WIPER AND WASHER SYSTEM SYMPTOMSWW-73
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
Rear wiper does not
stop. ON only
• Combination switch
•BCM Rear wiper motor circuit
Refer to WW-28, "
Compo-
nent Function Check".
INT only • Combination switch
•BCM Combination switch
Refer to BCS-56, "
Symptom
Ta b l e".
Rear wiper does not
operate normally. Wiper is not linked to
the washer operation.
• Combination switch
• Harness between rear wiper motor and BCM
•BCM
Combination switch
Refer to BCS-56, "
Symptom
Ta b l e".
BCM —
Rear wiper does not
return to the Stop posi-
tion (Stops after a five-
second operation). •BCM
• Harness between rear wiper motor and BCM
• Rear wiper motor Rear wiper auto stop signal
circuit
Refer to WW-30, "
Compo-
nent Function Check".
Rear wiper stops after
operating for five sec-
onds when ignition
switch is turned ON.
Symptom
Probable malfunction location Inspection item
Revision: April 20092010 QX56
WW-76
< SYMPTOM DIAGNOSIS >
FRONT WIPER DOES NOT OPERATE
1. Turn the ignition switch ON.
2. Select "FRONT WIPER" of IPDM E/R active test item.
3. With operating the test item, check voltage between IPDM E/R
harness connector and ground.
Is the measurement value normal?
YES >> Replace front wiper motor. Refer to WW-80, "Wiper Motor and Linkage".
NO >> Replace IPDM E/R. Refer to PCS-35, "
Removal and Installation of IPDM E/R".
5. CHECK FRONT WIPER REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select "FR WIP REQ" of IPDM E/R data monitor item.
2. Switch the front wiper switch to HI and LO.
3. With operating the front wiper switch , check the status of "FR WIP REQ".
Is the status of item normal?
YES >> Replace IPDM E/R. Refer to PCS-35, "Removal and Installation of IPDM E/R".
NO >> GO TO 6
6. CHECK COMBINATION SWITCH
1. Perform the inspection of the combination switch. Refer to BCS-56, "
Symptom Table".
Is combination switch normal?
YES >> Replace BCM. Refer to BCS-59, "Removal and Installation".
NO >> Repair or replace the applicable parts.
Te r m i n a l s Te s t i t e m
Voltage
(Approx.)
(+)
(− )
IPDM E/R
GroundFRONT WIP-
ER
Connector Terminal
E121 32
LO
Battery
voltage
OFF 0 V
35 HI
Battery
voltage
OFF 0 V
WKIA1427E
Monitor item ConditionMonitor
status
FR WIP REQ Front wiper switch HI
HI ON
STOP OFF
Front wiper switch LO 1LOW ON
STOP OFF
Revision: April 20092010 QX56
