2010 Lexus GX460 Using The Bluetooth Audio System / LEXUS 2010 GX460 OWNERS MANUAL QUICK GUIDE (OM60E77U)

9
GX460_QG_U (OM60E77U)
OverviewRoof
Anti-glare inside rear view mirror*1
Compass*1
Moon roof switches
Garage door opener switches
*1
“SOS” button
P. 83
P. 77
Vanity mirrors*1
Sun visors*1
Personal/interior lights*1
SRS curtain shield airbags*1
Auxiliary box*1
Conversation mirror*1
Personal/interior lights*1
: If equipped
*1: Refer to “Owner’s Manual”.

10
GX460_QG_U (OM60E77U)
Keys
■Electronic key
Smart access system with push-button start
(P. 11, 14)
■Mechanical key
Carry the mechanical key together with the
electronic key. If the electronic key battery
is depleted or the entry function does not
operate properly, you will need the
mechanical key.
To take out the mechanical key, slide the
release lever and take the key out.
■Wireless remote control
Locks all the doors
Unlocks all the doors
Pressing the button unlocks the driver’s
door. Pressing the button again within 3
seconds unlocks the other doors.
Opens the windows and moon roof
(press and hold)*
Opens the glass hatch (press and hold)
The glass hatch can be opened only
when the back door is closed.
Sounds the alarm (press and hold)
*: This setting must be customized at your
Lexus dealer.

11
GX460_QG_U (OM60E77U)
Smart Access System with Push-button Start
■Entering the vehicle
Grip the handle to unlock the doors.
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.
■Exiting the vehicle
Touch the lock sensor (the indentation on
the upper or lower part of the door handle)
to lock the doors.
■Unlocking and locking the back door
Locks the all doors
Unlocks the all doors
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.
The following operations can be performed simply by carrying the electronic key on your
person, for example in your pocket.
For details on starting the engine, see page 14.

12
GX460_QG_U (OM60E77U)
■Opening the glass hatch
Press the button to open the glass hatch.
The glass hatch will pop up.
The glass hatch can be opened only
when the back door is closed.
Theft Deterrent System
■Immobilizer system
Without navigation system
The indicator light flashes after the
“ENGINE START STOP” switch has been
turned off to indicate that the system is
operating.
With navigatio n system
For details on what to do when the electronic key does not operate properly, see page 88.

13
GX460_QG_U (OM60E77U)
■Alarm
The system sounds the alarm and flashes the lights when forced entry is detected.
To set the alarm: Close the doors, glass hatch and hood, and lock all the doors. The system
will be set automatically after 30 seconds.
The indicator light changes from being on to flashing when the system is set.
To deactivate or stop the alarm: Start the engine (The alarm will be deactivated or stopped
after a few seconds), or unlock the doors.
■Steering lock
After turning the “ENGINE START STOP”
switch off and opening and closing the
doors, the steering wheel will be locked due
to the steering lock function. Operating the
“ENGINE START STOP” switch again
automatically cancels the steering lock.
When the steering lock cannot be released,
the green indicator light on the “ENGINE
START STOP” switch will flash and a mes-
sage will be shown on the multi-information
display. Press the “ENGINE START STOP”
switch again while turning the steering
wheel left and right.

14
GX460_QG_U (OM60E77U)
Engine (Ignition) Switch
■Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal.
The “ENGINE START STOP” switch
indicator will turn green. If the indica-
tor does not turn green, the engine
cannot be started.
Press the “ENGINE START STOP”
switch.
The engine will crank until it starts or
for up to 25 seconds, whichever is
less.
Continue depressing the brake pedal
until the engine is completely started.
The engine can be started from any
mode.
■Stopping the engine
Stop the vehicle.
Shift the shift lever to P.
Set the parking brake.
Press the “ENGINE START STOP” switch.
Release the brake pedal and check that the indicator on the “ENGINE START STOP”
switch is off.
Performing the following operations when carrying the electronic key on your person
starts the engine or changes “ENGINE START STOP” switch modes.

15
GX460_QG_U (OM60E77U)
■Changing “ENGINE START STOP” switch modes
Modes can be changed by pressing the “ENGINE START STOP” switch with brake pedal
released. (The mode changes each time the switch is pressed.)
Off*
The emergency flashers can be used.
ACCESSORY mode
Some electrical components such as the
audio system can be used.
The “ENGINE START STOP” switch
indicator turns amber.
IGNITION ON mode
All electrical components can be used.
The “ENGINE START STOP” switch
indicator turns amber.
*: If the shift lever is in a position other than
P when turning off the engine, the
“ENGINE START STOP” switch will be
turned to ACCESSORY mode, not to
OFF.

16
GX460_QG_U (OM60E77U)
Multi-information Display (Optitron Meters)
●Trip information contents
Displays driving range, fuel consumption and other cruising-related information.
●Electronic features control contents
●Multi-terrain Select display (if equipped)
●Intuitive parking assist display* (if equipped)
●Crawl Control display* (if equipped)
●Dynamic radar cruise control display* (if equipped)
●LDA (Lane Departure Alert) display* (if equipped)
●Wa r n i n g m e s s a g e s
Automatically displayed when a malfunction occurs in one of the vehicles systems.
(Refer to the “Owner’s Manual”.)
●Customization
Settings (e.g.available language) can be changed.
(Customizable features Refer to the “Owner’s Manual”.)
*: Automatically displayed when the system is used
■Switching the display
Menu switch
Changes modes to electronic features
control mode, customization mode or
back to normal display mode.
“ENTER” switch
Changes trip information items. This
switch is also used to turn on/off elec-
tronic features controls and to change
customization settings.
The multi-information display presents the driver with a variety of driving-related data.
