2010 INFINITI QX56 heater

INTAKE DOOR MOTORVTL-27
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
INTAKE DOOR MOTOR
Removal and InstallationINFOID:0000000005147617
Intake Door Motor - Front Heater and Cooling Unit Assembly
REMOVAL
1. Remove the front heater and cooling unit assembly. Refer to VTL-17, "Removal and Installation".
2. Remove the steering member from the front heater and cooling unit assembly.
3. Disconnect the intake door motor electrical connector.
4. Remove the three screws and remove the intake door motor.
INSTALLATION
Installation is in the reverse order of removal.
LJIA0139E
1. Front heater and cooling unit assembly 2. Intake door motor 3. Air mix door motor (driver)
4. Variable blower control 5. Air mix door motor (passenger) 6. Mode door motor
7. Defroster door motor
Revision: April 20092010 QX56

VTL-28
< ON-VEHICLE REPAIR >
MODE DOOR MOTOR
MODE DOOR MOTOR
ComponentsINFOID:0000000005147618
Front Mode Door Motor - Front Heater and Cooling Unit Assembly
LJIA0139E
1. Front heater and cooling unit assembly 2. Intake door motor3. Air mix door motor (driver)
4. Variable blower control 5. Air mix door motor (passenger) 6. Mode door motor
7. Defroster door motor
Revision: April 20092010 QX56

MODE DOOR MOTORVTL-29
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
Rear Mode Door Motor - Rear Heater and Cooling Unit Assembly
Removal and InstallationINFOID:0000000005147619
FRONT MODE DOOR MOTOR
Removal
1. Remove the instrument lower panel LH. Refer to IP-11, "Exploded View".
2. Remove the accelerator pedal. Refer to ACC-4, "
Removal and Installation".
3. Remove the BCM. Refer to BCS-59, "
Removal and Installation".
4. Remove the BOSE amp. (if equipped). Refer to AV-182, "
Removal and Installation".
5. Remove the center console lower cover LH. Refer to IP-20, "
Removal and Installation".
6. Disconnect the front mode door motor connector.
7. Remove the two screws and remove the front mode door motor.
Installation
Installation is in the reverse order of removal.
REAR MODE DOOR MOTOR
Removal
1. Remove the luggage side finisher lower and upper RH. Refer to INT-19, "Removal and Installation".
2. Remove the rear heater and cooling unit assembly. Refer to VTL-17, "
Removal and Installation".
3. Disconnect the rear mode door motor connector.
4. Remove the two screws and remove rear mode door motor.
Installation
Installation is in the reverse order of removal.
ALIIA0065ZZ
1. Variable blower control 2. Mode door motor3. Rear heater and cooling unit assembly
Front
Revision: April 20092010 QX56

VTL-30
< ON-VEHICLE REPAIR >
AIR MIX DOOR MOTOR
AIR MIX DOOR MOTOR
ComponentINFOID:0000000005147620
Front Air Mix Door Motors - Front Heater and Cooling Unit Assembly
LJIA0139E
1. Front heater and cooling unit assembly 2. Intake door motor3. Air mix door motor (driver)
4. Variable blower control 5. Air mix door motor (passenger) 6. Mode door motor
7. Defroster door motor
Revision: April 20092010 QX56

AIR MIX DOOR MOTORVTL-31
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
Rear Air Mix Door Motor - Rear Heater and Cooling Unit Assembly
Removal and InstallationINFOID:0000000005147621
FRONT AIR MIX DOOR MOTOR (DRIVER)
Removal
1. Remove the front heater and cooling unit assembly. Refer to VTL-17, "Removal and Installation".
2. Remove the steering member from the front heater and cooling unit assembly.
3. Disconnect the air mix door motor electrical connector.
4. Remove the three screws and remove the air mix door motor.
Installation
Installation is in the reverse order of removal.
FRONT AIR MIX DOOR MOTOR (PASSENGER)
Removal
1. Remove the center console lower cover LH. Refer to IP-12, "Removal and Installation".
2. Disconnect the air mix door motor electrical connector.
3. Remove the three screws and remove the air mix door motor.
Installation
Installation is in the reverse order of removal.
REAR AIR MIX DOOR MOTOR
Removal
1. Remove the luggage side lower finisher RH. Refer to INT-19, "Removal and Installation".
ALIIA0066ZZ
1. Air mix door motor2. Heater core 3. Blower motor
4. Variable blower control 5. Rear heater and cooling unit assembly Front
Revision: April 20092010 QX56

DUCTS AND GRILLESVTL-33
< ON-VEHICLE REPAIR >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
DUCTS AND GRILLES
ComponentINFOID:0000000005147624
Ducts - Front Heater and Cooling Unit Assembly
AWIIA0090ZZ
1. Defroster nozzle 2. LH side demister duct3. LH ventilator duct
4. RH side demister duct 5. RH ventilator duct6. Center ventilator duct
Revision: April 20092010 QX56

VTL-34
< ON-VEHICLE REPAIR >
DUCTS AND GRILLES
Ducts - Rear Heater and Cooling Unit Assembly
7. Front heater and cooling unit assembly 8. Floor duct9. Clips
10. Heat duct Front
AWIIA0091GB
1. Rear floor duct2. Rear heater and cooling unit assembly 3. Rear lower overhead duct
4. Rear upper overhead duct Front
Revision: April 20092010 QX56

VTL-36
< ON-VEHICLE REPAIR >
DUCTS AND GRILLES
Removal and Installation
INFOID:0000000005147625
CENTER CONSOLE HEAT DUCT AND REAR FINISHER ASSEMBLY GRILLE
Removal
The center console must be removed and disassembled to remove the heat duct and rear finisher assembly
grille. Refer to IP-20, "
Removal and Installation".
Installation
Installation is in the reverse order of removal.
DEFROSTER NOZZLE
Removal
1. Remove the instrument panel trim. Refer to IP-12, "Removal and Installation".
2. Remove the front heater and cooling unit assembly. Refer to VTL-17, "
Removal and Installation".
3. Remove the defroster nozzle.
Installation
Installation is in the reverse order of removal.
RH AND LH SIDE DEMISTER DUCT
Removal
1. Remove the instrument panel trim. Refer to IP-12, "Removal and Installation".
2. Remove the RH or LH side demister duct screws.
3. Remove the RH or LH side demister duct.
Installation
Installation is in the reverse order of removal.
RH AND LH VENTILATOR DUCT
Removal
1. Remove the instrument panel trim. Refer to IP-12, "Removal and Installation".
2. Remove the front heater and cooling unit assembly. Refer to VTL-17, "
Removal and Installation".
3. Remove the RH or LH ventilator duct.
Installation
Installation is in the reverse order of removal.
CENTER VENTILATOR DUCT
Removal
1. Remove the instrument panel trim. Refer to IP-12, "Removal and Installation".
2. Remove the front heater and cooling unit assembly. Refer to VTL-17, "
Removal and Installation".
3. Remove the defroster nozzle.
4. Remove the RH and LH side demister ducts.
5. Remove the RH and LH ventilator ducts.
6. Remove the center ventilator duct.
Installation
Installation is in the reverse order of removal.
FLOOR DUCT
Removal
1. Remove the floor carpet. Refer to INT-16, "Removal and Installation".
2. Remove the two clips and remove the floor duct.
Installation
Installation is in the reverse order of removal.
Revision: April 20092010 QX56
