PRACTICAL INFORMATION
172
Parking the vehicle
I m m o b i l i s e t h e v e h i c l e w h e r e
i t d o e s n o t b l o c k t r a f fi c : t h e
g r o u n d m u s t b e l e v e l , s t a b l e a n d
n o n - s l i p p e r y g r o u n d .
Apply the parking brake unless it
has been programmed to automatic
m o d e , s w i t c h o f f t h e i g n i t i o n a n d e n -
g a g e fi r s t g e a r * t o l o c k t h e w h e e l s .
Check that the braking warning lamp
and the P w a r n i n g l a m p o n t h e p a r k -
i n g b r a k e c o n t r o l c o m e o n .
I f n e c e s s a r y , p l a c e a c h o c k u n d e r t h e
wheel diagonally opposite the wheel
t o b e c h a n g e d .
T h e o c c u p a n t s m u s t g e t o u t o f t h e v e -
h i c l e a n d w a i t w h e r e t h e y a r e s a f e .
Never go underneath a vehicle raised
u s i n g a j a c k ; u s e a n a x l e s t a n d .
Removing a wheel
List of operations
Remove the chromed bolt cover
from each of the bolts using the
tool 3 ( a c c o r d i n g t o e q u i p m e n t ) .
F i t t h e s e c u r i t y s o c k e t 5 on the
wheelbrace 1 to slacken the security
b o l t .
Slacken the other bolts using the
wheelbrace 1 o n l y .
Place the jack 2 in contact with one
of the two front A or rear B locations
p r o v i d e d o n t h e u n d e r b o d y , w h i c h -
ever is closest to the wheel to be
c h a n g e d .
E x t e n d t h e j a c k 2 until its base plate
i s i n c o n t a c t w i t h t h e g r o u n d . E n s u r e
that the centreline of the jack base
plate is directly below the location A
or B u s e d .
R a i s e t h e v e h i c l e u n t i l t h e r e i s s u f -
fi c i e n t s p a c e b e t w e e n t h e w h e e l a n d
the ground to admit the spare (not
p u n c t u r e d ) w h e e l e a s i l y .
Remove the bolts and store them in
a c l e a n p l a c e .
R e m o v e t h e w h e e l .
* p o s i t i o n R for the electronic gear
c o n t r o l m a n u a l g e a r b o x ; P for the
a u t o m a t i c g e a r b o x .
Page 198 of 315
PRACTICAL INFORMATION
Fitting the "space-saver"
spare wheel
I f y o u r v e h i c l e i s fi t t e d w i t h a l -
l o y w h e e l s , w h e n t i g h t e n i n g t h e b o l t s
o n fi t t i n g i t i s n o r m a l t o n o t i c e t h a t t h e
washers do not come into contact
w i t h t h e " s p a c e - s a v e r " s p a r e w h e e l .
The wheel is secured by the conical
c o n t a c t o f e a c h b o l t .
Fitting a wheel
List of operations
Put the wheel in place on the hub
using the centring guide 4 .
Screw in the bolts by hand to the
s t o p .
P r e - t i g h t e n t h e s e c u r i t y b o l t u s i n g
the wheelbrace 1 fi t t e d w i t h t h e
security socket 5 .
P r e - t i g h t e n t h e o t h e r b o l t s u s i n g t h e
wheelbrace 1 o n l y .
L o w e r t h e v e h i c l e f u l l y .
F o l d t h e j a c k 2 a n d d e t a c h i t .
Tighten the security bolt using the
wheelbrace 1 fi t t e d w i t h t h e s e c u r i t y
socket 5 .
Tighten the other bolts using the
wheelbrace 1 o n l y .
R e fi t t h e c h r o m e d b o l t c o v e r s o n
each of the bolts (according to
e q u i p m e n t ) .
S t o r e t h e t o o l s i n t h e b o x .
After changing a wheel
To store the punctured wheel in the
b o o t c o r r e c t l y , fi r s t r e m o v e t h e c e n t r a l
c o v e r .
W h e n u s i n g t h e " s p a c e - s a v e r " t y p e
s p a r e w h e e l , d o n o t e x c e e d 5 0 m p h
( 8 0 k m / h ) .
Have the tightening of the bolts and
the pressure of the spare wheel
c h e c k e d b y a P E U G E O T d e a l e r w i t h -
o u t d e l a y .
Have the punctured wheel repaired
and replace it on the vehicle as soon
a s p o s s i b l e .
Page 215 of 315
PRACTICAL INFORMATION
190
TOWING THE VEHICLE
Access to the tools Towing your vehicle
O n t h e f r o n t b u m p e r , u n c l i p t h e c o -
v e r b y p r e s s i n g a t t h e b o t t o m .
S c r e w t h e t o w i n g e y e i n f u l l y .
I n s t a l l t h e t o w i n g b a r .
Switch on the hazard warning lamps
o n t h e t o w e d v e h i c l e .
O n t h e r e a r b u m p e r , u n c l i p t h e c o v e r
b y p r e s s i n g a t t h e b o t t o m .
S c r e w t h e t o w i n g e y e i n f u l l y .
I n s t a l l t h e t o w i n g b a r .
Switch on the hazard warning lamps
o n t h e t o w e d v e h i c l e .
Towing another vehicle
The towing eye is installed in the boot
u n d e r t h e fl o o r .
T o g a i n a c c e s s t o i t :
o p e n t h e b o o t ,
r a i s e t h e fl o o r ,
secure it by hooking the cords on
the hooks on the rear parcel shelf
s u p p o r t ,
r e m o v e t h e p o l y s t y r e n e b o x ,
remove the towing eye from the
h o l d e r . When towing with all four
w h e e l s o n t h e g r o u n d , a l w a y s
u s e a t o w i n g b a r .
When towing with only two wheels on
t h e g r o u n d , a l w a y s u s e p r o f e s s i o n a l
l i f t i n g e q u i p m e n t .
W h e n t o w i n g w i t h t h e e n g i n e o f f ,
there is no longer any braking or
s t e e r i n g a s s i s t a n c e .
P l a c e t h e g e a r l e v e r i n n e u -
tral (position N o n t h e e l e c -
t r o n i c g e a r c o n t r o l g e a r b o x
o r a u t o m a t i c g e a r b o x ) .
F a i l u r e t o o b s e r v e t h i s s p e - cial condition could result
i n d a m a g e t o c e r t a i n b r a -
king components and the
a b s e n c e o f b r a k i n g a s s i s -
t a n c e t h e n e x t t i m e t h e e n -
g i n e i s s t a r t e d .
Procedure for having your vehicle towed
or for towing another vehicle using a
r e m o v a b l e t o w i n g e y e .
Page 226 of 315
201
EMERGENCY OR ASSISTANCE CALL
EMERGENCY CALL ASSISTANCE CALL
OPERATION OF THE SYSTEM
In an emergency, press this button for more than 2 seconds. Flashing of the green diode and a voice m e s s a g e c o n fi r m t h a t t h e c a l l h a s b e e n m a d e t o t h e PEUGEOT Emergency team * .
Pressing this button again immediately cancels the request. The green diode switches off.
T h e g r e e n d i o d e r e m a i n s o n ( w i t h o u t fl a s h i n g ) w h e n c o m m u n i c a t i o n i s established. It switches off at the end of communication.
This call is dealt with by the PEUGEOT Emergency team which receives locating information from the vehicle and can send a detailed alert to the appropriate emergency services. In countries in whi ch the team is not operational, or when the locating service has been expressly refused, t h e c a l l i s d e a l t w i t h d i r e c t l y b y t h e e m e r g e n c y s e r v i c e s ( 1 1 2 ) w i t h o u t t h e vehicle location.
If an impact is detected by the airbag ECU, and independently of any triggering of the airbags, an emergency call is mad e automatically.
* This service is subject to conditions and availability. Consult a PEUGEOT dealer.
Press this button for more than 2 seconds to requ est assistance if the vehicle breaks down. A v o i c e m e s s a g e c o n fi r m s t h a t t h e c a l l h a s b e e n m a d e * .
Pressing this button again immediately cancels the request. T h e c a n c e l l a t i o n i s c o n fi r m e d b y a v o i c e m e s s a g e .
When the ignition is switched on, the green indicator lamp comes on for 3 seconds indicating that the system is operating correctly.
I f t h e o r a n g e i n d i c a t o r l a m p fl a s h e s : t h e r e i s a system malfunction. I f t h e o r a n g e i n d i c a t o r l a m p i s l i t c o n t i n u o u s l y : the backup battery must be replaced. In both cases, consult a PEUGEOT dealer.
