Page 74 of 164
!
Safety
72
Anti-slip regulation (ASR)
and electronic stability
programme (ESP)
Trajectory control systems
Deactivation
In exceptional conditions (starting a vehicle
which is bogged down, stuck in snow, on soft
ground, ...), it may be advisable to deactivate
the ASR and ESP systems, so that the wheels
can move freely and regain grip.
)
Press this button button, located on the
dashboard to the right of the steering
wheel, until the corresponding symbol
appears in the instrument panel screen.
Activation
These systems are activated automatically
each time the vehicle is star ted.
They come into operation in the event of a grip
or trajectory problem.
The display of this symbol indicates
that the ASR and ESP systems are
deactivated.
Reactivation
These systems are not reactivated
automatically.
)
Press this button again to reactivate them
manually.
The symbol going off in the instrument panel
indicates the reactivation of the ASR and ESP
systems.
The anti-slip regulation (also known as Traction
Control) optimises traction to prevent skidding
of the wheels, by acting on the brakes of the
driving wheels and on the engine.
The electronic stability programme acts on the
brake of one or more wheels and on the engine
to keep the vehicle on the trajectory required
by the driver, within the limits of the laws of
physics.
This is indicated by flashing of this
warning lamp in the instrument panel.
The ASR /ESP systems offer
exceptional safety in normal driving, but
this should not encourage the driver to
take extra risks or drive at high speed.
The correct functioning of these
systems depends on obser vation of
the manufacturer’s recommendations
regarding the wheels (tyres and rims),
the braking components, the electronic
components and the assembly
and repair procedures used by the
CITROËN dealer network.
After an impact, have these systems
checked by a CITROËN dealer or a
qualified workshop.
Operating fault
The display of this message
in the instrument panel
indicates a malfunction of
these systems.
Contact a CITROËN dealer or a qualified
workshop to have the ASR /ESP systems checked.
Page 75 of 164
7
Safety
73
Seat belts
Front seat belts
Fastening
)
Pull the strap, then inser t the tongue in the
buckle A
.
)
Check that the seat belt is fastened
correctly by pulling the strap.
Front seat belt not fastened/
unfastened warning lamp
If the driver does not fasten their seat belt
within one minute after switching on the
ignition, the warning lamp flashes accompanied
by an intermittent audible signal.
After about 90 seconds, the warning lamp, the
audible signal and the display stop, and then
return until the driver fastens their seat belt.
If the seat belt is unfastened while the vehicle
is moving
, you are warned by the same aler ts.
The front seat belts are fitted with a
pretensioning and force limiting system.
This system improves safety in the front
seats in the event of a front or side impact.
Depending on the severity of the impact, the
pretensioning system instantly tightens the seat
belts against the body of the occupants.
The pretensioning seat belts are active when
the ignition is on.
The force limiter reduces the pressure of the
seat belt on the chest of the occupant,
so improving their protection.
Unfastening
)
Press the red button on the buckle A
.
When the ignition is switched on, this
warning lamp comes on accompanied
by an audible signal for a few seconds
if the driver and/or passenger has not
fastened their seat belt.
Page 130 of 164
1
2
74
5
6
3
8
9
7
01
128
FIRST STEPS
1. On/Off and volume adjustment.
2. CD eject.
3. Selection of source:
FM1, FM2, CD, USB, AUX, Streaming.
Accept an incoming call.
Long press:
- access to calls log of the telephone
connected,
- or end a call in progress.
4. Selection of a preset radio station.
Radio: long press: preset a radio station.
Other than radio: see relevant sections.
5. Display the list of stations received,
the CD/USB tracks or folders.
Long press: update the list of stations
received.
6. Abandon current operation
.
Up one level (menu or folder).
7. Automatic search for a lower/higher radio
frequency.
Selection of previous/next CD, USB track.
Navigation in a list.
Maintained press: fast forwards or
backwards.
8. Main menu.
9. Audio settings:
equalizer, treble, bass, loudness,
distribution, left/right balance, front/rear
balance, automatic volume.
Page 131 of 164
02
1
12
2
3
129
RADIO
Press SRC/TEL several times in
succession and select the FM1 or FM2
radio band.
Press a button to listen to the
corresponding preset station.
Select the desired radio station and
confi rm by pressing "OK"
.
RADIO
Press LIST
to display the list of stations
received in alphabetical order.
The exterior environment (hills, buildings, tunnel, car park, below ground...) may prevent reception, even in RDS station tracking mode.
This phenomenon is normal in the propagation of radio waves and is in no way indicative of a fault with the audio system.
A long press on LIST
builds or updates
the list of stations; audio reception is cut
momentarily.
Make a long press on one of the buttons
to preset the station being heard.
The name of the station is displayed
accompanied by an audible signal to
confi rm the preset.
A press changes to the next or previous
letter (e.g. A, B, D, F, G, J, K, ...).
MANAGE THE LIST
PRESETTING AND SELECTING A STATION
Page 132 of 164
1
2
02
1
2
130
RDS, if displayed, enables you to continue listening to the same
station by automatic retuning to alternative frequencies. However,
in certain conditions, coverage of an RDS station may not be
assured throughout the country as radio stations do not cover
100 % of the territory. This explains the loss of reception of the
station during a journey.
RADIO
RDS
When the radio is displayed in the
screen, press MENU
then select
"Radio"
.
Select or deselect "RDS"
to activate or
deactivate RDS then confi rm with "OK"
to save the setting.
ENTER A FREQUENCY MANUALLY
Press MENU
, select "Radio"
, then
select "Write freq."
.
Press +
or -
to select the desired
frequency and confi rm with "OK"
.
Page 133 of 164
1
2
02
1
131
RADIO
Radio text is information transmitted by the radio station related to
the current programme or song.
With the radio displayed on the screen,
press MENU
then select "Radio"
.
Select or deselect "
TXT
"
to activate or deactivate the display of
Radio Text.
DISPLAY RADIO TEXT
RECEIVING TA MESSAGES
The TA (Traffi c Announcement) function gives priority to TA alert
messages. To operate, this function needs good reception of a
radio station transmitting this type of message. When a traffi c
report is transmitted, the current audio source (Radio, CD,
USB, ...) is interrupted automatically to play the TA message.
Normal playback of the audio source resumes at the end of the
transmission of the message.
Press MENU
, select "Radio"
, then
select or deselect "TA"
to activate
or deactivate the reception of traffi c
messages.
Page 134 of 164
03
1
2
132
AUDIO
AUDIO CD
Insert 12 cm diameter circular compact discs only.
Some anti-pirating systems, on original discs or CDs copied using
a personal recorder, may cause faults which are no refl ection on
the quality of the original player.
Without pressing the EJECT
button, insert a CD in the player, play
begins automatically.
To play a disc which has already been
inserted, press the SRC/TEL
button
several times until CD play is displayed.
Press one of the buttons to select a
track on the CD.
Press and hold one of the buttons for
fast forward or backward.
PLAYING A CD
Page 137 of 164
7
6
8
9
03
5
10
135
Select a line in the list.
Jump a page.
Select the play mode: "Normal"
,
"Random"
, "TA"
, "Random all"
or
"Repeat"
.
Up a level in the menu.
AUDIO
Return to the top level of the folder structure to select the type of
tracks.
- By Folders
(CD or USB): all folders containing audio fi les
recognised on the peripheral device, in alphabetical order without
following the folder structure.
- By Artist
(USB only): all of the artist names defi ned in the
ID3 Tags, in alphabetical order.
- By Genre
(USB only): all of the genres defi ned in the ID3 Tags.
- By Playlist
(CD or USB): if playlists have been saved.
Press LIST
to display the menu of
Folders in the compilation.
Press MENU
, select "Media"
then
select or deselect "TA"
to activate or
deactivate reception of traffi c messages.
