Page 3 of 164
i !
We draw your attention to the following...
Key
safety warning
additional information
contributes to the protection of the environment
refer to the page indicated Your vehicle is fitted with only some of
the equipment described in this document,
depending on the trim level, version and the
specifications for the country in which it is sold.
The fitting of electrical equipment or
accessories which are not recommended
by CITROËN may result in a failure of your
vehicle's electronic system. Please note this
specific warning and contact a CITROËN
dealer to be shown the recommended
equipment and accessories.
CITROËN has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
Happy motoring!
At the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.
Page 4 of 164
.
Contents
Instrument panel 18
Indicator and warning lamps 19
Main battery state of charge indicator 26
Energy consumption/generation indicator 27
Distance recorder 28
Tr i p d i s t a n c e r e c o r d e r 2 8
Lighting dimmer 29
Ser vice indicator 29
Range indicator 30
Monitoring Familiarisation
Remote control key 31
Electric windows 34
Doors 35
Boot 36
Charging fl aps 37
Access
Front seats 38
Rear seats 40
Mirrors 42
Interior fi ttings 44
Heating and Ventilation 47
Air conditioning 49
Rear screen demist - defrost 51
Comfort
Star ting - stopping the vehicle 52
Manual parking brake 53
Drive selector 54
Driving
Lighting controls 56
Automatic illumination of headlamps 58
Headlamp adjustment 58
Wiper controls 59
Courtesy lamp 60
Visibility
Page 7 of 164
.Familiarisation
5
31
Access
A.
Unfolding/Folding the key.
B.
Locking the vehicle.
C.
Unlocking the vehicle.
Remote control key
Bonnet
114
Electric windows
A.
Release lever.
B.
Safety catch.
C.
Bonnet stay.
A.
Driver’s electric window switch.
B.
Passenger’s electric window switch.
C.
Right hand rear electric window switch.
D.
Left hand rear electric window switch.
E.
Deactivating the passenger and rear
electric window switches.
34
Page 15 of 164
.Familiarisation
13
Passenger safety
1.
Inser t the key.
2.
Select position:
"ON"
(activation), with front passenger or
"for wards facing" child seat,
"OFF"
(deactivation), with "rear facing"
child seat.
Front passenger’s airbag
Two rings A
, located between the seat cushion
and backrest are used to secure an ISOFIX
child seat.
A ring B
is used to secure an upper strap called
the TOP TETHER
.
ISOFIX mountings
77
Child lock
A.
Child lock on.
B.
Child lock off.
68
65
Page 17 of 164
.Familiarisation
15
Driving safely
P.
Parking.
Press the brake pedal to come out of
this position.
R.
Reverse.
N.
Neutral.
D.
Drive (for ward).
Drive selector
54
- Check that the drive selector is in position P
.
- Inser t the key in the ignition switch.
- Turn the key to position 4 (START)
.
- Hold it in this position for a few seconds,
until the " READY
" lamp comes on,
accompanied by an audible signal.
- Release the key.
The switch returns automatically to
position 3 (ON)
.
Starting the motor
52
- Stop the vehicle.
- Keep your foot on the brake pedal.
- Put the drive selector in position P
.
- Apply the parking brake.
- Turn the key anti-clockwise to the LOCK
position.
Stopping the motor
52
Page 33 of 164
2
i
!
Access
31
System which permits central unlocking or locking of the vehicle using the door lock or from a distance. It is also used to start the vehicle, as well as
providing protection against theft.
Remote control key
Unlocking the vehicle
Unfolding the key
)
First press button A
to unfold the key.
Unlocking using the remote
control
)
Press the open padlock to unlock
the vehicle.
Locking the vehicle
Unlocking is confirmed by the interior lighting
which comes on for approximately 15 seconds
and the direction indicators which flash twice
.
The door mirrors unfold at the same time.
Unlocking using the key
)
Turn the key to the right in the driver's
door
lock to unlock the vehicle.
Locking is confirmed by the interior lighting,
which comes on for about 15 seconds and
the direction indicators, which flash twice
.
On the other hand, the door mirrors are not
unfolded (see § "door mirrors").
Normal locking using the remote
control
)
Press the closed padlock to lock
the vehicle.
Locking is confirmed by the direction indicators
which come on once
.
The door mirrors unfold at the same time.
Normal locking using the key
)
Turn the key to the left in the driver's door
lock to lock the vehicle.
Locking is confirmed by the direction indicators,
which flash once
.
On the other hand, the door mirrors are not
unfolded (see § "door mirrors").
The vehicle will lock itself again
automatically after thir ty seconds
unless a door or the boot is opened.
This function avoids inadvertent
unlocking.
The passenger's door lock barrel does
not lock or unlock the other doors and
the boot.
Page 34 of 164
Access
32
Folding the key
Anti-theft protection
)
First press button A
to fold the key.
Electronic engine immobiliser
The key contains an electronic chip which has a
special code. When the ignition is switched on,
this code must be recognised to permit star ting.
This electronic engine immobiliser locks the
engine management system a few moments
after the ignition is switched off and prevents
star ting of the engine by anyone who does not
have the key.
In the event of a malfunction and if your vehicle
does not start, contact a CITROËN dealer as
soon as possible.
Remote control problem
In the event of a remote control malfunction,
you can neither unlock nor lock your vehicle.
)
First of all, use the key in the driver's door
lock to unlock or lock your vehicle.
)
Then, contact a CITROËN dealer to check
the operation of the remote control and
replace the battery if necessary.
Page 35 of 164
2
!
Access
33
Lost keys
Visit a CITROËN dealer with the vehicle's V5 registration document and your personal
identification documents.
The CITROËN dealer will be able to retrieve the key code and the transponder code
required to order a replacement key.
Remote control
The high frequency remote control is a sensitive system; do not operate it while it is in your
pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of
your vehicle. You run the risk of stopping it from working.
The remote control does not operate when the key is in the ignition, even when the ignition
is switched off.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by
the emergency services more difficult in an emergency.
As a safety precaution (with children on board), remove the key from the ignition when you
leave the vehicle, even for a shor t time.
Anti-theft protection
Do not make any modifications to the electronic immobiliser system; this could cause
malfunctions.
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure that the keys in your
possession are the only ones which can star t the vehicle.
