2010 TOYOTA SIENNA audio

423
4-1. Maintenance and care
4
Maintenance and care
NOTICE
■
Cleaning detergents
Do not use organic substances such as benzene or gasoline, acidic or alka-
line solutions, dye, bleach or other detergent. Doing so may discolor the
vehicle interior or cause streaks or damage to painted surfaces.
■ Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration o\
f
leather surfaces.
●Remove any dust or dirt on leather surfaces immediately.
● Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.
● Do not place items made of vinyl, plastic, or that contain wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.
■ Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components under the floor of the vehicle, and
may also cause the body to rust.
■ Cleaning the inside of the rear wi ndow and the rear quarter windows
● Do not use glass cleaner to clean the rear window and the rear quarter
windows, as this may cause damage to the rear window defogger heater
wires or print type antenna (if equipped). Use a cloth dampened with luke-
warm water to gently wipe the windows clean. Wipe the windows in
strokes running parallel to the heater wires or print type antenna (if
equipped).
● Be careful not to scratch or damage the heater wires or print type antenna
(if equipped).

479
4-3. Do-it-yourself maintenance
4
Maintenance and care
8 RAD NO.1 15 A Audio system
9 EFI NO.1 20 A
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO.2
10 ALT-S 7.5 A Charging system
11 HAZ 15 A Turn signal lights, emergency
flashers
12 ECU-B 10 A Power sliding door, air conditioning
system, power windows, multiplex
communication system, meter and
gauge, wireless remote control sys-
tem
13 H-LP RH 15 A Right-hand headlight
14 H-LP LH 15 A Left-hand headlight
15 RAD NO.3 30 A Audio system
16 EFI NO.2 10 A Multiport fuel injection system/
sequential multiport fuel injection
system
17 A/F 25 A Multiport fuel injection system/
sequential multiport fuel injection
system
18 SPARE 15 A Spare fuse
19 SPARE 20 A Spare fuse
20 SPARE 30 A Spare fuse
21 SPARE 30 A Spare fuse
22 RR2 SEAT 50 A Power third seat
23 HTR 50 A Air conditioning system, A/C
24 FAN 50 A Electric cooling fans
25 PBD 30 A Power back door
26 R-PSD 30 A Right side power sliding door
FuseAmpereCircuit

481
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
Under the driver’s side instrument panel
FuseAmpereCircuit
1 MIR HTR 10 A Outside rear view mirror defoggers
2RAD2 7.5 A Audio system, navigation system,
rear seat entertainment system
3 PWR OUTLET 15 A Power outlets
4 CIG 15 A Cigarette lighter
5 ECU ACC 7.5 A Shift lock control system, air condi-
tioning system, power rear view
mirror control
6 GAUGE2 7.5 A Meter and gauge
7 IGN 7.5 A Multiport fuel injection system/
sequential multiport fuel injection
system, SRS airbag system, multi-
plex communication system
8 IG2 7.5 A Multiport fuel injection system/
sequential multiport fuel injection
system
9 RR WIP 15 A Rear window wiper
10 WIP 30 A Windshield wiper and rear window
wiper
11 GAUGE1 10 A Back-up lights, turn signal lights,
emergency flashers
12 S-HTR 15 A Seat heaters

482 4-3. Do-it-yourself maintenance
13 WSH20 AWindshield washer and rear win-
dow washer
14 HTR 10 A Air conditioning system
15 ECU-IG 10 AIntuitive parking assist system, rear
view monitor system, multiplex
communication system, multiport
fuel injection system/sequential
multiport fuel injection system, anti-
lock brake system, traction control
system, vehicle stability control
system, shift lock control system,
dynamic laser cruise control sys-
tem, seat heaters, power back
door, moon roof, multi-information
display, auto anti-glare inside rear
view mirror, power windows, power
outlets (115 V), power third seat,
driving position memory system
16 PANEL 10 AAir conditioning system, seat heat-
ers, audio system, navigation sys-
tem, power sliding door, power
back door, trip information display,
rear window defogger, emergency
flashers, instrument panel lights,
steering switch lights
17 TAIL 10 AStop/tail lights, license plate lights,
parking lights, side maker lights
18 S/ROOF 25 A Moon roof
19 AC INV 15 A Power outlets (115 V)
20 FR DEF 15 A Windshield wiper de-icer
21 AM1 7.5 AMultiport fuel injection system/
sequential multiport fuel injection
system, starter system
FuseAmpereCircuit

5
When trouble arises
533
5-2. Steps to take in an emergency
■
Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
■ Avoiding a discharged battery
●Turn off the headlights and the audio system while the engine is turned
off.
● Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
■ When the battery is removed or discharged
●The power sliding door (if equipped) must be initialized. ( P. 37)
● The power back door (if equipped) must be initialized. ( P. 47)
● The power window must be initialized. ( P. 100)
● The moon roof (if equipped) must be initialized. ( P. 104)
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at your Toyota
dealer as soon as possible.STEP4

Index
575
Abbreviation list ..................... 576
Alphabetical index .................. 578
What to do if... ........................ 589
For details of equipment related to the navigation sys-
tem and touch screen, such as the audio system, refer
to the “Navigation System Owner's Manual”.

578
Alphabetical index
Alphabetical index
A/C ..................... 240, 246, 256, 253
ABS ........................................... 215
Air conditioning filter............... 469
Air conditioning systemAir conditioning filter .............. 469
Front automatic air conditioning system ............ 246
Front manual air conditioning system ................................ 240
Rear automatic air
conditioning system ............ 256
Rear manual air conditioning system ................................ 253
Airbags Airbag operating conditions............................ 121
Airbag precautions for your child .................................... 125
Airbag warning light............... 505
Curtain shield airbag operating
conditions............................ 121
Curtain shield airbag
precautions ......................... 125
Front passenger occupant classification system ........... 130
General airbag precautions ......................... 125
Locations of airbags .............. 118
Modification and disposal of
airbags ................................ 129
Proper driving
posture ........................ 116, 125 Side airbag operating
conditions ........................... 121
Side airbag precautions ........ 125
SRS airbags .......................... 118
Alarm......................................... 113
Antenna .................................... 268
Anti-lock brake system ........... 215
Armrest ..................................... 392
Audio input ............................... 291
Audio system A/V input adapter .................. 318
Antenna................................. 268
Audio input ............................ 291
Audio visual input .................. 318
AUX adapter ......................... 291
CD player/changer ................ 271
DVD player.... 303, 312, 315, 316
MP3/WMA disc ..................... 279
Optimal use ........................... 287
Portable music player ........... 291
Radio..................................... 265
Rear seat entertainment system ................................ 296
Steering wheel audio switch.................................. 292
Type ...................................... 262
Audio visual input.................... 318
Automatic light control system .................................... 185
Automatic transmission .......... 170
AUX adapter ............................. 291
Auxiliary box ........................... 375
A/V input adapter ..................... 318A

586 Alphabetical index
Spare tireInflation pressure................... 548
Spare tire............................... 516
Spark plug ................................ 546
Specifications........................... 542
Speech command switch ........ 332
Speedometer ............................ 174
Steering Column lock release.............. 167
Steering wheel Adjustment ..............................94
Audio switches ...................... 292
Stop lights Replacing light bulbs ............. 486
Wattage ................................. 549
Storage feature......................... 364
Storage precautions ................223
Stuck If your vehicle becomes stuck ................................... 539
Sunshades Rear door .............................. 393
Roof....................................... 105
Sun visors................................. 383
Switch Engine switch ........................ 167
Fog light switch ..................... 190
Ignition switch........................ 167
Light switches........................ 185
Power door lock switch ...........33
Power window switch .... 100, 102
Window lock switch ............... 100
Wiper and washer
switch .......................... 191, 193 Tables
Front seat side table ............. 399
Seatback tables .................... 397
Tachometer .............................. 174
Tail lights Replacing light bulbs ............. 486
Switch ................................... 185
Wattage................................. 549
Talk switch ............................... 332
Telephone switch..................... 332
Theft deterrent system Alarm..................................... 113
Engine immobilizer system ... 111
Theft prevention labels ........... 115
Third seats.................................. 61
Tire inflation pressure ............. 463
Tire information
Glossary ................................ 559
Size ....................................... 548
Tire identification number...... 555
Uniform tire quality grading................................ 557
Tires
Chains ................................... 226
Checking ............................... 454
If you have a flat tire...... 515, 516
Inflation pressure .................. 463
Information ............................ 553
Replacing .............................. 516
Rotating tires ......................... 454
Size ....................................... 548
Snow tires ............................. 226
Tire pressure warning system ........................ 454, 507
Tools ......................................... 516
Total load capacity .................. 225T
