2010 SUBARU FORESTER Owners Manual

10
Illustrated index &Exterior1) Engine hood (page 11-5)
2) Headlight switch (page 3-25)
3) Replacing bulbs (page 11-46)
4) Wiper switch (page 3-30)
5) Moonroof (page 2-23)
6) Roof rail (page 8-14)
7) Door locks (page 2-4)
8) Tire pressure (page 11-32)
9) Flat tires (page 9-6)
10) Tire chains (page 8-11)
11) Front fog light switch (page 3-28)
12) Tie-down hooks (page 9-12)
13) Towing hook (page 9-12)

1) Rear window defogger button(page 3-40)
2) Fuel filler lid and cap (page 7-3)
3) Child safety locks (page 2-19)
4) Tie-down hook (page 9-13)
5) Rear gate (page 2-22)
6) Towing hook (page 9-13) 11
– CONTINUED –

12 &Interior
! Passenger compartment area
1) Lower anchorages for child restraint
system (page 1-30)
2) Seatbelt (page 1-11)
3) Parking brake lever (page 7-31)
4) Front seat (page 1-2)
5) Rear seat (page 1-7)

1) Center console (page 6-5)
2) Cup holder (page 6-8)
3) Front power supply socket (page 6-9)
4) Glove box (page 6-5)13
– CONTINUED –

14 &Instrument panel
1) Door locks (page 2-4)
2) Outside mirror switch (page 3-39)
3) Illumination brightness control
(page 3-27)
4) Light control lever (page 3-25)
5) Combination meter (page 3-5)
6) Wiper control lever (page 3-29)
7) Hazard warning flasher switch (page 3-5)
8) Audio (page 5-1)
9) Shift lever (MT) (page 7-14)/ Select lever (AT) (page 7-15)
10) Climate control (page 4-1)
11) Cruise control (page 7-34)
12) Horn (page 3-43)
13) SRS airbag (page 1-35)
14) Tilt/telescopic steering (page 3-42)
15) Audio control buttons (page 5-28)
16) Fuse box (page 11-44)
17) Vehicle Dynamics Control OFF switch (page 7-29)
18) Hood lock release knob (page 11-5)
19) Power windows (page 2-20)

&Light control and wiper control levers/switches1) Windshield wiper (page 3-30)
2) Mist (page 3-31)
3) Windshield washer (page 3-31)
4) Rear window wiper and washer switch
(page 3-31)
5) Wiper intermittent time control switch (page 3-30)
6) Wiper control lever (page 3-29)
7) Light control switch (page 3-25)
8) Fog light switch (page 3-28)
9) Headlight ON/OFF (page 3-25)
10) Headlight flasher High/Low beam change (page 3-26)
11) Turn signal (page 3-27) 15
– CONTINUED –

16 &Combination meter
! U.S.-spec. models
1) Tachometer (page 3-8)
2) Speedometer (page 3-6)
3) Fuel gauge (page 3-8)
4) Trip meter A/B selection and trip meter
reset knob (page 3-6)
5) Odometer/Trip meter (page 3-6)
6) Select lever and gear position indicator (AT models) (page 3-21)
7) Coolant temperature low indicator light/ Coolant temperature high warning light
(page 3-13)

!Except U.S.-spec. models1) Tachometer (page 3-8)
2) Speedometer (page 3-6)
3) Fuel gauge (page 3-8)
4) Trip meter A/B selection and trip meter
reset knob (page 3-6)
5) Odometer/Trip meter (page 3-6)
6) Select lever and gear position indicator (AT models) (page 3-21)
7) Coolant temperature low indicator light/ Coolant temperature high warning light
(page 3-13) 17
– CONTINUED –
