2010 INFINITI QX56 Power window

FRONT PASSENGER SIDE POWER WINDOW ALONE DOES NOT OPERATE
PWC-99
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
FRONT PASSENGER SIDE POWER WINDOW ALONE DOES NOT OPER-
AT E
Diagnosis ProcedureINFOID:0000000005147248
1. CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Check power window and door lock/unlock switch RH.
Refer to PWC-13, "
FRONT POWER WINDOW SWITCH : Component Function Check".
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK POWER WINDOW AND DOOR LOCK/ UNLOCK SWITCH RH SERIAL LINK CIRCUIT
Check power window and door lock/unlock switch RH serial link circuit.
Refer to PWC-40, "
FRONT POWER WINDOW SWITCH : Component Function Check".
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace the malfunctioning parts.
3. CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT
Check front power window motor RH circuit.
Refer to PWC-18, "
PASSENGER SIDE : Component Function Check".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "
Intermittent Incident".
Revision: April 20092010 QX56

PWC-100
< SYMPTOM DIAGNOSIS >
REAR LH SIDE POWER WINDOW ALONE DOES NOT OPERATE
REAR LH SIDE POWER WINDOW ALONE DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000005147249
1. CHECK REAR POWER WINDOW SWITCH LH
Check rear power window switch LH.
Refer to PWC-15, "
REAR POWER WINDOW SWITCH : Component Function Check".
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK REAR POWER WINDOW MOTOR LH
Check rear power window motor LH.
Refer to PWC-20, "
REAR LH : Component Function Check".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "
Intermittent Incident".
Revision: April 20092010 QX56

REAR RH SIDE POWER WINDOW ALONE DOES NOT OPERATE
PWC-101
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REAR RH SIDE POWER WINDOW ALONE DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000005147250
1. CHECK REAR POWER WINDOW SWITCH RH
Check rear power window switch RH.
Refer to PWC-15, "
REAR POWER WINDOW SWITCH : Component Function Check".
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK REAR POWER WINDOW MOTOR RH
Check rear power window motor RH.
Refer to PWC-21, "
REAR RH : Component Function Check".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "
Intermittent Incident".
Revision: April 20092010 QX56

PWC-110
< SYMPTOM DIAGNOSIS >
POWER WINDOW RETAINED POWER OPERATION DOES NOT OPERATE
PROPERLY
POWER WINDOW RETAINED POWER OPERATION DOES NOT OPER-
ATE PROPERLY
Diagnosis ProcedureINFOID:0000000005147259
1. CHECK FRONT DOOR SWITCH
Check front door switch.
Refer to PWC-34, "
Component Function Check".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "
Intermittent Incident".
Revision: April 20092010 QX56

PWC-112
< SYMPTOM DIAGNOSIS >
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
KEYLESS POWER WINDOW DOWN DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000005147261
1. CHECK INTELLIGENT KEY FUNCTION
Check Intelligent Key function.
Refer to DLK-56, "
CONSULT-III Function (INTELLIGENT KEY)".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incident".
NO >> Replace BCM. Refer to BCS-59, "
Removal and Installation".
Revision: April 20092010 QX56

POWER WINDOW LOCK SWITCH DOES NOT FUNCTIONPWC-113
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW LOCK SWITCH DOES NOT FUNCTION
Diagnosis ProcedureINFOID:0000000005147262
1. REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
Replace main power window and door lock/unlock switch.
Refer to PWC-117, "
Removal and Installation".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "
Intermittent Incident".
Revision: April 20092010 QX56

PWC-114
< SYMPTOM DIAGNOSIS >
REAR POWER VENT WINDOWS DO NOT OPERATE
REAR POWER VENT WINDOWS DO NOT OPERATE
Diagnosis ProcedureINFOID:0000000005147263
1. CHECK BCM POWER SUPPLY AND GROUND CIRCUIT
Check BCM power supply and ground circuit.
Refer to BCS-33, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace the malfunctioning parts.
2. CHECK REAR POWER VENT WINDOW SWITCH
Check rear power vent window switch.
Refer to PWC-44, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace the malfunctioning parts.
3. CHECK REAR POWER VENT WINDOW MOTOR CIRCUIT
Check rear power vent window motor circuit.
Refer to PWC-45, "
Diagnosis Procedure" and PWC-46, "Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace the malfunctioning parts.
4. CHECK REAR POWER VENT WINDOW RELAY
Check rear power vent window relay.
Refer to PWC-47, "
Diagnosis Procedure" and PWC-49, "Diagnosis Procedure".
Is the inspection result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-38, "
Intermittent Incident".
Revision: April 20092010 QX56

POWER WINDOW MAIN SWITCHPWC-117
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
ON-VEHICLE REPAIR
POWER WINDOW MAIN SWITCH
Removal and InstallationINFOID:0000000005147265
REMOVAL
1. Remove the power window main switch finisher (2) from the door finisher LH. Refer to INT-11, "
Removal and Installation".
2. Using a suitable tool (A), remove the screws from the power win- dow main switch (1), then release from the finisher (2).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA0856ZZ
Revision: April 20092010 QX56
