2010 TOYOTA SIENNA audio

312
3-3. Using the rear audio system
Using the DVD player (video CD)
■Remote controller
Selecting a switch (icon)
Selecting a chapter
Playing/pausing a disc
Reversing a disc
Displaying operation
switches (icon)
Inputting the selected
switch (icon)
Fast forwarding a disc
Stopping a disc
Changing the initial setting
■ Unit
Skipping to the desired
chapter
Playing/pausing a disc
Selecting a switch (icon)
Inputting the selected
switch (icon)

313
3-3. Using the rear audio system
3
Interior features
■
Display (page 1)
Selecting a disc menu num-
ber
Turning off the menu screen
Displaying page 2
Turning on the disc menu
Returning to the previous
page screen (with the disc
menu displayed)
Proceeding to the next page
screen (with the disc menu
displayed)
Changing to a multiplex
transmission
■ Display (page 2)
Displaying page 1
Reversing a disc
Pausing the disc/canceling
the pause
Fast forwarding a disc
■ Front audio system
Selecting a chapter
Selecting either the front
audio system or DVD player
audio for the speakers

314 3-3. Using the rear audio system
Selecting a disc menu numberSelect
to display the disc menu number search screen.
Select the disc menu number, and press or to input it.
Select to return to the previous screen.
Slow playback
Press or select and then press or select . Video
is played slowly when you press or select by pressing and
holding or .

315
3-3. Using the rear audio system
3
Interior features
Using the DVD player (audio CD/CD text)
■Canceling random, repeat and scan play
Select , or again.
Using the control screen,
press or to display
the control screen.
Repeat play
Random playback
Search playback
■ Front audio system
Selecting a track
Selecting either the front
audio system or DVD player
audio for the speakers

316
3-3. Using the rear audio system
Using the DVD player (MP3 discs)
Repeat play■ Repeating a file
Select .
■ Repeating all of files in a folder
Select , and press and hold or .
■Using the control screen
Press or to dis-
play the control screen.
Repeat play
Random playback
Search playback
Displaying file information
Selecting a folder
■ Front audio system
Selecting a file
Selecting either the front
audio system or DVD player
audio for the speakers

317
3-3. Using the rear audio system
3
Interior features
Random playback
■ Playing files from a particular folder in random order
Select .
■ Playing all of the files on a disc in random order
Select , and press and hold or .
Search playback
■ Selecting the desired file by cueing the files in the folder
Select .
The player will scan all the files in the folder. Each file will be
played for 10 seconds.
■ Selecting the desired file by cueing the folders on the disc
Select , and press and hold or .
The player will scan all the folders on the disc. The first file in each
folder will be played for 10 seconds.
■ Canceling random, repeat and play back
Select , or again.

318
3-3. Using the rear audio system
Using the video mode
Using the adapterOpen the cover.
The A/V input adapter is com-
posed of 3 input adapters.
Yellow: Image input adapter
White: Left channel audio input
adapter
Red: Right channel audio input
adapter
Press or to select
the video mode.
Before switching to the video
mode, connect the audio
device to the A/V input
adapter.
■A/V input adapter
The rear seat entertainment system plays videos and sounds when audio-
video device is connected to the A/V input adapter. For details, refer to the
manufacturer's instructions.
■ Power outlet
The power outlet is used to connect the audio device. ( P. 387)

319
3-3. Using the rear audio system
3
Interior features
NOTICE
■
When the A/V input adapter is not in use
Keep the A/V input adapter cover closed.
Inserting anything other than an appropriate plug may cause electrical fail-
ure or short circuit.
