67
The seat cushion lowers to be
covered by the seat back; this
l e a v e s a fl a t b o o t fl o o r , i f t h e
a d j u s t a b l e fl o o r i s i n t h e i n t e r m e d i a t e
position.
F o l d i n g t h e s e a t f r o m t h e r e a r
Check that no object, either on or un-
derneath the seat, could hinder its
movement.
Move the corresponding front seat
forwards if necessary,
check that the seat belt is positioned
correctly on the side of the seat
back,
place the head restraints in the low
position or remove them if necessary,
pull the control 1 forwards to release
the seat back 2 which tilts easily
onto the seat cushion 3 .
R e t u r n i n g t h e s e a t b a c k t o i t s o r i g i n a l p o s i t i o n
Put the seat back in the upright posi-
tion and secure it, the seat cushion
also returns to its original position,
check that the red indicator, located
at the control 1 , is no longer visible,
r e fi t t h e h e a d r e s t r a i n t s o r p u t t h e m
back in place.
When returning the rear seat back to
its original position, take care not to
trap the seat belts and ensure that their
buckles are positioned correctly.
Page 80 of 315
78
The electric window controls
remain operational for ap-
proximately 45 seconds after
the ignition is switched off or until the
vehicle is locked after a front door is
opened.
If one of the passenger windows can-
n o t b e o p e r a t e d f r o m t h e d r i v e r ' s d o o r
control pad, carry out the operation
from the control pad of the passen-
ger door concerned, and vice versa.
ELECTRIC WINDOWS
System intended to open or close a
window manually or automatically. Fit-
ted with a safety anti-pinch system and
a system for deactivation in the event of
misuse of the rear controls.
1. Driver's electric window control.
2. Passenger's electric window
control.
3. Rear right electric window
control.
4. Rear left electric window control.
5. Deactivation of the rear electric
window and door controls. I f t h e w i n d o w c a n n o t b e c l o s e d
(for example, in the presence
of ice), immediately after the
movement is reversed:
press and hold the control until
the window opens fully,
then pull the control immediately
and hold it until the window closes,
continue to hold the control for
approximately one second after
the window has closed.
The safety anti-pinch function is not
operational during these operations.
Safety anti-pinch
When the window rises and meets an
o b s t a c l e , i t s t o p s a n d p a r t i a l l y l o w e r s
again.
-
automatic mode
P r e s s o r p u l l t h e c o n t r o l fi r m l y .
The window opens or closes fully
when the control is released.
Pressing the control again stops
the movement of the window.
One-touch electric windows
There are two options:
- manual mode
Press or pull the control gently.
The window stops when the
control is released. After approximately ten con-
secutive complete opening/
closing movements of the win-
dow, a protection function is activated
to prevent damage to the electric win-
dow motor.
After this, you have approximately
one minute within which to close the
window.
O n c e t h e w i n d o w i s c l o s e d , t h e c o n -
t r o l s w i l l b e c o m e a v a i l a b l e a g a i n a f -
ter approximately 40 minutes.
Page 86 of 315
83
LOWER TAILGATE
Opening
Push the handle C to the right and
tilt the tailgate D gently.
Closing
Raise the tailgate D , push it fully to
close it, check that it is secured cor-
rectly. B e f o r e o p e n i n g t h e b o o t , e n -
sure that no one is within the
radius of opening.
For reasons of safety, correct opera-
tion and compliance with regulations,
d o n o t d r i v e w i t h t h e b o o t a n d t h e
lower tailgate open.
I f t h e b a t t e r y i s d i s c o n n e c t e d , t h e
b o o t c a n n o t b e o p e n e d .
D o n o t c l i m b o n t o t h e l o w e r t a i l g a t e
a n d d o n o t s u b j e c t i t t o h e a v y k n o c k s ,
i t m a y b e d a m a g e d .
Always close the lower tailgate and
c h e c k t h a t i t i s s e c u r e d c o r r e c t l y b e -
f o r e c l o s i n g t h e b o o t .
When closing the lower tailgate, en-
s u r e t h a t n o p e r s o n o r o b j e c t i s i n t h e
proximity of the moving parts to avoid
a n y r i s k o f i n j u r y o r d a m a g e .
Do not open the lower tailgate
w h e n a t o w b a r i s fi t t e d .
Maximum authorised weight
on the lower tailgate when
open: 200 kg .
Page 87 of 315
84
T h e k e y c a n n o t b e r e m o v e d
from the lock until the cap is
p u t b a c k o n t h e t a n k .
O p e n i n g t h e c a p m a y t r i g g e r a n i n -
rush of air. This vacuum, which is
c o m p l e t e l y n o r m a l , i s c a u s e d b y t h e
sealing of the fuel system.
FUEL TANK
Capacity of the tank: approximately
60 litres. T o fi l l t h e t a n k s a f e l y :
it is essential that the engine is
switched off,
o p e n t h e f u e l fi l l e r fl a p ,
insert the key in the cap, then turn it
to the left,
When refueling is complete:
p u t t h e c a p b a c k i n p l a c e ,
turn the key to the right, then remove
it from the cap,
c l o s e t h e fi l l e r fl a p .
remove the cap and secure it on the
hook, located on the inside of the
fl a p ,
fi l l t h e t a n k , b u t do not continue af-
ter the 3rd cut-off of the nozzle ;
this could cause malfunctions.
Low fuel level
Operating fault
A malfunction of the fuel gauge is indi-
c a t e d b y t h e r e t u r n t o z e r o o f t h e f u e l
level indicator needle.
H a v e i t c h e c k e d b y a P E U G E O T d e a l e r .
Refueling
A l a b e l a f fi x e d t o t h e i n s i d e o f t h e fi l l e r
fl a p r e m i n d s y o u o f t h e t y p e o f f u e l t o b e
used according to your engine.
M o r e t h a n 5 l i t r e s o f f u e l m u s t b e a d d -
e d i n o r d e r t o b e r e g i s t e r e d b y t h e f u e l
gauge. When the fuel tank minimum
level is reached, this warning
lamp comes on on the instru-
m e n t p a n e l , a c c o m p a n i e d b y a n
a u d i b l e s i g n a l a n d a m e s s a g e
on the multifunction screen.
W h e n t h e l a m p fi r s t c o m e s o n , y o u h a v e
approximately 6 litres of fuel remaining.
You must refuel to avoid run-
ning out of fuel.
If you run out of fuel (Diesel), re-
fer also to the "Checks" section.
Page 108 of 315
FITTINGS
100
To avoid any risk of jamming
of the pedals:
MATS
Removable carpet protection. Refitting
T o r e fi t t h e m a t o n t h e d r i v e r ' s s i d e :
position the mat correctly,
r e fi t t h e fi x i n g s b y p r e s s i n g ,
check that the mat is secured cor-
rectly.
Fitting
W h e n fi t t i n g t h e m a t f o r t h e fi r s t t i m e ,
o n t h e d r i v e r ' s s i d e u s e o n l y t h e fi x i n g s
provided in the wallet attached.
The other mats are simply placed on
the carpet.
Removal
To remove the mat on the driver's side:
move the seat as far back as pos-
sible,
u n c l i p t h e fi x i n g s ,
remove the mat. - only use mats which are suited to
t h e fi x i n g s a l r e a d y p r e s e n t i n t h e
v e h i c l e ; i t i s i m p e r a t i v e t h a t t h e s e
are used,
-
n e v e r fi t o n e m a t o n t o p o f a n o t h e r.
Page 113 of 315
FITTINGS
100
To avoid any risk of jamming
of the pedals:
MATS
Removable carpet protection. Refitting
T o r e fi t t h e m a t o n t h e d r i v e r ' s s i d e :
position the mat correctly,
r e fi t t h e fi x i n g s b y p r e s s i n g ,
check that the mat is secured cor-
rectly.
Fitting
W h e n fi t t i n g t h e m a t f o r t h e fi r s t t i m e ,
o n t h e d r i v e r ' s s i d e u s e o n l y t h e fi x i n g s
provided in the wallet attached.
The other mats are simply placed on
the carpet.
Removal
To remove the mat on the driver's side:
move the seat as far back as pos-
sible,
u n c l i p t h e fi x i n g s ,
remove the mat. - only use mats which are suited to
t h e fi x i n g s a l r e a d y p r e s e n t i n t h e
v e h i c l e ; i t i s i m p e r a t i v e t h a t t h e s e
are used,
-
n e v e r fi t o n e m a t o n t o p o f a n o t h e r.
Page 119 of 315
FITTINGS
When changing a wheel
The hooks permit easy access
to the spare wheel by retain-
ing the boot carpet by means of the
two cords.
The hooks permit the securing of
shopping bags.
Hooks
In order to connect a 12 V accessory
(max power: 120 Watts), remove
the cap and connect the appropriate
adaptor.
Turn the key to the ignition position.
12 V accessories socket Luggage retaining net
Hooked onto the stowing rings on the
m o v a b l e b o o t fl o o r , t h i s e n a b l e s y o u t o
secure your luggage.
Observe the loads indicated on the side
of the boot, in accordance with the posi-
t i o n o f t h e m o v a b l e fl o o r .
For safety reasons in case of sharp
braking, we recommend that heavy ob-
j e c t s a r e p l a c e d o n t h e fl o o r a s c l o s e a s
possible to the back of the rear seats.
Page 121 of 315
FITTINGS
108
Adjustable boot floor
T h i s t h r e e p o s i t i o n fl o o r a l l o w s y o u t o o p t i -mise the volume of the boot by means
of the guides placed on the sides:
- H i g h p o s i t i o n ( 5 0 k g m a x ) : t h e fl o o r is level with the closed lower tail-
gate.
You can load objects while keeping an area protected and isolated.
- Intermediate position (100 kg max): t h e fl o o r i s l e v e l w i t h t h e o p e n l o w e r
tailgate.
Y o u o b t a i n a fl a t fl o o r t o t h e f r o n t seats when the rear seats are in the
retracted position.
- Low position (150 kg max): maxi- mum boot volume. T o p l a c e a n d s u p p o r t t h e fl o o r a t a n a n g l e :
From the high position, raise the
fl o o r t o w a r d s t h e l o a d s p a c e c o v e r .
Do not hesitate to pass the two re-
t r a c t a b l e s t o p s t h e n p l a c e t h e fl o o r
back on these two stops.
T o c h a n g e t h e h e i g h t o f t h e fl o o r :
P u s h t h e fl o o r f u l l y f o r w a r d s t h e n , w i t h
the help of the support stops A , move
t h e fl o o r t o t h e p o s i t i o n r e q u i r e d . T h e fl o o r i s e q u i p p e d w i t h f o u r s t o w i n g
rings to secure your luggage, observing
the loads indicated (in the boot).
