) position to raise or lower any
window. To open a window, push the
switchdownandholdit.Releasethe
switch when you want the window to
stop. Pull back on the switch and
hold it to close the window.
The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off. Pressing this button also
turns the rear window def ogger on
and off. PowerMirrorHeaters
PowerWindows
Mirrors, Power Windows
106
MAIN SWITCH
FRONT
PASSENGER’S
WINDOW SWITCHINDICATOR
Without navigation system is shown. REAR WINDOW DEFOGGER/
HEATED MIRROR BUTTON
DRIVER’S
WINDOW
SWITCHClosing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
10/08/27 14:28:03 31TP6610_111
2011 Accord Crosstour

µ
µ If either f ront
window senses any obstacle while it
is closing automatically, it will
reverse direction and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
The driver’s window auto
reverse f unction is disabled when
you continuously pull up the switch.
When you push the main switch in,
the indicator comes on and the
passengers’ windows cannot be
raised or lowered. Use the main
switchwhenyouhavechildreninthe
vehicle so they do not injure
themselves by operating the
windows unintentionally. To cancel
this feature, push on the switch
again. The switch will pop out and
the indicator will go of f .
The windows and the main switch
feature will operate for up to 10
minutes after you turn off the
ignition switch. Opening either f ront
door cancels this f unction.
To open either f ront
window f ully, push the window
switch f irmly down to the second
detent, then release it. The window
automatically goes down all the way.
To stop the window f rom going all
the way down, pull back on the
window switch briefly.
To close either f ront window f ully,
pull back the window switch f irmly
to the second detent, then release it.
The window automatically goes all
the way up. To stop the window f rom
going all the way up, push down on
the window switch briefly. AUTO REVERSE
AUTO
Power Windows
Inst rument s and Cont rols
107
NOTE:
10/08/27 14:28:09 31TP6610_112
2011 Accord Crosstour

Press the UNLOCK button a
second time, and hold it. The
remaining doors unlock, and all
f our windows and the moonroof
start to open. To stop the windows
and moonroof , release the button.Turn the key clockwise, then
release it. Insert the key in the driver’s door
lock.
To open:
Press the UNLOCK button once
to unlock the driver’s door. To open the windows and
moonroof f urther, press the
button again (within 10 seconds of
step 1) and hold it. If the windows
and the moonroof stop bef ore the
desired position, repeat steps 1
and 2.
You cannot close the windows or the
moonroof with the remote
transmitter. You can open and close the windows
and moonroof with the key in the
driver’s door lock.
You can open all of the windows and
the moonroof f rom outside with the
remote transmitter.
1. 2.
3.
1.
2.
Opening the Windows and
Moonroof with the Remote
Transmitter
Opening/Closing the Windows
and Moonroof with the K ey
Power Windows
108
Open
Close
UNLOCK
BUTTON
10/08/27 14:28:20 31TP6610_113
2011 Accord Crosstour

Turnthekeyclockwiseagain,and
hold it. All f our windows and the
moonroof start to open. To stop
the windows and the moonroof ,
release the key.To close:
Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
the moonroof , release the key.
To close the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
To open the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
If the windows and the
moonroof stop bef ore the desired
position, repeat steps 2 and 3.
If the windows and the
moonroof stop bef ore the desired
position, repeat steps 2 and 3. 1.
2.
3.
4.
3.
4.
Power Windows
Inst rument s and Cont rols
109
NOTE:
NOTE:
10/08/27 14:28:28 31TP6610_114
2011 Accord Crosstour
