DLN-66
< COMPONENT DIAGNOSIS >[ATX14B]
P1824 TRANSFER MOTOR
3. Check continuity between transfer motor harness connector F57
terminal 15 and ground.
Also check harness for short to ground and short to power.
Are the inspection results normal?
YES >> GO TO 6.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK TRANSFER MOTOR
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer motor harness connector.
3. Apply 12V direct current between transfer motor terminals 14 and 15.
Does transfer motor operate?
YES >> GO TO 7.
NO >> Replace transfer motor. Refer to DLN-140, "
Removal
and Installation".
7.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-81, "
Reference Value".
Are the inspection results normal?
YES >> GO TO 8.
NO >> Check transfer control unit pin terminals fo r damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
8.CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
Are the inspection results normal?
YES >> Inspection End.
NO >> Replace transfer control unit. Refer to DLN-130, "
Removal and Installation".
Component InspectionINFOID:0000000005148828
TRANSFER MOTOR RELAY
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove transfer motor relay. Refer to DLN-16, "
Component Parts Location".
3. Apply 12V direct current between transfer motor relay terminals 1 and 2.
4. Check continuity between relay terminals 3 and 5.
5. If inspection results are abnormal replace transfer motor relay.
TRANSFER MOTOR
Continuity should exist.
SDIA2740E
LDIA0097E
Condition Continuity
12V direct current supply between terminals 1 and 2 Yes
OFF No
LDIA0098E
Revision: April 20092010 QX56

P1824 TRANSFER MOTORDLN-67
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove transfer motor. Refer to DLN-140, "
Removal and Installation".
3. Apply 12V direct current between transfer motor terminals 14 and 15.
4. If transfer motor does not operate, replace transfer motor.
LDIA0097E
Revision: April 20092010 QX56

DLN-68
< COMPONENT DIAGNOSIS >[ATX14B]
P1826 TRANSFER FLUID TEMPERATURE
P1826 TRANSFER FLUID TEMPERATURE
DescriptionINFOID:0000000005148829
Signal voltage from the transfer fluid temperature sensor is abnormally high (Transfer fluid temperature is
abnormally low) while driving.
DTC LogicINFOID:0000000005148830
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1826 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-68, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005148831
Regarding Wiring Diagram information, refer to DLN-89, "Wiring Diagram - ALL-MODE 4WD SYSTEM -".
1.CHECK TRANSFER FLUID TEMPERATURE SENSOR SIGNAL
With CONSULT-III
1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out the value of FLUID TEMP SE.
Without CONSULT-III
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminals and ground.
Are inspection results normal?
DTC CONSULT-III Diagnostic item is detected when... Reference
[P1826] OIL TEMP SEN Signal voltage from transfer fluid temper-
ature sensor is abnormally high (Trans-
fer fluid temperature is abnormally low)
while driving.Refer to
DLN-68
.
Condition Display value
(Approx.)
Transfer fluid temperature approx. 20 - 80 °C (68 - 176 °F) 1.1 - 0.3V
Connector Terminal ConditionData
(Approx.)
E143 28 -
Ground Always
0V
31 -
Ground Ignition switch:
ON Transfer fluid temperature
approx. 20
°C (68 °F) 1.1V
Transfer fluid temperature
approx. 80 °C (176 °F) 0.3V
SDIA2742E
Revision: April 20092010 QX56

P1826 TRANSFER FLUID TEMPERATUREDLN-69
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TRANSF ER CONTROL UNIT AND TRANSFER TERMINAL CORD AS-
SEMBLY
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit har ness connector and transfer terminal cord assembly harness connec-
tor.
3. Check continuity between the following terminals.
- Transfer control unit harness connector E143 terminal 28 and
transfer terminal cord assembly harness connector F56 terminal
3 .
- Transfer control unit harness connector E143 terminal 31 and
transfer terminal cord assembly harness connector F56 terminal
2.
Also check harness for short to ground and short to power.
Are inspection results normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK TRANSFER FLUID TEMPERATURE SENSOR
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.
3. Check resistance between transfer terminal cord assembly ter- minals 2 and 3.
Are inspection results normal?
YES >> GO TO 4.
NO >> Replace transfer fluid temperature sensor. Refer to DLN-16, "
Component Parts Location".
4.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-81, "
Reference Value".
Are inspection results normal?
YES >> GO TO 5.
NO >> Check transfer control unit pin terminals for damage or loose connection with harness connector. If any items are damaged, repair or replace damaged parts.
5.CHECK DTC
Drive the vehicle and then perform self-diagnosis.
Are inspection results normal?
YES >> Inspection End.
NO >> Replace transfer control unit. Refer to DLN-130, "
Removal and Installation".
Component InspectionINFOID:0000000005148832
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer terminal cord assembly harness connector.Continuity should exist.
SDIA2743E
Temperature
°C ( °F) Resistance (Approx.)
20 (68) 2.5 kΩ
80 (176) 0.3 kΩ
WDIA0188E
Revision: April 20092010 QX56

P1827 CLUTCH PRESSURE SWITCHDLN-71
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
P1827 CLUTCH PRESSURE SWITCH
DescriptionINFOID:0000000005148833
Improper signal from the clutch pressure switch is input due to open or short circuit. Also, a malfunction may
have occured in clutch pressure switch or hydraulic circuit.
DTC LogicINFOID:0000000005148834
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1827 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-71, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005148835
Regarding Wiring Diagram information, refer to DLN-89, "Wiring Diagram - ALL-MODE 4WD SYSTEM -".
1.CHECK CLUTCH PRESSURE SWITCH SIGNAL
With CONSULT-III1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out ON/OFF switching action of the CL PRES SW while operating 4WD shift switch.
Without CONSULT-III
1. Start engine.
DTCCONSULT-III Diagnostic item is detected when... Reference
[P1827] CLUTCH PRES SW • Improper signal from clutch pressure
switch is input due to open or short cir-
cuit.
• Malfunction occurs in clutch pressure switch or hydraulic circuit. Refer to DLN-71
.
Condition
Display value
• Ignition switch: ON
• A/T selector lever D posi- tion 4WD shift switch: AUTO or 4H (Wait
function is not operating.)
ON
Ignition switch: ON 4WD shift switch: 2WD (Wait func-
tion is not operating.) OFF
Revision: April 20092010 QX56

DLN-72
< COMPONENT DIAGNOSIS >[ATX14B]
P1827 CLUTCH PRESSURE SWITCH
2. Check voltage between transfer control unit harness connector
terminals and ground.
Are inspection results normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TRANSFER CONT ROL UNIT AND CLUTCH PRESSURE SWITCH
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the transfer terminal cord assembly harness con-
nector.
3. Check continuity between transfer control unit harness connec- tor E143 terminal 34 and transfer terminal cord assembly har-
ness connector F56 terminal 7
Also check harness for short to ground and short to power.
Are inspection results normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to DLN-81, "
Reference Value".
Are inspection results normal?
YES >> GO TO 4.
NO >> Check transfer control unit pin terminals for damage or loose connection with the harness connec- tor. If any items are damaged, repair or replace damaged parts.
4.CHECK CLUTCH PRESSURE SWITCH
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove clutch pressure switch. Refer to DLN-16, "
Component Parts Location".
3. Push and release clutch pressure switch and check continuity between terminal 7 and ground.
Are inspection results normal?
YES >> GO TO 5.
NO >> Replace clutch pressure switch.
5.CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
Are inspection results normal?
Connector Terminal ConditionVoltage
(Approx.)
E143 34 -
Ground • Ignition switch: ON
• A/T selector lever D
position 4WD shift switch:
AUTO or 4H (Wait
function is not op-
erating.)
0V
Ignition switch: ON 4WD shift switch:
2WD (Wait function
is not operating.)Battery
voltage
SDIA2746E
Continuity should exist.
SDIA2747E
Terminal
Condition Continuity
7 -
Ground Push clutch pressure switch
Yes
Release clutch pressure switch No
WDIA0171E
Revision: April 20092010 QX56

P1827 CLUTCH PRESSURE SWITCHDLN-73
< COMPONENT DIAGNOSIS > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
YES >> GO TO 6.
NO >> Replace transfer control unit. Refer to DLN-130, "
Removal and Installation".
6.CRUISE TEST
Perform cruise test. Refer to DLN-7, "
Preliminary Check".
Are inspection results normal?
YES >> Inspection End.
NO >> Perform the applicable trouble diagnosis.
Component InspectionINFOID:0000000005148836
1. Turn ignition switch OFF. (Stay for at least 5 seconds.)
2. Remove clutch pressure switch. Refer to DLN-16, "
Component Parts Location".
3. Push and release clutch pressure switch and check continuity between terminal 7 and ground.
4. If the inspection results are abnormal replace the clutch pres- sure switch.
Terminal Condition Continuity
7 - Ground Push clutch pressure switch
Yes
Release clutch pressure switch No
WDIA0171E
Revision: April 20092010 QX56

DLN-74
< COMPONENT DIAGNOSIS >[ATX14B]
P1828 LINE PRESSURE SWITCH
P1828 LINE PRESSURE SWITCH
DescriptionINFOID:0000000005148837
Improper signal from line pressure switch is input due to open or short circuit. Also, a malfunction may have
occured in the line pressure switch or hydraulic circuit.
DTC LogicINFOID:0000000005148838
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Perform self-diagnosis.
Is DTC P1828 displayed?
YES >> Perform diagnosis procedure. Refer to DLN-74, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000005148839
Regarding Wiring Diagram information, refer to DLN-89, "Wiring Diagram - ALL-MODE 4WD SYSTEM -".
1.CHECK LINE PRESSURE SWITCH SIGNAL
With CONSULT-III1. Start engine.
2. Select DATA MONITOR mode for ALL MODE AWD/4WD with CONSULT-III.
3. Read out ON/OFF switching action of LINE PRES SW while operating 4WD shift switch.
Without CONSULT-III
1. Start engine.
DTCCONSULT-III Diagnostic item is detected when... Reference
[P1828] LINE PRES SW • Improper signal from line pressure
switch is input due to open or short cir-
cuit.
• Malfunction occurs in line pressure switch or hydraulic circuit. Refer to
DLN-74
.
Condition Display value
• A/T selector lever D position
• 4WD shift switch: AUTO ON
• Except the above
• The vehicle has been left at room temperature for 5
minutes and more with ig-
nition switch in OFF posi-
tion. • Ignition switch: ON
• A/T selector lever: P or N position
• 4WD shift switch: other than
AUTO OFF
Revision: April 20092010 QX56
