< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
OVERHEAD CONSOLE AREA ANTENNA
OVERHEAD CONSOLE AREA ANTENNA
DescriptionINFOID:0000000005146920
Detects whether Intelligent Key is inside the vehicle.
Component Function CheckINFOID:0000000005146921
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL
With CONSULT-III
1. Check “ANTENNA” in “Active Test” mode with CONSULT-III.
2. Touch “ROOM ANT2”.
3. When Intelligent Key is in overhead consol e area antenna detection area, hazard lamps flash.
Is the inspection result normal?
YES >> Overhead console area antenna is OK.
NO >> Refer to DLK-66, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000005146922
Regarding Wiring Diagram information, refer to DLK-178, "Wiring Diagram — INTELLIGENT KEY SYSTEM —
".
1.CHECK INSIDE KEY ANTENNA POWER SUPPLY SIGNAL
1. Turn ignition switch OFF.
2. Check signal between Intelligent Key unit connector and ground with an oscilloscope.
Is the inspection result normal?
YES >> Overhead console area antenna is OK.
NO >> GO TO 2
2.CHECK INSIDE KEY ANTENNA
1. Disconnect Intelligent Key unit connector and overhead console area antenna connectors.
2. Check continuity between Intelligent Key unit harness connector (A) M70 terminals 33, 34 and overhead console area antenna harness connector (B) R210 terminals 1, 2.
Test Item Condition Possible cause
ROOM ANT2 An excessive high or low voltage from inside
antenna is sent to the Intelligent Key Unit • Overhead console area antenna
• Between Intelligent Key unit and overhead console area
antenna
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 33 Ground Ignition
switch is
pushed.
ALKIA0589ZZPIIB7441E
Revision: April 20092010 QX56

OVERHEAD CONSOLE AREA ANTENNADLK-67
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Check continuity between Intelligent Key unit harness connector (A) M70 terminals 33, 34 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness between Intelligent Key unit and overhead console area antenna.
3.CHECK INSIDE KEY ANTENNA POWER SUPPLY SINGAL
1. Replace overhead console area antenna. (New antenna or other antenna)
2. Connect Intelligent Key unit connector.
3. Check signal between Intelligent Key unit connector and ground with oscilloscope.
Is the inspection result normal?
YES >> Replace overhead console area antenna.
NO >> Replace Intelligent Key unit. Refer to SEC-120, "
Removal and Installation".
Intelligent Key
unit connectorTe r m i n a l sOverhead console
area antenna con-
nector Terminals Continuity
A: M70 33
B: R210 1
Ye s
34 2
Item Connector TerminalsContinuity
Intelligent Key unit A: M70 33
Ground No
34
ALKIA0590ZZ
Connector Item Te r m i n a l s
Condition Signal (V)
(Reference value)
(+) (–)
M70 Intelligent
Key unit 33 Ground Ignition
switch is
pushed.
ALKIA0589ZZ
PIIB7441E
Revision: April 20092010 QX56

DLK-68
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
INTELLIGENT KEY UNIT
INTELLIGENT KEY UNIT
: Diagnosis ProcedureINFOID:0000000005146923
Regarding Wiring Diagram information, refer to DLK-178, "Wiring Diagram — INTELLIGENT KEY SYSTEM —
".
1.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key unit connector.
3. Check voltage between Intelligent Key unit harness connector M70 terminals 6, 11 and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace Intelligent Key unit power supply circuit.
2.CHECK GROUND CIRCUIT
Check continuity between Intelligent Key unit harness connector
M70 terminal 12 and ground.
Is the inspection result normal?
YES >> Power supply and ground circuits are OK.
NO >> Repair or replace the Intelligent Key unit ground circuit.
BCM (BODY CONTROL MODULE)
BCM (BODY CONTROL MODULE) : Diagnosis ProcedureINFOID:0000000005380580
Regarding Wiring Diagram information, refer to BCS-49, "Wiring Diagram".
1. CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
Connector Terminals Ignition switch position
M70 (+) (–) OFF
ON
6 Ground 0V Battery voltage
11 Battery voltage Battery voltage
WIIA1171E
12 - Ground : Continuity should exist.
WIIA1172E
Terminal No. Signal nameFuses and fusible link No.
57 Battery power supply 22 (15A)
70 F (50A)
11 Ignition ACC or ON 4 (10A)
38 Ignition ON or START 59 (10A)
Revision: April 20092010 QX56

POWER SUPPLY AND GROUND CIRCUITDLK-69
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair or replace harness.
BACK DOOR CONTROL UNIT
BACK DOOR CONTROL UNIT : Diagnosis ProcedureINFOID:0000000005146925
Regarding Wiring Diagram information, refer to DLK-199, "Wiring Diagram—AUTOMATIC BACK DOOR SYS-
TEM—".
1.BACK DOOR POWER SUPPLY CIRCUIT INSPECTION
1. Turn ignition switch OFF.
2. Disconnect back door control unit connector.
Connector Te r m i n a l s
Power
source Condition Voltage (V) (Ap-
prox.)
(+) (-)
M18 11 Ground
ACC
power
supply Ignition
switch
ACC or
ON Battery voltage
38 Ground Ignition
power
supply Ignition
switch ON or START Battery voltage
M20 57 Ground
Battery
power
supply Ignition
switch OFF Battery voltage
70 Ground Battery
power
supply Ignition
switch
OFF Battery voltage
LIIA2415E
BCM
GroundContinuity
Connector Terminal
M20 67 Yes
LIIA0915E
Revision: April 20092010 QX56

DLK-70
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
3. Check voltage between back door control unit connector B55
terminals 3, 7, 10 and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair the back door control unit power supply circuit.
2.BACK DOOR GROUND CIRCUIT INSPECTION
Check continuity between back door control unit connector B55 ter-
minal 1, 2 and ground.
Is the inspection result normal?
YES >> Circuit is OK.
NO >> Repair the harness between the back door control unit and ground.
Connector Te r m i n a l s
Power
source Condition
Voltage (V) (Ap-
prox.)
(+) (-)
B55 3Ground
Battery
power
supply Ignition
switch OFF Battery voltage
7Ground Ignition
power
supply Ignition
switch ON
or START Battery voltage
10 Ground Battery
power
supply Ignition
switch OFF Battery voltage
ALKIA1604ZZ
BCM
GroundContinuity
Connector Terminal
B55 1Y
es
2Y es
LIIA0801E
Revision: April 20092010 QX56

DOOR SWITCHDLK-71
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR SWITCH
DescriptionINFOID:0000000005146926
Detects door open/close condition.
Component Function CheckINFOID:0000000005146927
1.CHECK FUNCTIONWith CONSULT-III
Check door switches in data monitor mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-71, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000005146928
Regarding Wiring Diagram information, refer to DLK-157, "Wiring Diagram — POWER DOOR LOCK SYS-
TEM —".
1.CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-III
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", "BACK DOOR
SW") in DATA MONITOR mode with CONSULT–III.
• When doors are open:
• When doors are closed:
Without CONSULT-III
Check voltage between BCM connector M18 or M19 terminals 12, 13, 43, 47, 48 and ground.
Monitor item Condition
DOOR SW-DR
CLOSE → OPEN: OFF → ON
DOOR SW-AS
DOOR SW-RL
DOOR SW-RR
BACK DOOR SW
DOOR SW-DR :ON
DOOR SW-AS :ON
DOOR SW-RL :ON
DOOR SW-RR :ON
BACK DOOR SW :ON
DOOR SW-DR :OFF
DOOR SW-AS :OFF
DOOR SW-RL :OFF
DOOR SW-RR :OFF
BACK DOOR SW :OFF
Revision: April 20092010 QX56

DLK-72
< COMPONENT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR SWITCH
Is the inspection result normal?
YES >> Door switch circuit is OK.
NO >> GO TO 2
2.CHECK DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door switch and BCM.
3. Check continuity between BCM connector (A) M18, M19 terminals 12, 13, 43, 47, 48 and door switch con-
nector (B) B8 (Front LH), B108 (Front RH), B18 (Rear LH), B116 (Rear RH) terminal 2 or back door latch
connector (C) D503 terminal 7.
4. Check continuity between door switch connector (B) B8 (Front
LH), B108 (Front RH), B18 (Rear LH), B116 (Rear RH) terminal
2 or back door latch connector (C) D503 terminal 7 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3.CHECK DOOR SWITCHES
• Disconnect door switch harness.
• Check continuity between door switch connector terminals.
Connec- tor Item Te r m i n a l s
ConditionVoltage (V)
(Approx.)
( + ) ( – )
M19 Back door
switch/latch 43
Ground Open
↓
Closed 0
↓
Battery voltage
Front door
switch LH 47
Rear door switch LH 48
M18 Front door
switch RH 12
Rear door
switch RH 13
LIIA1041E
2 - 47
:Continuity should exist
2 - 12 :Continuity should exist
2 - 48 :Continuity should exist
2 - 13 :Continuity should exist
7 - 43 :Continuity should exist
2 - Ground :Continuity should not exist
7 - Ground :Continuity should not exist
ALKIA0689ZZ
Revision: April 20092010 QX56

DOOR SWITCHDLK-73
< COMPONENT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> Door switch circuit is OK.
NO >> (Front and rear doors) Replace door switch.
NO >> (Back door) GO TO 4
4.CHECK BACK DOOR SWITCH CIRCUIT
• Check continuity between door switch connector terminal and ground.
Is the inspection result normal?
YES >> Replace back door switch.
NO >> Repair or replace harness.
Switch Terminals Condition Continuity
A: Door switch
(front and rear) 2 – GroundOpen
Yes
Closed No
B: Back door switch 7 – Ground Open
Yes
Closed No
ALKIA0690ZZ
Connector TerminalsContinuity
Back door switch 8 – GroundYes
ALKIA0691ZZ
