2011.5 Citroen C5 RHD bluetooth

7
FAMILIARISATION



129

INTERIOR


Electric parking brake

The electric parking brake combines automatic application when the
engine is switched off, and automatic release when the vehicle is set in
motion (automatic function activated by default).
Manual application/release is possible.
Parking space sensor

The "Parking space sensor"
system assists you in fi nding a
parking space.
Dual-zone digital air conditioning

This air conditioning system provides inde-
pendent adjustment of the comfort levels for
the driver and front passenger.
Audio and communication systems

These systems benefi t from the latest techno-
logy: MP3 compatible radio, Bluetooth® system,
NaviDrive 3D, MyWay.



54


225



157

II
43
MULTIFUNCTION SCREENS











MONOCHROME SCREEN C

Main Menu

Press on the button A
to view the
Main Menu of the multifunction
screen. This menu gives you access
to the following functions:

Presentation

Radio-CD

(see "Audio and Telematics"
chapter)


Bluetooth ®
system

(see "Audio and Telematics"
chapter)


Controls



1.
Time

2.
Ambient temperature

3.
Date and display zone
When the outside temperature is
between +3 °C and -3 °C, the tem-
perature display fl ashes (ice risk).
The ambient temperature displayed
may be greater than the actual tem-
perature, if the vehicle is parked in
bright sunlight.
It is recommended that the driver
should not operate the controls
while the vehicle is in motion.


Personalisation -
Configuration
This permits activation/deactivation of the:


- brightness and contrast of the
multifunction screen,

- date and time,

- units of the outside temperature
displayed.



A.
Access to the "Main Menu"

B.
Cancellation of the operation or
return to the previous display

C.
Scrolling in the screen menus
Confi rmation at the steering
wheel

D.
Confi rmation on the audio equip-
ment control panel

XI
195
PRACTICAL INFORMATION
FUSEBOX C



Fuse N°



Rating



Function




F1



15 A

Rear screen wipe (Tourer)


F2



30 A

Locking and deadlocking relay


F3



5 A

Airbags


F4



10 A

Automatic gearbox - additional heater unit (Diesel) -
electrochrome rear view mirror


F5



30 A

Front window - sunroof - passenger door lighting -
passenger door mirror adjustment


F6



30 A

Rear window


F7



5 A

Vanity mirror lighting - Glove box lighting - interior lamps -
torch (tourer)


F8



20 A

Radio - CD changer - Steering mounted controls - Screen - Under-infl ation detection -
Electric boot ECU


F9



30 A

Cigar lighter - front 12 V socket


F10



15 A

Alarm - Steering mounted controls, signalling and wiper controls


F11



15 A

Low current ignition switch


F12



15 A

Driver’s electric seat - instrument panel - seat belt not fastened warning lamps -
air conditioning controls


F13



5 A

Engine relay unit - Hydraulic suspension pump cut-off relay -
airbag ECU supply


F14



15 A

Rain and sunshine sensor - parking sensors - passenger’s electric seat -
trailer relay unit - HIFI amplifi er ECU - Bluetooth system -
Lane Departure Warning System


F15



30 A

Locking and deadlocking relay


F17



40 A

Heated rear screen - heated door mirrors


FSH



SHUNT

PARK SHUNT

227
2ABC3DEF5JKL4GHI6MNO8TUV7PQRS9WXYZ0*#
1RADIO MEDIANAV ESC TRAFFIC
SETUPADDR
BOOK
2ABC3DEF5JKL4GHI6MNO8TUV7PQRS9WXYZ0*#
1RADIO MEDIANAV ESC TRAFFIC
SETUPADDR
BOOK
EMERGENCY OR ASSISTANCE CALL USING
NAVIDRIVE 3D









EMERGENCY CALL


In an emergency, press the SOS button until an audible
signal is heard and a "Confi rmation/Cancellation"
screen is displayed (if valid SIM card inserted).
A call is made to the CITROËN Emergency team which
receives locating information from the vehicle and
can send a detailed alert to the relevant emergency
services.
In countries in which the team is not operational, or
when the locating service has been expressly declined,
the call is sent to the emergency services (112).
Warning - the emergency call and the services are only active
if the internal telephone is used with a valid SIM card. With a
Bluetooth telephone and without a SIM card, these services are not
operational.

Press this button for access to CITROËN services.

Customer call


If an impact is detected by the airbag control unit, and independently
of the deployment of any airbags, an emergency call is made
automatically.
The message "Deteriorated emergency call" associated with
fl ashing of the orange indicator lamp indicates a malfunction.
Consult a CITROËN dealer.











ASSISTANCE CALL

Select "Customer call" to request
any information about the CITROËN
marque.
Select "CITROËN Assistance" to make
a breakdown assistance call.

CITROËN Assistance




This service is subject to conditions and availability. Consult a
CITROËN dealer. If you have purchased your vehicle outside the
CITROËN dealer network, we invite you to have a dealer check the
confi guration of these services and, if desired, modifi ed to suit your
wishes.

229
2ABC3DEF5JKL4GHI6MNO8TUV7PQRS9WXYZ0*#
1
RADIO MEDIANAV ESC TRAFFIC
SETUPADDR
BOOK

The NaviDrive 3D is protected in such a way that it
will only operate in your vehicle. If it is to be installed
in another vehicle, contact a CITROËN dealer for
confi guration of the system.

Certain functions described in this handbook will
become available during the course of the year.







NAVIDRIVE 3D


For safety reasons, it is imperative that the driver
carries out operations which require prolonged attention
while the vehicle is stationary.
When the engine is switched off and to prevent
discharging of the battery, the NaviDrive 3D switches off
following the activation of the Energy Economy mode.


01 First steps

02 Voice commands and steering
mounted controls

03 General operation

04 Navigation - Guidance

05 Traffic information

06 Radio

07 Music media players

08 Using the telephone

09 Configuration

10 Screen menu map p.
p.
p.
p.
p.
p.
p.
p.
p.
p. 230
232
235
240
249
251
252
257
261
262
CONTENTS

Frequently asked questions p. 267
MULTIMEDIA AUDIO SYSTEM/BLUETOOTH TELEPHONE
GPS EUROPE

230
01
2ABC3DEF
5JKL4GHI6MNO
8TUV7PQRS9WXYZ
0*#
1
RADIO MEDIANAV ESC TRAFFIC
SETUPADDR
BOOK
1
10
2
3
4
612
9
7
8
115
TU PQRS
0*

1. CD eject.

2. RADIO: access to the "Radio" Menu.
Display the list of stations in alphabetical
order (FM waveband) or frequency order
(AM waveband).
MEDIA: access to the "Media" Menu (Audio CD,
Jukebox, External Device).
Display the list of tracks. Change of source.
NAV: access to the "Navigation" Menu and display
of the last destinations.
ESC: abandon the operation in progress.
Long press: return to the main display.
TRAFFIC: access to the "Traffi c" Menu (function
described in detail in sections 02 and 10). ADDR BOOK: access to the "Address book" Menu
(function described in detail in section 10).
SETUP: access to the "SETUP" Menu
(confi guration) (function described in detail in
sections 02 and 10).
Long press: GPS coverage.

3. Audio settings (Balance/Fader, Bass/Treble,
Musical Ambience...).

4. Volume adjustment (each source is independent,
including message and navigation alert)
.
Long press: reinitialisation of the system.
Short press: mute.

5. Automatic search for a radio station on a lower
frequency.
Selection of the previous CD or MP3 track.
FIRST STEPS


NaviDrive 3D CONTROL PANEL


6. Automatic search for a radio station on a higher frequency. Selection of the next CD or MP3 track.

7. Normal display or black screen.

8. Selection of the successive display on the screen
of "MAP"/"NAV" (if navigation is in progress)/"TEL"
(if a conversation is in progress)/"RADIO" or
"MEDIA" currently being played.

9. PICK UP: access to the "Phone" menu.
With Bluetooth connection, accept an incoming call.

10. HANG UP: access to the "Phone" menu.
Hang up the current call or refuse an incoming
call, with Bluetooth connection.

11. Entering of numbers or letters on the alpha-numeric
keypad, pre-selection of 10 radio frequencies.

12. SD card reader.


Short press: clears the last
character.

Long press: activates voice
recognition.

246
04
1
2
3
1
2
3

CITROËN SEND-TO-CAR with


REGISTRATION AND ACTIVATION
USE

The SIM card must be inserted in the support located in the glove
box. The system does not operate with the Bluetooth connection. This service only operates with a SIM card from a French, German
or Italian service provider.

SIM cards the numbers of which have been the subject of a change
of service provider are not compatible with this service.

To access the registration site, go to www.citroen.fr then activate
the account with the registration confi rmation email.

Register the vehicle and choose the identifi er, which will be used to
send POIs from Google Maps.

Activate the service on your NaviDrive 3D in accordance with the
operating procedure downloaded from the internet website.
It may take a few minutes for the Google Maps menu to appear.

In order to activate the service, the SIM card used must be that
declared on the Internet site during registration.
Once the service has been activated, you can change SIM card or
service provider.

Search for a POI on http://maps.google.fr. Select it and click on
"send".
Select "vehicle" and "CITROËN" then enter the identifi er chosen.
Click on "send". Find your destinations on Google Maps then let CITROËN guide you.

Only the Google Maps results symbolised by a red icon can be sent
to the NaviDrive 3D system.
The "Notes" fi eld is not sent.

Press this button then select Google Maps and
confi rm by pressing OK.
An automatic call is triggered to a voice mail for
receipt of the POI.

Press on "ADDR BOOK" and select "My Addresses" to display the
list of POIs received.
You can then start guidance, call the POI or display it on the map.

This service is free, with the exception of the cost of the
communication - 2 SMS and 1 call for activation, 1 call for each
receipt of a POI (approximately 30 seconds).


NAVIGATION - GUIDANCE

257
08
1
2ABC3DEF5JKL4GHI6MNO8TUV7PQRS9WXYZ0*#
1RADIO MEDIANAV ESC TRAFFIC
SETUPADDR
BOOK
2
2ABC3DEF5JKL4GHI6MNO8TUV7PQRS9WXYZ0*#
1RADIO MEDIANAV ESC TRAFFIC
SETUPADDR
BOOK















CHOOSING BETWEEN THE BLUETOOTH
TELEPHONE/INTERNAL TELEPHONE

To activate the Bluetooth telephone
or the internal telephone, press PICK
UP TEL.

USING THE TELEPHONE


Select Phone menu, then "Select
phone" then choose between
"Telephone off", "Use Bluetooth
phone" or "Use internal phone".
Press OK at each step to confi rm.

The system can only be connected to one Bluetooth telephone and
one SIM card (Internal telephone) at the same time.
In this case, the phone book is synchronised with the Bluetooth
telephone.
