Page 1254 of 3039
Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive Belt Tensioner
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
3. Refer to: Air Cleaner Outlet Pipe LH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
Installation
4. NOTE: Note the fitted position.
5. Torque: 40 Nm
1. CAUTIONS:
Make sure the accessory belt is correctly aligned to the pulleys.
Failure to follow this instruction may result in damage to the vehicle.
Clean and inspect the accessory drive belt pulleys for damage.
To install, reverse the removal procedure.
Page 1255 of 3039
Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Idler Pulley
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
3. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
Installation
4. NOTES:
Note the fitted position.
Engine shown removed for clarity.
5. Torque: 40 Nm
1. CAUTION: Make sure the supercharger belt is correctly aligned to the
pulleys. Failure to follow this instruction may result in damage to
the vehicle.
To install, reverse the removal procedure.
Page 1256 of 3039
Published: 11-May-2011
Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Tensioner
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
3. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
Installation
4.
5. Torque: 40 Nm
Page 1268 of 3039
Published: 11-May-2011
Starting System - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Starter Motor
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).
4. Torque: 6 Nm 5. CAUTION: Make sure that the protective cover is
correctly installed over the electrical connector.
Torque: 12 Nm www.JagDocs.com
Page 1269 of 3039
7. Torque: 48 Nm
1. To install, reverse the removal procedure.
Page 1304 of 3039
4. Torque: 8 Nm
5. NOTES:
Do not disassemble further if the component is
removed for access only.
Some variation in the illustrations may occur, but the
essential information is always correct.
LH illustration shown, RH is similar.
6. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
Page 1307 of 3039
4. Torque: 8 Nm
5. NOTES:
Do not disassemble further if the component is
removed for access only.
Some variation in the illustrations may occur, but the
essential information is always correct.
LH illustration shown, RH is similar.
6. NOTES:
Some variation in the illustrations may occur, but the
essential information is always correct.
LH illustration shown, RH is similar.
Page 1311 of 3039
Published: 11-May-2011
Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol - Air Cleaner Outlet Pipe T-Connector
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Engine Cover - V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-05 Interior Trim and Ornamentation, Removal and Installation).
Installation
2. Torque: 10 Nm
1. To install, reverse the removal procedure. www.JagDocs.com
