Assembly of Armrest
Assembly is in the reverse order of disassembly.
Disassembly of Seatback Trim and Pad
1. Remove the headrest.
2. Remove the retainer under the back of seatback.
3. Remove the clips, and then remove the striker cover.
4. Remove the headrest holder.
5. To remove armrest, refer to "Disassembly of Armrest " .
6. Remove the seatback trim.
7. Remove the bolts, and then remove the rear seat lock assembly.
8. Remove the seatback pad from the seatback frame.
9. Remove the seatback center bracket
bolt and then remove the seatback frame.
PIIB2486J
PIIB2485J
PIIB4084J
PIIB2487J
Revision: January 20102010 Versa

REAR SEATSE-23
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
5. Remove the kicking plate rear inner. Refer to EI-40, "Removal and Installation" .
6. Remove the bolt under the seatback side.
7. Pull seatback side up, and then remove seatback side.
8. Remove the bolts, and then remove rear seatback center bracket.
9. Remove the bolt, and then remove rear seatback side bracket from the vehicle.
10. Remove the rear seatback finisher. Refer to EI-54, "
Removal and Installation" .
11. Remove the bolts, and then remove the rear seat striker.
Installation
Installation is in the reverse order of removal. Be careful of the following point.
• When installing the rear seatback side bracket perform the following procedure.
1. Install the rear seatback side bracket in the vehicle.
2. Temporarily tighten the seatback asse mbly and rear seatback side bracket.
3. Lift to fold up seatback assembly. Be sure to lock seatback assembly to rear seat striker.
4. Tighten the bolt.
PIIB2482J
PIIB2483J
PIIB2484J
PIIB2484J
Revision: January 20102010 Versa

REAR SEATSE-25
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
Disassembly of Seatback Trim and Pad
1. Remove the headrest.
2. Remove the retainer under the back of seatback.
3. Remove the clips, and then remove the striker cover.
4. Remove the headrest holder.
5. To remove armrest, refer to "Disassembly of Armrest " .
6. Remove the seatback trim.
7. Remove the bolts, and then remove the rear seat lock assembly.
8. Remove the seatback pad from the seatback frame.
9. Remove the seatback center bracket
bolt and then remove the seatback frame.
Assembly of Seatback Trim and Pad
Assembly is in the reverse order of disassembly.
• Before installing headrest holder, check its orientation (front/rear and right/left).
PIIB2486J
PIIB2485J
PIIB4084J
PIIB2487J
Revision: January 20102010 Versa

REAR SEATSE-27
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
Disassembly of Seat Cushion Trim and Pad
Remove the rings to separate the trim and pad.
Assembly of Seat Cushion Trim and Pad
Assembly is in the reverse order of disassembly.
